Citizen CBM1000II RF Manual de instalación

LINE THERMAL PRINTER

MODEL CBM1000II

Rev. 2.01 Newly issued on June 19, 2003

Command Reference

Rev.No. Date Comment

Rev. 1.00 2001/10/19 Newly issued

Rev. 2.00 2002/05/09 Added “GS p” on Page 89.

Rev. 2.01 2003/06/19 Added parameter on ESC t (After MPV3.12000).

REVISION

— 1 —

1 HT Horizontal tab S.P.

<09>H

2 LF Printing and paper feed S.P.

<0A>H

3 CR Back to printing S.P.

<0D>H

4FF

Printing in PAGE MODE and returning to P

<0C>H

STANDARD MODE

Printing and paper feeding to the top of

the Label (Black mark position) S

5 CAN Canceling print data in PAGE MODE P

<18>H

6 DLE EOT Sending status in real-time S.P.

<10>H<04>H<n>

7 DLE ENQ Real-time request to printer S.P.

<10>H<05>H<n>

8 DLE DC4 Outputting specified pulse in real-time S.P.

<10>H<14>H<n>

<m><t>

9 ESC FF Printing data in PAGE MODE P

<1B>H<0C>H

10 ESC RS Buzzer-on S.P.

<1B>H<1E>H

11 ESC SP Setting the right spacing of the character S.P.*

<1B>H<20>H<n>

12 ESC ! Collectively specifying the printing mode S.P.

<1B>H<21>H<n>

13 ESC $ Specifying the absolute positions S.P.*

<1B>H<24>H<n1>

<n2>

14 ESC %

Specifying/Canceling download character set

S.P.

<1B>H<25>H<n>

<1B>H<26>H<s>H

15 ESC & Defining the download characters S.P.

<p2> ⋅ ⋅ <ps×a>]

m-n+1

16 ESC *Specifying the bit image mode S.P.

<1B>H<2A>H<m>

<n1><n2>[<d>]k

17 ESC - Specifying/Canceling underline S.P.

<1B>H<2D>H<n>

18 ESC 2 Specifying 1/6-inch line feed rate S.P.

<1B>H<32>H

19 ESC 3 Setting line feed rate of minimum pitch S.P.*

<1B>H<33>H<n>

20 ESC = Data input control S.P.

<1B>H<3D>H<n>

21 ESC ? Deleting download characters S.P.

<1B>H<3F>H<n>

22 ESC @ Initializing the printer S.P.

<1B>H<40>H

23 ESC D Setting horizontal tab position S.P.

<1B>H<44>H [<n>]k<00>

24 ESC E Specifying/Canceling Emphasis Printing S.P.

<1B>H<45>H<n>

25 ESC G

Specifying/Canceling Double strike printing

S.P.

<1B>H<47>H<n>

26 ESC J

Printing and feeding paper in minimum pitch

S.P.*

<1B>H<4A>H<n>

27 ESC L Selecting PAGE MODE S

<1B>H<4C>H

28 ESC M Selection of character fonts S.P.

<1B>H<4D>H<n>

29 ESC R Selecting the international character set S.P.

<1B>H<52>H<n>

30 ESC S Selecting STANDARD MODE P

<1B>H<53>H

No.

Command

Function Mode Code Page

1. PRINT CONTROL FUNCTIONS

1.1 Command List

— 2 —

No.

Command

Function Mode Code Page

In the Mode column: S = STANDARD MODE, P = PAGE MODE

*shows the command affected by GS P.

31 ESC T Selecting the character printing direction P

<1B>H<54>H<n>

in PAGE MODE

32 ESC V Specifying/Canceling 90°-right-turned S

<1B>H<56>H<n>

characters

<1B>H<57>H<xL><xH>

33 ESC W Defining the print area in PAGE MODE P*

34 ESC \ Specifying the relative position S.P.*

<1B>H<5C>H<nL><nH>

35 ESC a Aligning the characters S.P.

<1B>H<61>H<n>

36 ESC c3 Selecting the Paper Sensor valid for S.P.

<1B>H<63>H<33>H

paper end signal output

<n>

37 ESC c4 Selecting the Paper Near-end Sensor valid S.P.

<1B>H<63>H<34>H

for print stop

<n>

38 ESC c5 Enabling/Disabling the panel switches S.P.

<1B>H<63>H<35>H

<n>

39 ESC d

Printing and feeding the paper by “n” lines

S.P.

<1B>H<64>H<n>

40 ESC p Generating the specified pulses S.P.

<1B>H<70>H<m>

41 ESC t Selecting the character code table S.P.

<1B>H<74>H<n>

42 ESC {

Specifying/Canceling the inverted characters

<1B>H<7B>H<n>

43 GS ! Specifying the character size S.P.

<1D>H<21>H<n>

44 GS $ Specifying the absolute vertical position P*

<1D>H<24>H<nL>

of characters in PAGE MODE

<nH>

45 GS *Defining the download bit image S.P.

<1D>H<2A>H<n1>

<n2>[<d>]n1×n2×8

46 GS ( A Execution of test printing S

<1D>H<28>H<41>H

47 GS / Printing the downloaded bit image S.P.

<1D>H<2F>H<m>

48 GS : Starting/Ending macro definition S.P.

<1D>H<3A>H

49 GS B Specifying/Canceling the black/white S.P.

<1D>H<42>H<n>

inverted printing

50 GS H Selecting of printing position of HRI S.P.

<1D>H<48>H<n>

characters

51 GS I Sending the printer ID S.P.

<1D>H<49>H<n>

52 GS L Setting the left margin S*

<1D>H<4C>H<nL>

<nH>

53 GS P Specifying the basic calculation pitch S.P.

<1D>H<50>H<x>

<y>

(

1)<1D>H<56>H<m>

54 GS V Cutting the paper S.P.*

(2)<1D>H<56>H<m>

<n>

— 3 —

55 GS W Setting the print area width S.P.*

<1D>H<57>H<nL>

<nH>

56 GS \ Specifying the relative vertical position S.P.*

<1D>H<5C>H<nL>

of a character in PAGE MODE

<nH>

57 GS ^ Executing the macro S.P.

<1D>H<5E>H<n1>

58 GS a Enabling/Disabling ASB (Automatic Status S.P.

<1D>H<61>H<n>

Back)

59 GS b Specifying/Canceling the smoothing S.P.

<1D>H<62>H<n>

60 GS f Selecting the font of HRI characters S.P.

<1D>H<66>H<n>

61 GS h Specifying the height of the bar code S.P.

<1D>H<68>H<n>

(1)<1D>H<6B>H<m>

62 GS k Printing the bar code S.P.

[d1...dk]NUL

(2)<1D>H<6B>H<m>

<n>[d1...dn]

63 GS p Selecting the paper mode S

<1D>H<70>H<n>

64 GS r Sending status S.P.

<1D>H<72>H<n>

65 GS v0

<1D>H<76>H<30>H

Printing of raster bit image S

<yL><yH>[<d>]k

66 GS w Specifying the horizontal size S.P.

<1D>H<77>H<n>

(magnification) of bar code

No.

Command

Function Mode Code Page

Command relative to NV memory

<1C>H<67>H<33>

<m>H<a1>H<a2>H

67 FS g3

Writing data into the download user NV memory

<a3>H<a4>H<nL>H

<nH>H[<d>]nL+

(nH×256)

<1C>H<67>H<34>H

68 FS g4

Reading data from the download user NV memory

S.P.

<m>H<a1>H<a2>H

<a3>H<a4>H<nL>H

<nH>H

69 FS p Printing the download NV bit images S

<1C>H<70>H<n>

<m>

70 FS q Defining the download NV bit image S

<1C>H<71>H<n>H

101

No.

Command

Function Mode Code Page

— 4 —

<1D>H<43>H

<32>H<n1><n2>

75 GS C1 S.P.

<1D>H<43>H

Setting the numbering counter mode (A) <31>H<n1><n2>

107

76 GS C2 Setting the numbering counter S.P. 108

77 GS C; Setting the numbering counter mode (B) S.P.

109

78 GS c Print the counter S.P.

<1D>H<63>H 110

79 GS I Setting the label length S.P.

<1d>H<6C>H

110

<1D>H<43>H<3B>

H<N1><3B>H<N2>

<3B>H<N3><3B>

H<N4><3B>H

<N5><3B>H

In the Mode column: S = STANDARD MODE, P = PAGE MODE

*shows the command affected by GS P.

Label Control

71 GS FF Printing and discharging the labels S <1D>H<0C>H 104

72 GS < Initialiging the printer mechanism S.P.

<1D>H<3C>H

105

73 GS A Correcting the label top position S.P.

<1D>H<41>H<m><n>

105

74 GS C0 Setting the numbering print mode S.P.

<1D>H<43>H

<30>H<m><n> 106

No.

Command

Function Mode Code Page

Commands Nos. 71, 72, 73, and 79 are available only if the "Label" (Black mark) feature

is specified.

— 5 —

1.2 Command Details

1.2.1 Descriptions of Each Item

XXXX

[Function] The name of a command.

[Code] The string of codes comprising the command is represented

by < >H for hexadecimal numbers, < >B for binary numbers,

and < > for decimal numbers, [ ] k denotes the number of

repetition of “k” times.

[Range] Indicates the values (setting range) of argumeuts of the

command.

Note: If values outside the defined domain specified with

control codes are used, malfunctions could possibly

occur, so be sure to use the values within the defined

domain.

[Outline] Describes the functions of the command.

[Caution] Describes important points and cautionary notes, as required.

[Default] Initial values for the command if it has arguments.

[Reference] Describes commands related to the command when it is used.

[Sample Program] Describes examples of coding on Quick-Basic.

Examples are only for reference. They may vary depending

on language and version. For details, please refer to a manual

in your language.

[Printing Result] Describes the print results obtained by executing the above

programs. However, the print results shown are different in scale

from actual print results.

— 6 —

1.2.2 Command Details

[Function] Horizontal tab

[Code] <09>H

[Outline] Shifts the printing position to the next horizontal tab position.

• Ignored when the next horizontal tab position has not been

set.

[Caution] • The horizontal tab position is set by ESC D.

• The initial setting of horizontal tab positions is at intervals of

8 characters for font A at 9th, 17th, 25th, 33rd, columns.

[See Also] ESC D

[Sample Program]

[Printing Result] 12345678901234567890

AAA BBB ← Initially set horizontal tab

AAA BBB CCC ← When set to the 4th, 8th, and 15th columns

LPRINT “0123456789012345678901”;

LPRINT CHR$(&HA);

LPRINT CHR$(&H9) + “AAA”;

LPRINT CHR$(&H9) + “BBB”;

LPRINT CHR$(&HA) ;

LPRINT CHR$(&H1B) + “D”;

LPRINT CHR$(3) + CHR$(7) + CHR$(14) + CHR$(0);

LPRINT CHR$(&H9) + “AAA”;

LPRINT CHR$(&H9) + “BBB”;

LPRINT CHR$(&H9) + “CCC” + CHR$(&HA) ;

END

— 7 —

[Function] Printing and paper feed

[Code] <0A>H

[Outline] Prints data inside the print buffer and feeds paper based on the

line feed amount having been set.

[Caution] The head of the line becomes the next print starting position.

[See Also] ESC 2, ESC 3

[Sample Program]

[Print Results] AAA ← Print and line feed

BBB ← Print and line feed

← Line feed only

CCC ← Print and line feed

LPRINT “AAA” + CHR$(&HA) ;

LPRINT “BBB” + CHR$(&HA) ;

LPRINT CHR$(&HA) ;

LPRINT “CCC” + CHR$(&HA) ;

END

— 8 —

[Function] Back to printing

[Code] <0D>H

[Outline] 1) When DSW1-5 is OFF:

This command is ignored.

2) When DSW1-5 is ON:

With data held inside the internal print buffer, printing and

line feed are performed.

Without data inside the internal print buffer, however, only

line feed is performed.

[See Also] LF

[Sample Program]

[Print Results] AAA ← Print and line feed

BBB ← Print and line feed

← Line feed only

CCC ← Print and line feed

LPRINT “AAA” + CHR$(&HD) ;

LPRINT “BBB” + CHR$(&HD) ;

LPRINT CHR$(&HD) ;

LPRINT “CCC” + CHR$(&HD) ;

END

Tabla de contenidos

Otros manuales de Impresora de Citizen

Citizen

Citizen CT-S281 Series Manual de usuario

Citizen

Citizen iDP-3540/3541 Manual de usuario

Citizen

Citizen CD-S500 series Manual de instalación

Citizen

Citizen CT-S601 Manual de usuario

Citizen

Citizen CT-S651 Series Manual de usuario

Citizen

Citizen CTS801IIN3NEBPXX Manual de usuario

Citizen

Citizen Z-START CLP-521Z Manual de usuario

Citizen

Citizen CL-S521 Manual de usuario

Citizen

Citizen CBM-262 Type II Manual de usuario

Citizen

Citizen CT-S310 Manual de usuario

Citizen

Citizen CMP-40L Manual de usuario

Citizen

Citizen CMP-20 Manual de usuario

Citizen

Citizen 120D+ Manual de usuario

Citizen

Citizen CT-S851 Manual de usuario

Citizen

Citizen CTE351XEEBX Manual de usuario

Citizen

Citizen CLP-7001 Manual de usuario

Citizen

Citizen CT-E301TR Manual de usuario

Citizen

Citizen CBM-230 Manual de usuario

Citizen

Citizen CMP-10 Manual de usuario

Citizen

Citizen iDP-460 Manual de usuario

Citizen

Citizen CLP-6001 Manual de usuario

Citizen

Citizen CLP 8301 CLP-8301 CLP-8301 Manual de usuario

Citizen

Citizen CX-77WN/BN Manual de usuario

Citizen

Citizen LINE THERMAL PRINTER CT-S280 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario
