Cisco CP-8865 Manual de usuario

CP-8865

Do Not Ship Enclosure with Phone Installed

[PHONE MUST BE INSTALLED ON-SITE]

- Due to the size and mass of this product, it is

Take into consideration before you install:

important that the Backbox is safely installed

according to these installation instructions.

- Make sure that the type of wall is capable of supporting

the system and use screws that are suitable for that type of wall.

accordance with state and local building regulations.

CP-8865 Mounting the Enclosure

Accessory Kits

Drilled Spanner

Coverplate

Mounting

Screw

#6-32 x 3/16”

Button Head Torx

(Spare)

Machine Screw

T-15 Pin Torx

Security Driver Bit

#8 Hex Nut

(Ground Lug)

Jumper Shunt

#6-32 x 5/8” Flat Head

Pin Torx Machine Screw

(Spare - 2 Pieces)

Machine Screw

Torx Security Bit &

#00 Screw Driver Kit

Keypad Cover Accessory Kit

Keypad

Driver Bit

Spare Screw Kit

+ 1 Spare

M3x0.5Pitch Machine Screw

Phone Mounting Screw Kit

Hookswitch Coverplate

T-15 Driver Bit Kit (on the Outside by the Hookswitch)

3/16”

Hex L-Key

Tools Required:

1) Electric Powered Hand Drill

2) Drill Bit (Use Correct Drill Bit for Wood / Concrete)

Mount the Backbox Assembly

to the Wall

A) Prepare Hole on Drywall (with Stud Behind) / Concrete

B) Insert Stud Anchors in to Holes

C) Align then Place Backbox Assembly Mounting Holes to Studs Anchors

Steps

Figure Shown Typical Installation:

3) Leveler

4) Torque Wrench, Wrench and Socket

D) Tighten Washers and Nuts that included with Stud Anchors

E) Torque to Stud Anchors Manufacturer's Recommended ft./lbs.

Remove Both

USB & KEM

Covers

Then Connect Power Plug (1) &

Network Cable (2), etc. Through

Mounting Bracket

Remove Handset &

Disconnect Cord from Phone.

(2)

(1)

(3)

This Will Allow Camera to Line Up with

Camera Hole on the Faceplate

Screw

Mounting

Phone

Mount

Cable

Exit

Cables Run Through Cable Exit then

Connect to Phone

Mounting

Holes

the USB Port on the Side

Right Angle USB-A to

Then Tightening Screws

Lower Phone Mount Until Tabs Stops

Tab

the USB to Analog Audio Module (UAAM)

USB-B to

Screw

Mounting

from Serial

Controller

Network Cable

AUX

Update Note: 1) Serial Controller RJ11 to AUX

Date: 02/07/2019

Red Wire to J4 (Position 1)

Green Wire to J4 (Position 3)

Black Wire to J4 (Position 4)

Yellow Wire to J4 (Position 2)

Armored Cord Handset to

USB to Analog Audio Module

1) #00 size Phillips Screw Driver

Tool Provided for Terminal Block Screw:

Armored Cord Handset Wires End

RED Wire

YELLOW Wire

GREEN Wire

BLACK Wire

Handset

Serial Controller Connections (6,7 & 8)

To Phone

Install Shunt on JP2

to Enable [Auto Answer Mode]

USB-A

USB-B to

RED Wire

BLACK Wire

921285C

GREEN Wire

RED Wire

BLACK Wire

Hookswitch Connections

Connections

Ground Lug

Hex Nut

Not Provided

Assembly

Ground the Backbox from ESD

Ground Wire &

UAAM Not Shown

*Handset Wires to

Network Cable are

Network Cable

Serial

Controller

Backbox

UAAM

Open Camera Shutter

Before Installing the Faceplate Assembly

<< Factory Disconnected >>

Reconnect Before Installing the Faceplates Assemblies

*First Install the Upper Faceplate Assembly

then the Lower Faceplate Assembly

Use Provided Driver Bit

to Install Security Screws

Tool Required:

Powered Screw Driver or Powered Hand Drill

Also Double Check all Cables and Wires are Plugged in and Secure

Connection Label

with Diagram

UAAM

Ground Wires Twist

Nut

Ground Faceplate from ESD

Lip Go Under

Diagram Shown Typical Installation

Upper Faceplate Assembly
