Cisco Catalyst 2960 Series Manual de usuario

Cisco Catalyst

2960 Series

Switches

Feature Matrix

Cisco Catalyst 2960 Series Switches

Offers Fast Ethernet in 8, 24- and 48-port

configurations for small branch offices and

wiring closets

Offers standard Layer 2 services with entry-

level availability, security, and QoS

Scalable and secure network management

Offers simplified management and

troubleshooting for lower total cost of

ownership

Offers CiscoWorks LMS, Cisco Network

Assistant and Cisco Smartports

Provides limited lifetime hardware warranty and

software updates at no additional charge

Provides Fast Ethernet, Gigabit Ethernet, and

Power over Ethernet for entry-level enterprise and

mid-market customers

Offers enhanced Layer 2+ intelligent LAN services:

Availability

Enhanced security

Advanced quality of service (QoS)

Offers simplified management and troubleshooting

for lower total cost of ownership

Offers CiscoWorks LMS, Cisco Network Assistant

and Cisco Smartports

Provides limited lifetime hardware warranty and

software updates at no additional charge

Cisco® Catalyst® 2960 LAN Base Series Catalyst 2960 LAN Lite Series

Uses Cisco ASICs for superior quality and hardware and software integration

Cisco Catalyst 2960 LAN Base Series —

Model Overview

24 10/100 ports

2 10/100/1000 uplink ports

Cisco Catalyst 2960-24TT-L

24 10/100 ports

2 dual-purpose uplink ports

Cisco Catalyst 2960-24TC-L

20 10/100/1000 ports

4 dual-purpose uplink ports

Cisco Catalyst 2960G-24TC-L

24 10/100 PoE ports

2 dual-purpose uplink ports

Cisco® Catalyst® 2960-24PC-L

48 10/100 ports

2 10/100/1000 uplink ports

Cisco Catalyst 2960-48TT-L

Cisco Catalyst 2960-48TC-L

48 10/100 ports

2 dual-purpose uplink ports

Cisco Catalyst 2960G-48TC-L

44 10/100/1000 ports

4 dual-purpose uplink ports

Cisco Catalyst 2960-24LT-L

24 10/100 ports (8 PoE ports)

2 10/100/1000 uplink ports

Enterprise-class intelligent

services: Advanced QoS,

enhanced security, high availability

8 10/100 ports

1 dual-purpose uplink port

Compact form-factor with no fan

Cisco Catalyst 2960-8TC-L

7 10/100/1000 ports

1 dual-purpose uplink port

Compact form-factor with no fan

Cisco Catalyst 2960G-8TC-L

Software

LAN Base Image

8 10/100/1000 ports

1 10/100/1000 PoE Input port

Compact form-factor with no fan

Cisco Catalyst 2960PD-8TT-L

Cisco Catalyst 2960 LAN Lite Series —

Model Overview

Note: Cisco Catalyst 2960 Switches Cannot Be Upgraded or Downgraded Between LAN Base and LAN Lite Software.

Software

LAN Lite Image

Cisco Catalyst 2960-48TC-S

48 10/100 ports

2 dual-purpose uplink ports

Entry level QoS, security, and

availability with a focus on ease-of-

use and lower total cost of ownership

Cisco Catalyst 2960-48TT-S

48 10/100 ports

2 10/100/1000 uplink ports

24 10/100 ports

Cisco Catalyst 2960-24-S

24 10/100 ports

2 dual-purpose uplink ports

Cisco® Catalyst® 2960-24TC-S

8 10/100 ports

1 dual-purpose uplink port

Compact form-factor with no fan

Cisco Catalyst 2960-8TC-S

Sep.

‘08

Sep.

‘08

Sep.

‘08

Sep.

‘08

Availability

For more detailed information please read the Cisco Catalyst 2960 LAN Base and

Cisco Catalyst 2960 LAN Lite Data Sheets

Cisco® Catalyst® 2960

LAN Lite Cisco Catalyst2960

LAN Base

Flash memory or DRAM 32 / 128 MB 32 / 128 MB

RPS Support No Yes

Jumbo Frames Yes Yes

VLANs 64 255

Voice VLAN Yes Yes

VTPv2 Yes Yes

Cisco Discovery Protocol v2 Yes Yes

LLDP Yes Yes (+MED)

802.3ad LACP Yes Yes

Scanning Tree protocol Instances 64 128

802.1w / 802.1s Yes Yes

PVST / PVRST+ Yes Yes

Port Fast / Uplink Fast Yes Yes

Flex Link No Yes

Link State Tracking No Yes

Quality of Service

Cisco® Catalyst® 2960

LAN Lite Cisco Catalyst 2960

LAN Base

Port CoS Trust and Override Yes Yes

Trusted Boundary No Yes

ACL Classification No Yes

Ingress Policing (1MB incr.) No Yes

Auto QoS No Yes

802.1p queues 4 4

Scheduling SRR SRR

Priority Queuing Yes Yes

Configure CoS Priority Queues Yes Yes

Configure Queue Weights No Yes

Configure Buffers and Thresholds No Yes

Class & Policy Maps No Yes

Modify CoS and DSCP Mapping No Yes

DSCP Transparency Yes Yes

Weighted Tail Drop Yes Yes

Security

Cisco® Catalyst® 2960

LAN Lite Cisco Catalyst 2960

LAN Base

SSH, SSL , and SCP Yes Yes

RADIUS and TACACS+ Yes Yes

SNMPv3 crypto Yes Yes

802.1x Yes Yes

802.1x Accounting / MIB Yes Yes

802.1x w/ Port Security Yes Yes

802.1x w/ Voice VLAN Yes Yes

802.1x Guest VLAN Yes Yes

802.1x VLAN assignment Yes Yes

802.1x Auth-Fail VLAN No Yes

802.1x AAA Fail Open No Yes

802.1x WOL No Yes

802.1x MAC-Auth Bypass Yes Yes

802.1x Web-Auth No Yes

802.1x Multi-Domain Auth No No

802.1x w/ download ACLs No No

Security, Multicast, IPv6

Cisco® Catalyst® 2960

LAN Lite Cisco Catalyst 2960

LAN Base

Layer 2-4 ACLs (Port, Time,

and DSCP-based) No Yes

BPDU / Root Guard Yes (voice aware) Yes (voice aware)

Port Security Yes (voice aware) Yes (voice aware)

DHCP Snooping No Yes

Dynamic ARP Inspection No No

IP Source Guard No No

DHCP Option 82 No Yes

DHCP Server No Yes

Private VLAN Edge Yes Yes

Storm Control Yes Yes

Block unknown unicast and

multicast Yes Yes

IPv6 Host No Yes

IPv6 MLD Snooping No Yes

MVR No Yes

IGMP Snooping Yes Yes

IGMP Filter / Throttle Yes Yes

Management and Troubleshooting

Cisco® Catalyst® 2960

LAN Lite Cisco Catalyst 2960

LAN Base

Auto-MDIX Yes Yes

TDR Yes Yes

UDLD Yes Yes

IP SLA Responder No Yes

Layer 2 / IP Traceroute Yes Yes

SPAN (# of sessions) Yes (1) Yes (2)

RSPAN No Yes

Express Setup Yes Yes

Device Manager Yes Yes

Cisco Network Assistant Yes Yes

Smartports + Advisor Yes Yes

Troubleshooting Advisor Yes Yes

Drag-and-drop Cisco IOS® Upgrade Yes Yes

IP Address DHCP Yes Yes

Autoinstall with saved configuration Yes (future) Yes (future)

Configuration Replace Yes (future) Yes (future)

DHCP Auto Image Upgrade Yes (future) Yes (future)

DHCP Port Based Allocation Yes Yes

Error Disable MIB Yes Yes
