Cisco Explorer 4640HDC and 4650HDC High-

Definition Set-Tops with Multi-Stream CableCARD

Interface

Power, flexibility, and advanced security features highlight the Cisco®Explorer®

4640HDC and 4650HDC High-Definition Set-Tops with Multi-Stream CableCARD™

(M-Card™) Interface.

The 4640HDC and 4650HDC set-tops support the tru2way™(formerly OCAP™) and Federal Communications

Commission (FCC) mandates for separable security. The set-tops also offer MPEG-4 (H.264) high definition (HD)

and standard definition (SD) decoding with HD and SD outputs and DOCSIS®2.0 data capability. The 4650HDC

set-top also provides analog tuning.

Figure 1. Cisco Explorer 4650HDC Front Panel (Image May Vary from Actual Product and Specification)

Features

Network Utilization Enhancements

●1 GHz Tuning enables cable operators to expand network bandwidth to provide additional services such

as VOD, tru2way, DOCSIS 2.0, and high-speed data

●MPEG-4 (H.264) Decoding supports compression technology that provides better video quality at

approximately half the data rate of MPEG-2

●DOCSIS 2.0 provides greatly increased upstream throughput for future advanced services and provides a

path for future IP video services (optional software)

OpenCable™and Conventional Network Support

●M-Card Interface uses a Multi-Stream CableCARD (M-Card) for separable security

●Axiom™Middleware supports tru2way applications such as Service Navigators, Games, and other future

tru2way applications (optional software)

●DSG (DOCSIS Set-top Gateway) provides a powerful standard transport mechanism for command and

control signaling between the set-top and service provider network (optional software)

●DAVIC Receiver/Transmitter allows IP-based, real-time, two-way communication between the set-top and

the service provider network for on-demand services (optional software)

Home Networking Features

●USB 2.0 Connection enables a host connection to peripheral devices such as navigation controllers,

network adapters, and memory media readers

●Ethernet Connection enables a connection to the home IP LAN for advanced services such as content

sharing to the set-top from retail-purchased electronic devices

Figure 2. Cisco Explorer 4650HDC Front Panel (Image May Vary from Actual Product and Specification)

Table 1. Front Panel

Feature Description

Controls Vol+, Vol-, Ch+ Ch-, Select, Guide, Info, Exit, Settings, IR receiver, Power

Connections USB 2.0 host, software-controlled

Indicators Four-segment LED digits, Power icon, Message icon, HDTV, 5.1, Auto, 1080i/p, 720i/p, 480i/p

Color Black, grey text

Branding Cisco, model number, provision for customer brand

Figure 3. Cisco Explorer 4650HDC Back Panel (Image May Vary from Actual Product and Specification)

Table 2. Back Panel

Feature Description

Connections In Cable In, Power

Connections-Interactive USB 2.0 Host, RJ-45 Ethernet, software controlled

Connections Out HDMI™(1.3) with CEC, IEEE 1394 (4-pin), Dual L/R Audio, Baseband Video, YPbPr, IR,

S-Video Out, Optical Digital Audio, Coaxial Digital Audio Out, RF Out, Switched Outlet, see Note 1

Output Resolutions 720 x 480i 60 Hz, 1920 x 1080i 60 Hz, 1920 x 1080p 30 Hz, 1920 x 1080p 24 Hz,

1280 x 720p 60 Hz, 720 x 480p 60 Hz, 720 x 480i 60 Hz, software controlled, see Note 1

Output Control Scaled video in graphics, scaled HD video in graphics, graphics on HD and SD outputs, aspect ratio control,

native resolution pass-thru, HD down convertible to SD, software controlled

Power Input Polarized 2-prong modular cord plug, 115 VAC, 60 Hz

Power Output Polarized 2-prong outlet, at input line voltage, software controlled

Labels Serial Number, eCM MAC Address, RF MAC Address, M-Card Serial Number, M-Card MAC Address

Product Specifications

Table 3. Product Specifications

Specification Value

Tuning and Decoding

Tuning Analog (4650HDC), QAM 64 or 256, In-Band 54 MHz-1 GHz,

QPSK out-of-band (OOB) 70-130 MHz, DOCSIS 91-867 MHz, A/V in display

Video Decoders MPEG-2 MP@ML, MP@HL (SD, 720 x 480i), MPEG-4 (H.264) up to [email protected] (HD), VC1, Video Scaling,

software controlled

Audio Decoders Dolby™Digital to 5.1, MPEG-1 and MPEG-2, Dolby Digital+, AAC, AAC+, AC3, MP3

Conditional Access Separable security with M-Card

Graphics Engine Up to 960 x 540 resolution, 32 bit (16 million) color

DAVIC FDC (Forward Data Channel) 1.54 Mbps QPSK, RDC (Reverse Data Channel) 1.54 Mbps QPSK, FAT QAM

Channel Downstream, software controlled

DOCSIS OOB and interaction via DOCSIS 2.0, DOCSIS Set-top Gateway, Baseline Privacy Interface, software controlled

Memory/Storage

RAM Minimum of 128 MB, see Note 2

Flash Minimum of 32 MB

NVM Minimum of 16 KB

Processors

Application/CPU 700 MHz (approximately 1000 dMIPs)

DOCSIS 333 MHz CPU

Network 400 MHz CPU

Dimensions

Product (HxWxD) 2.75 in. x 13.75 in. x 9 in. (7.0 cm x 34.9 cm x 22.9 cm)

Product Weight 4.5 lbs (2.04 kg)

Carton (HxWxD) Carton of 5 units = 16.5 in. x 11.0 in. x 16.5 in. (41.9 cm x 27.9 cm x 41.9 cm)

Total Weight Carton of 5 units = 25.25 lbs (11.45 kg)

Environment Specifications

Placement Locate with at least 2 inches of open space above and on each side

Room Temperature 32º to 105ºF (0º to 40ºC) during operation

Storage Temperature 14º to 158ºF (-10º to 70ºC)

Power Dissipation 50W maximum peak, ENERGY STAR Tier 1

Table 4. Accessories

Specification Value

In Carton

HDMI Cable, Power Cord, Quick Reference Guide

Sold Separately Part Number

License, Axiom OCAP (tru2way) Middleware, non-DVR, see Note 2 4026954

SARA Software License, 1 year term 4020466

SARA Software License, 2 year term 4020467

MultiStream CableCARD PKM802 4014733 is EOL

MultiStream CableCARD PKM803 (Multiples of 200) 4033273

AllTouch® AT8650 Remote Control 4016237

Specification Value

RGB Adapter and Cables 749790 is EOL

IR Extender - 12 ft (3.65 m) 1004648

USB IR Extender - 12 ft (3.65 m) 1001807 is EOL

USB IR Extender - 25 ft (7.32 m) 4006725 is EOL

HDMI-to-HDMI Cable (additional or replacement) 1002048

Ordering Information

Table 5. Ordering Information

Model Description Part Number

Set-Top with PowerKEY

M-Card Module

Cisco Explorer 4640HDC Cisco Explorer 4640HDC High-Definition Interactive Set-Top (with 256 MB) 4028057

Cisco Explorer 4640HDC Cisco Explorer 4640HDC High-Definition Interactive Set-Top (with 512 MB) 4033997

Cisco Explorer 4650HDC Cisco Explorer 4650HDC High-Definition Interactive Set-Top (with 256 MB) 4024132

Cisco Explorer 4650HDC Cisco Explorer 4650HDC High-Definition Interactive Set-Top (with 512 MB) 4034702

Notes:

1. 1080p/24 or 1080p/30 output formats are available on HDMI, if those formats are presented to the set-top box

at its input. Incoming video formats will not be converted to either of these for output. Output of these formats

is under software control.

2. Axiom Middleware for tru2way (formerly OCAP) support is recommended only for the 4600 models that have

a minimum of 256 MB RAM.

AVC Video License

With respect to each AVC/H.264 product, we are obligated to provide the following notice:

THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND

NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC

STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER

ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO

PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR

ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE

http://www.mpegla.com.

Accordingly, please be advised that service providers, content providers, and broadcasters are required to obtain

a separate use license from MPEG LA prior to any use of AVC/H.264 encoders and/or decoders.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered

trademarks of HDMI Licensing LLC in the United States and other countries.

Printed in USA C78-728769-00 06/13
