Quick Start Guide for Cisco 910 Industrial Routers

Quick Start Guide for Cisco 910 Industrial

Routers

78-21635-01C0

Overview, page 2

Accessories, page 3

Ports, page 4

LED Definition, page 5

Installation of the Device, page 9

Powering On and Logging In to the System, page 19

Resetting to Factory Mode, page 20

FCC Class A Notices and Warnings, page 20

RF Exposure Safety Notice, page 20

Declaration of Conformity with Regard to the EU Directive 1999/5/EC (R&TTE Directive), page 21

Regulatory Standards Compliance, page 23

For More Information, page 24

This guide describes how to quickly install the Cisco 910 Industrial Router.

For configuration information, see the Cisco 910 Industrial Router documentation on Cisco.com. For system

requirements, important notes, limitations, open and resolved bugs, and documentation updates, see the release notes

on Cisco.com.

Before installing, configuring, or upgrading the Cisco 910 Industrial Router, refer to the Release Notes for the latest

information.

Note: If you are using the 3G models of Cisco 910 Industrial Routers, the Mobile Equipment Identifier (MEID), International

Mobile Equipment Identity (IMEI), and Electronic Serial Number (ESN) are necessary for you to set up the 3G interface to

be used for your service provider carriers. You can use the show cellular unit all command to display MEID, IMEI, and

ESN information. For more information, see the “Monitoring Cellular 3G Information” section in Chapter 20, Configuring

Cellular 3G Setting, of the Cisco 910 Industrial Router Software Configuration Guide.

Quick Start Guide for Cisco 910 Industrial Routers

Overview

The Cisco 910 Industrial Router is available in following models: IR910-K9, IR910G-K9/IR910G-NA-K9, and IR910W-K9

(Figure 1). IR910-K9 supports only the Ethernet combo uplink, IR910W-K9 supports both Wi-Fi and Ethernet combo

uplink. and IR910G-K9/IR910G-NA-K9 supports both 3G (CDMA-EVDO or HSPA selective) and Ethernet combo uplink.

Figure 1 Cisco 910 Industrial Router Models

No. Model No. Description

1IR910-K9 Cisco 910 Industrial Router (Ethernet only)

2IR910G-K9

IR910G-NA-K9

Cisco 910 Industrial Router (3G and Ethernet)

3IR910W-K9 Cisco 910 Industrial Router (Wi-Fi and Ethernet)

1 2 3

390960

Quick Start Guide for Cisco 910 Industrial Routers

Accessories

This section describes the basic model accessory kit contents of the Cisco 910 Industrial Router package, and

configurable items, spares, and options.

Package Contents

Figure 2 shows the accessories of the three basic models of the Cisco 910 Industrial Router:

Figure 2 Accessories of Basic Models

No. Accessory Kit Contents Contained in Model No.

1Chassis IR910-K9,

IR910G-K9/IR910G-NA-K9,

and IR910W-K9

2DIN mounting kit, preinstalled at the rear of the device

3DC power connectors jack x 2

43G antenna IR910G-K9/IR910G-NA-K9

5Wi-Fi antenna IR910W-K9

63G or Wi-Fi antenna wire clip IR910G-K9/IR910G-NA-K9 and IR910W-K9

390961

Quick Start Guide for Cisco 910 Industrial Routers

Ports

Configurable Items, Spares, and Options

Table 1 shows the configurable items, spares, and options of the Cisco 910 Industrial Router:

Note: All the configurable items, spares, and options should be purchased individually, and are not included by default

with the Cisco 910 Industrial Router. Verify that you have received the items you have purchased. If any item is missing

or damaged, contact your Cisco representative or reseller.

Ports

Table 2 shows the ports of the Cisco 910 Industrial Router models.

Table 1 Configurable Items, Spares, and Options

Configurable Items Model No. Description

ACC-IR910-S16 External storage, SSD media, 16-GB capacity.

ACC-IR910-H-M= IP55 enclosure and wall and pole mount kit.

ACC-IR910-W-M= Mount bracket to fix sensor module into chassis.

ACC-IR910-LORA-868 868 MHz LoRa card and antenna.

ACC-IR910-LORA-433 433 MHz LoRa card and antenna.

Table 2 Cisco 910 Industrial Router Ports

Model No. Port

IR910-K9 1 GE combo (1 RJ-45 + 1 SFP) uplink

1 Open slot for sensor module

1 USB 2.0

2 RS232/RS485 (RJ-45) serial ports

1 Console (RJ-45)

IR910W-K9 1 GE combo (1 RJ-45 + 1 SFP) uplink

1 Open slot for sensor module

1 USB 2.0

2 RS232/RS485 (RJ-45) serial ports

1 Console (RJ-45)

Wi-Fi, 2.4GHz, 802.11 b/g/n

IR910G-K9

IR910G-NA-K9

1 GE combo (1 RJ-45 + 1 SFP) uplink

1 Open slot for sensor module

1 USB 2.0

2 RS232/RS485 (RJ-45) serial ports

1 Console (RJ-45)

3G (CDMA-EVDO/HSPA selective)

Quick Start Guide for Cisco 910 Industrial Routers

LED Definition

Figure 3, Figure 4, and Figure 5 show the positions of LEDs on the panel of each model. For detailed LED definitions, see

Table 3.

Figure 3 LEDs of IR910-K9

348

391243

Quick Start Guide for Cisco 910 Industrial Routers

LED Definition

Figure 4 LEDs of IR910W-K9

348

391245

Quick Start Guide for Cisco 910 Industrial Routers

LED Definition

Figure 5 LEDs of IR910G-K9/IR910G-NA-K9

348

391244

Quick Start Guide for Cisco 910 Industrial Routers

LED Definition

Table 3 shows the color and meaning of each LED.

Table 3 LED Definition

No. LED Single/Dual

Color

Color Meaning

1SYS Dual Off System is not powered on or CPU has not

completed boot up.

Blinking green System is in the Power-on self-test (POST)

stage, or system is getting IP address

(IR910G-K9 only).

Solid green System is operating normally, and IP address is

attached (IR910G-K9 only).

Solid red System is not functioning properly.

2VPN Dual Off VPN is not set up.

Blinking green VPN setup is in progress.

Solid green VPN is operating normally.

Solid red VPN is not functioning properly.

3COM1 Dual Off COM port is enabled and is configured as

RS232 port.

Solid green COM port is enabled and is configured as

RS485 port.

Solid red Not defined.

4COM2 Dual Off COM port is enabled and is configured as

RS232 port.

Solid green COM port is enabled and is configured as

RS485 port.

Solid red Not defined.

5Wi-Fi Single Off No activity.

Solid green The connection between the gateway and base

station has been established.

Blinking green Wi-Fi is transmitting data.

63G Single Off No activity.

Solid green Module is active (SIM card inserted).

7Open slot status Single Off No link.

Solid green Port link.

Blinking green Transmitting or receiving data.

8GE-RJ-45 Single Off No link.

Solid green Port link, no activity.

Blinking green Link is normal with activity.

9GE-SFP Single Off No link.

Solid green Port link, no activity.

Blinking green Link is normal with activity.

Quick Start Guide for Cisco 910 Industrial Routers

Installation of the Device

You can install the device to a standard DIN rail, or on a wall or a pole by using the IP55 enclosure and wall/pole mount

kit. For detailed installation procedure, see Mounting Kit Assembly Guide for Cisco 910 Industrial Router.

Before You Begin

Before installing a Cisco 910 Industrial Router, verify that these guidelines are met:

—Sufficient front clearance is available so that the LEDs can be seen.

—Cabling is away from sources of electrical noise, such as radios, power lines, and fluorescent lighting. Make sure

that the cables are safely away from other devices that might damage them.

—Airflow around the device is unrestricted.

—Temperature around the unit does not exceed 70°C.

—Humidity around the device does not exceed 85 percent.

—Altitude at the installation site is below 2000 m.

Warning Statements

Warning: IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any

equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for

preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the

10 DC-A Dual Off Power is not present on the circuit, or the

system is not powered up.

Solid green Power is present on the associated circuit and

the router is already booted up.

Solid red Power is not present on the associated circuit

and the router is configured for dual-input

power.

11 DC-B Dual Off Power is not present on the circuit, or the

system is not powered up.

Solid green Power is present on the associated circuit and

the router is already booted up.

Solid red Power is not present on the associated circuit

and the router is configured for dual-input

power.

12 SSD Single Off No power is provided to SSD.

Solid green Power is provided to SSD.

Blinking green SSD is being accessed.

Table 3 LED Definition (continued)

No. LED Single/Dual

Color

Color Meaning

Quick Start Guide for Cisco 910 Industrial Routers

Installation of the Device

translated safety warnings that accompanied this device. Statement 1071

SAVE THESE INSTRUCTIONS

Warning: In order to comply with FCC radio frequency (RF) exposure limits, antennas should be located at a

minimum of 7.9 inches (20 cm) or more from the body of all persons. Statement 332

Warning: This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the

protective device is rated not greater than: 20A. Statement 1005

Warning: The plug-socket combination must be accessible at all times, because it serves as the main disconnecting

device. Statement 1019

Warning: This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the

absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an

electrician if you are uncertain that suitable grounding is available. Statement 1024

Warning: Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Statement 1030

Warning: Ultimate disposal of this product should be handled according to all national laws and regulations.

Statement 1040

Warning: For connections outside the building where the equipment is installed, the following ports must be

connected through an approved network termination unit with integral circuit protection:

10/100/1000 Ethernet. Statement 1044

Warning: To prevent the system from overheating, do not operate it in an area that exceeds the maximum

recommended ambient temperature of: Statement 1047

140°F (60°C) (with SSD)

140°F (60°C) (without SSD card and in a sealed enclosure)

158°F (70°C) (without SSD card and in a vented enclosure)

Warning: Installation of the equipment must comply with local and national electrical codes. Statement 1074

Warning: To prevent airflow restriction, allow clearance around the ventilation openings to be at least:

3 inches (7.6 cm). Statement 1076

Warning: Hot surface. Statement 1079

Caution: This industrial router can only be accessed by service personnel or by users who have been instructed

about the reasons for the restrictions applied to the location. Access is through the use of a tool or lock and key, or

other means of security, and is controlled by the authority responsible for the location.

Caution: Be aware of the size and weight of the Cisco 910 Industrial Router when mounting. Ensure that the

mounting location has a stable flat surface and can safely support the weight of the device.

WARNING

HOT SURFACE

DO NOT TOUCH

390965

Otros manuales para 910

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de Cisco

Cisco

Cisco SOHO 97 Manual de usuario

Cisco

Cisco 2811 - Voice Security Bundle Router Manual de usuario

Cisco

Cisco 1905 Manual de instrucciones

Cisco

Cisco 7246VXR - uBR Router Manual de usuario

Cisco

Cisco Broadband Access Center Manual de usuario

Cisco

Cisco IPS-4240-K9 - Intrusion Protection Sys 4240 Manual de usuario

Cisco

Cisco uBR924 Hoja de instrucciones

Cisco

Cisco WS-SUP720-3B - Supervisor Engine 720 Manual de usuario

Cisco

Cisco 12000 - Series Chassis Modular Expansion... Guía de instalación

Cisco

Cisco Linksys RAN201 Manual de usuario

Cisco

Cisco 1805 Manual de usuario

Cisco

Cisco Linksys SFE2000 Manual de instrucciones

Cisco

Cisco 7600 Series Manual de usuario

Cisco

Cisco 500 Series Manual de usuario

Cisco

Cisco 1605-R Instrucciones de funcionamiento

Cisco

Cisco Small Business RV315W Manual de usuario

Cisco

Cisco 7507 Manual de usuario

Cisco

Cisco 2524 - Router - EN Manual de usuario

Cisco

Cisco Linksys EA2700 Manual de usuario

Cisco

Cisco DC Power Entry 10005 ESR Manual de usuario

Cisco

Cisco MGX 8230 Instrucciones de funcionamiento y mantenimiento

Cisco

Cisco XR 12000 Manual de instalación

Cisco

Cisco 12000 - Series Chassis Modular Expansion... Manual de usuario

Cisco

Cisco Cable Mgmt Bracket Cisco 7513/7576 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

EnGenius

EnGenius ESR-9710 Manual de usuario

LevelOne

LevelOne FBR-1416 Manual de usuario

Dynacord

Dynacord Promatrix 6000 Manual de usuario

Lorex

Lorex F5D8230-4 Manual de usuario
