VIP-FE-TX/4E Installation and Conﬁguration

Product Number VIP-FE-TX/4E(=)

This conﬁguration note is a standalone publication that provides instructions for installing,

conﬁguring, and maintaining the Fast Ethernet/Ethernet Versatile Interface Processor

(VIP-FE-TX/4E) in your Cisco 7000 series and Cisco 7500 series routers.

The VIP-FE-TX/4E operates with the CxBus in the Cisco 7000 series and CyBus in the Cisco 7500

series, and requires that the host Cisco 7000 series and Cisco 7500 series router is running Cisco

Internetwork Operating System (Cisco IOS) Release 11.1(1) or later, or a Cisco-approved beta

version of Cisco IOS Release 11.1 or later.

Note The entire VIP-FE-TX/4E assembly, with port adapters installed, is a ﬁeld-replaceable unit

(FRU). Individual port adapters are not available as spare parts.

Included are steps for VIP-FE-TX/4E hardware installation, and basic VIP conﬁguration steps and

examples for conﬁguring the individual interfaces on a new VIP.

This publication has two main sections:

•Versatile Interface Processor Functions, page 3—this section discusses general VIP features,

maintenance considerations, and overall functions

•VIP Port Adapter Functions, page 29—this section contains subsections that discuss each port

adapter and its speciﬁc features, conﬁguration and connection requirements, and functions

You need only refer to the information that is speciﬁc to your FE-TX and 4E port adapter or that

applies to speciﬁc VIP functionality. A table of contents is included on page 2 so you can more easily

ﬁnd what you need.

Note For complete descriptions of interface subcommands and the conﬁguration options available

for VIP-related interfaces, and which support VIP functionality, refer to the section “If You Need

More Information.”

DOC-782879=

78-2879-01

2VIP-FE-TX/4E Installation and Conﬁguration

Table of Contents

This conﬁguration note includes the following sections:

•If You Need More Information

•Versatile Interface Processor Functions, page 3

—What is the VIP?, page 3

Note The following section contains important information about the latest Cisco IOS release.

—VIP Software Prerequisites, page 5

—VIP Hardware Prerequisites, page 5

—What is the Cisco 7000 Family?, page 5

—VIP Port Adapter Hardware Conﬁguration Overview, page 10

—VIP Microcode Overview, page 11

—VIP Installation Prerequisites, page 11

—VIP Installation, page 16

—Checking the Installation and Verifying VIP Status, page 19

—Upgrading VIP Microcode, page 23

—Upgrading and Replacing DRAM SIMMs, page 26

•VIP Port Adapter Functions, page 29

—FE-TX Port Adapter, page 29

—4E Port Adapter, page 44

•SELV Circuit Warning Translations, page 57

•Cisco Information Online, page 58

If You Need More Information

The Cisco Internetwork Operating System (Cisco IOS) software running the router contains

extensive features and functionality. The effective use of many of many of these features is easier if

you have more information at hand.

To obtain general information about documentation, call Customer Service at 800 553-6387 or

408 526-7208. Customer Service hours are 5:00 a.m. to 6:00 p.m. Paciﬁc time, Monday through

Friday (excluding company holidays). You can also send e-mail to [email protected]. You can also

refer to the Cisco Information Packet that shipped with your router.

VIP-FE-TX/4E Installation and Configuration 3

Versatile Interface Processor Functions

For additional information on conﬁguring the Cisco 7000 series or Cisco 7500 series routers, the

following documentation resources are available to you:

•UniverCD

This publication and all other Cisco Systems publications are available on UniverCD, which is

Cisco’s online library of product information. UniverCD is updated and shipped monthly, so it

might be more up to date than printed documentation. To order UniverCD, contact a Cisco Sales

or Customer Service representative.

•For systems with Cisco IOS Release 11.1(1), a Cisco-approved 11.1 beta software version, or a

later Cisco IOS release, refer to the following modular conﬁguration and modular command

reference publications, as appropriate for your conﬁguration:

—Conﬁguration Fundamentals Conﬁguration Guide

—Conﬁguration Fundamentals Command Reference

—Wide-Area Networking Conﬁguration Guide

—Wide-Area Networking Command Reference

—Standard Network Protocols Conﬁguration Guide

—Standard Network Protocols Command Reference

—Network Protocols Conﬁguration Guide

—Network Protocols Command Reference

—Bridging and IBM Networking Conﬁguration Guide

—Bridging and IBM Networking Command Reference

—Conﬁguration Builder Getting Started Guide

—Troubleshooting Internetworking Systems

Versatile Interface Processor Functions

The following sections describe the Versatile Interface Processor (VIP) and discuss VIP-speciﬁc

features and functions, such as installing and removing the VIP, installing and removing port

adapters, and using and conﬁguring common VIP interface functions.

What is the VIP?The VIP is a new interface processor for use with the Cisco 7000 series and Cisco 7500 series

routers, and it installs in the interface processor slots in your Cisco 7000 series or 7500 series router.

The VIP uses a single motherboard with up to two port adapters. The VIP port adapters provide the

individual LAN, WAN, or LAN/WAN interface ports. The VIP can be removed from a chassis while

power is on and the system is operating.

Caution The VIP supports online insertion and removal (OIR), which allows you to remove and

replaceaVIPwithoutﬁrstshuttingdown the system. Online insertion and removalmaximizesrouter

availability by letting you add or remove VIPs during system operation; however, the system may

indicate a hardware failure if you fail to follow proper procedures. To help avoid problems with the

installation, review the functional description in the section “Online Insertion and Removal—An

Overview” on page 13, and follow the VIP installation steps carefully.

4VIP-FE-TX/4E Installation and Conﬁguration

Versatile Interface Processor Functions

Note The VIP port adapters themselves do not support OIR, nor are they FRUs.

The VIP uses a Reduced Instructions Set Computing (RISC), Mips 4600 processor for high

performance, and has an internal operating frequency of 100 megahertz (MHz) and a 50-MHz

system bus interface. The VIP has 8 megabytes (MB) of dynamic random access memory (DRAM)

as the default DRAM configuration.

Figure 1 shows a VIP-FE-TX/4E. The VIP ﬁrmware (microcode), which contains card-speciﬁc

software instructions, resides in a Flash memory device in socket location U17. For pinouts, refer to

the section “FE-TX Port Adapter Receptacles, Cables, and Pinouts” on page 33. Single in-line

memory modules contain the DRAM. You can install VIPs in any available interface processor slots

in your Cisco 7000 or Cisco 7500 series router.

Figure 1 VIP with One FE-TX and One 4E Port Adapter (Product Number VIP-FE-TX/4E[=])

Note In the Cisco 7000, Cisco 7507 and Cisco 7513 chassis, the VIP is installed vertically. In the

Cisco 7010 and Cisco 7505 chassis, the VIP is installed horizontally. Port adapters have a handle

attached, but this handle is not shown to allow a full view of detail on each port adapter’s faceplate.

H4711

DRAM

SIMMs

Microcode

Flash U17

Bus connector

ETHERNET-10BT

LINK

MII

LINK

RJ45

FAST ETHERNET

FE-TX in

port adapter

slot 0

4E in port

adapter

slot 1

Port adapter

handles not shown

VIP-FE-TX/4E Installation and Configuration 5

Versatile Interface Processor Functions

VIP Software Prerequisites

The VIP requires that the host Cisco 7000 series and Cisco 7500 series router is running Cisco

Internetwork Operating System (Cisco IOS) Release 11.1(1) or later, or a Cisco-approved beta

version of Cisco IOS Release 11.1 or later.

Note The latest Cisco IOS release is available via anonymous File Transfer Protocol (FTP) from

ftp/[email protected]. Detailed information about the latest Cisco IOS release can be

found in the ASCII ﬁle vip1-readme, which is also available via FTP from ftp.cisco.com in the

directory /ftp/beta111_dir. This ASCII ﬁle includes information and instructions on how to get

the current Cisco IOS software images and VIP microcode. To access information located in Cisco

Information Online (CIO), refer to the section “SELV Circuit Warning Translations” at the end of

this publication.

VIP Hardware Prerequisites

The VIP operates with the CxBus in the Cisco 7000 series and CyBus in the Cisco 7500 series, and

operates with the optional RSP7000 and RSP7000CI RSP-based processor modules in the

Cisco 7000 series routers: Cisco 7000 and Cisco 7010. The VIP will also operate with the Route

Processor (RP) and Switch Processor (SP) in the Cisco 7000 series routers. The VIP operates with

all RSP-based processor modules currently shipping in the Cisco 7000 series and Cisco 7500 series

routers: Cisco 7505, Cisco 7507, and Cisco 7513.

What is the Cisco 7000 Family?

For the Cisco 7000 family of routers, which includes the Cisco 7000 series and Cisco 7500 series

routers, network interfaces reside on modular interface processors, including the VIP, which provide

a direct connection between external networks and the high-speed CxBus in the Cisco 7000 series

and the high-speed CyBus in the Cisco 7500 series.

In all systems, the remaining slots support any combination of network interface types: Ethernet

attachment unit interface (AUI), Ethernet 10BASE-T, Fast Ethernet 100BASE-TX, Asynchronous

Transfer Mode (ATM), Token Ring, multichannel applications, Fiber Distributed Data Interface

(FDDI), channel attachment, serial, or High-Speed Serial Interface (HSSI), and all VIP–based

interfaces.

6VIP-FE-TX/4E Installation and Conﬁguration

Versatile Interface Processor Functions

Cisco 7000 Series Figure 2 and Figure 3 show the rear of the Cisco 7000 series routers: the seven-slot Cisco 7000 and

the ﬁve-slot Cisco 7010, respectively. In the Cisco 7000 series, two slots are reserved for the SP (or

SSP) and RP, or for the 7000 Series Route Switch Processor (RSP7000) and the 7000 Series Chassis

Interface (RSP7000CI). The remaining slots are for interface processors: slots 0 through 4 in the

Cisco 7000, and slots 0 through 2 in the Cisco 7010.

Figure 2 Cisco 7000, Interface Processor End

H5288

Interface processor slots 0 123 4 RSP

7000

slot 5

RSP

7000CI

slot 6

Upper

power supply

Lower

power supply

DC FAIL

AC POWER

DC FAIL

AC POWER

Captive

installation screw

Captive

installation screw

EJECT

SLOT 0

SLOT 1

NORMAL

CPU HALT

RESET

AUX.

CONSOLE

ROUTE SWITCH PROCESSOR

ENABLE

VIP-FE-TX/4E Installation and Configuration 7

Versatile Interface Processor Functions

Figure 3 Cisco 7010, Interface Processor End

Cisco 7500 Series Figure 4, Figure 5, and Figure 6 show the rear of the Cisco 7500 series routers: the ﬁve-slot

Cisco 7505, the seven-slot Cisco 7507, and the thirteen-slot Cisco 7513, respectively.

In the Cisco 7505, one slot (4) is reserved for the Route Switch Processor (RSP1), which contains

the system processor and performs packet switching functions. Slots 0 through 3 are for interface

processors.

Figure 4 Cisco 7505, Interface Processor End

H5874

RSP7000CI slot 4

RSP7000 slot 3

Interface processor slot 1

DC OK LED

Power switch

Chassis ground

screw

Power receptacle

Interface processor slot 2

Interface processor slot 0

AC-input power supply

EJECT

SLOT 0

SLOT 1

NORMAL

CPU HALT

RESET

AUX.

CONSOLE

ROUTE SWITCH PROCESSOR

ENABLE

H2761

RSP slot

DC OK LED

wer switch

Chassis

grounding

receptacles

Power receptacle AC-input power supply

EJECT

SLOT 0

SLOT 1

NORMAL

CPU HALT

RESET

AUX.

CONSOLE

ROUTE SWITCH PROCESSOR

ENABLE

Interface processor slot 1

Interface processor slot 2

Interface processor slot 0

Interface processor slot 3

8VIP-FE-TX/4E Installation and Conﬁguration

Versatile Interface Processor Functions

Figure 5 shows the rear of the seven-slot Cisco 7507 router. In the Cisco 7507, up to two slots (2 and

3) are reserved for the Route Switch Processor (RSP2), which contains the system processor and

performs packet switching functions. Slots 0 and 1 and 4 through 6 are for interface processors.

Figure 5 Cisco 7507, Interface Processor End

ENABLE

EJECT

SLOT 0

SLOT 1

NORMAL

CPU HALT

RESET

AUX.

CONSOLE

ROUTE SWITCH PROCESSOR 2

SLAVE

MASTER

SLAVE/MASTER

H3888

Slot 0 1234 5 6

pper

wer supply

hassis

ounding

ceptacles

wer

wer supply

DC FAIL

AC POWER

DC FAIL

AC POWER

RSP slots

aptive

stallation screw

aptive

stallation screw

VIP-FE-TX/4E Installation and Configuration 9

Versatile Interface Processor Functions

Figure 6 shows the rear of the Cisco 7513 with two AC-input power supplies installed. Two slots (6

and 7) are reserved for the second generation Route Switch Processor (RSP2), which contains the

system processor and performs packet switching functions. Slots 0 through 5 and 8 through 12 are

for interface processors.

Figure 6 Cisco 7513, Interface Processor End

ENABLE

H5268

EJECT

SLOT 0

SLOT 1

NORMAL

CPU HALT

RESET

AUX.

CONSOLE

ROUTE SWITCH PROCESSOR 2

SLAVE

MASTER

SLAVE/MASTER

Blower module

Cable-management

bracket

Card cage and

processor modules

Air intake vent

Power supplies

Chassis grounding

receptacles

OK FAN

OK OUTPUT

FAIL

OK FAN

OK OUTPUT

FAIL

POWER

10 VIP-FE-TX/4E Installation and Conﬁguration

Versatile Interface Processor Functions

VIP Port Adapter Hardware Conﬁguration Overview

The port adapters attach to the VIP motherboard. (See Figure 7.) Each port adapter contains the

physical connections for the VIP interface types to connect to your network.

Figure 7 VIP with One FE-TX and One 4E Port Adapter (Product Number VIP-FE-TX/4E[=])

Following are the VIP port adapters by interface type:

•Ethernet 10BASE-T—4E

•Fast Ethernet 100BASE-TX—FE-TX

•Synchronous serial—4T

•Token Ring—4R

Following are the supported electrical interfaces:

•4E port adapter—10BASE-T Ethernet, using RJ-45

•FE-TX port adapter—IEEE 802.3u Fast Ethernet 100BASE-TX, using Media Independent

Interface (MII) or RJ-45

•4T port adapter—synchronous serial (EIA/TIA-232, EIA-TIA-449, EIA-530, V.35, and X.21;

determined by the cable), using DB-60, 60-pin mini-D-sub connectors

•4R port adapter—IEEE 802.5 Token Ring, using DB-9, 9-pin D-sub connectors

H4711

DRAM

SIMMs

Microcode

Flash U17

Bus connector

ETHERNET-10BT

LINK

MII

LINK

RJ45

FAST ETHERNET

FE-TX in

port adapter

slot 0

4E in port

adapter

slot 1

Port adapter

handles not shown

Tabla de contenidos

Otros manuales de Hardware de red de Cisco

Cisco

Cisco ONS 15454 Manual de usuario

Cisco

Cisco CRS-1 - Carrier Routing System Router Guía del usuario

Cisco

Cisco NSS4100 - Gigabit Storage System Manual de instrucciones

Cisco

Cisco ISE - Line Card ISE Manual de usuario

Cisco

Cisco Content Engine 510 Manual de usuario

Cisco

Cisco Edge 300 Series Guía de inicio rápido

Cisco

Cisco ONS 15310-MA SDH Manual

Cisco

Cisco NCS 1000 Manual de usuario

Cisco

Cisco Linksys Business Series Network Storage System... Manual de usuario

Cisco

Cisco Firepower 1100 Series Manual

Cisco

Cisco Content Delivery Engine 100/200/300/400 Manual

Cisco

Cisco ISA 3000 Guía de inicio rápido

Cisco

Cisco Meraki Catalyst 9300/X/L-M Series Manual de usuario

Cisco

Cisco 5400 Manual de instrucciones

Cisco

Cisco 2431 - IAD Router Manual de usuario

Cisco

Cisco IP/VC 3500 Instrucciones originales

Cisco

Cisco 2610 - Router - EN Manual de usuario

Cisco

Cisco ONS 15327 Manual

Cisco

Cisco SCE 1000 and Manual del operador

Cisco

Cisco Aironet 1430 Series Manual de usuario

Cisco

Cisco NSS2000 Series Manual de usuario

Cisco

Cisco NCS 6008 LCC Manual de instrucciones

Cisco

Cisco ONS 15454 Manual

Cisco

Cisco ONS 15310-CL Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
