Features

The Cisco Firepower 9300 security appliance is a next generation network and content security platform. Its

modular standalone chassis offers high-performance and flexible I/O options, which enable it to run multiple

security services simultaneously.

The Firepower 9300 runs FXOS and can deploy multiple application types. See Cisco Firepower 4100/9300

FXOS Compatibility for more information about software version support for each component in the Firepower

9300. See 产品 ID 编号, on page 33 for a list of the component product IDs (PIDs) associated with the

Firepower 9300.

The following figure shows a fully populated Firepower 9300.

Cisco Firepower 9300 Hardware Installation Guide

Figure 1: Firepower 9300

The following table lists the hardware features of the Firepower 9300.

Table 1: Firepower 9300 Features

DescriptionFeature

Common Criteria (CC) and Federal Information Processing Standards (FIPS)

For more information, see the "Security Certifications Compliance"

topic in the Security Certifications Compliance chapter in the FXOS

Configuration Guide for your software version.

Note

Security standards

certifications

3 RUForm factor

Cisco Firepower 9300 Hardware Installation Guide

Overview

Features

DescriptionFeature

Mount rails included (4-post EIA-310-D rack) with span between front and rear

rails of 24 to 36 in.

Rack mount

Front to rear

Cold aisle to hot aisle

Airflow

Cisco Firepower 9300 Supervisor with eight 10-Gigabit Ethernet ports and two

network module slots for I/O expansion

See 机箱组件, on page 4 for more information about the chassis Supervisor.

Supervisor

ThreeSecurity module slots

• SM-24—24-physical core CPU security module (NEBS ready)

• SM-36—36-physical core CPU high performance security module

• SM-40—40-physical core CPU Crypto security module (NEBS ready)

• SM-44—44-physical core CPU high performance security module (NEBS

ready)

• SM-48—48-physical core CPU Crypto security module (NEBS ready)

• SM-56—56-physical core CPU Crypto security module

See 安全模块, on page 13 for more information about the security modules.

Supported security

modules

Two

Located in the Supervisor

Network module slots

• 8-port 10-Gigabit Ethernet SFP+

• 4-port 40-Gigabit Ethernet QSFP+

• 2-port 100-Gigabit Ethernet QSFP28 (double-wide, occupies both network

module slots)

• 2-port 100-Gigabit Ethernet QSFP28

• 4-port 100-Gigabit Ethernet QSFP28

• 2-port 40-Gigabit Ethernet QSFP+ (built-in) with hardware bypass

•6-port 10-Gigabit Ethernet SR/LR fiber SFP+ (built-in) with hardware bypass

You can deploy the Firepower 9300 as a dedicated threat sensor with

hardware bypass network modules.

Note

Supported network

modules

256-GB DDR4 DRAM per security moduleMemory

Up to twenty-four 10-Gigabit Ethernet (SFP+) interfaces; up to eight 40-Gigabit

Ethernet (QSFP+) interfaces with two network modules; up to eight 100-Gigabit

Ethernet (SFP+) interfaces

Maximum number of

interfaces

Cisco Firepower 9300 Hardware Installation Guide

Overview

Features

DescriptionFeature

One Gigabit Ethernet port on the Supervisor

Supports 1-Gb fiber or copper SFPs

Management port

One RJ-45 consoleSerial port

One USB 2.0 Type AUSB port

Displays serial numberPullout asset card

On rear panelGrounding lug

On front panelLocator beacon

On rear panel

The initial Firepower 9300 chassis does not have a power switch.

Note

Power switch

Two

On rear panel

Power supply slots

AC, DC, and HVDC

Do not mix power supply types or wattage.

Note

Power supply types

Yes 1 + 1Redundant power

Four (hot-swappable)

On rear panel

Fan slots

SM-24, SM-36, SM-44—Up to 2.4 TB per chassis (1.2 TB per security module

in RAID 1 configuration)

SM-40, SM-48, SM-56—UP to 4.8 TB per chassis (1.6 TB per security module

in RAID 1 Configuration)

Storage

机箱组件

Firepower 9300 机箱包含以下组件：

• Firepower 9300 管理引擎 -机箱管理引擎模块

•管理端口

• RJ-45 控制台端口

• USB A 型端口

• 8 个端口，用于 1千兆或 10 千兆以太网 SFP（光纤和铜缆）

Cisco Firepower 9300 Hardware Installation Guide

Overview

机箱组件

• Firepower 9300 安全模块 -最多三个安全模块

• Firepower 网络模块 -两个单位宽网络模块或一个双位宽网络模块

•两个电源模块（交流或直流）

•四个风扇模块

电源开关

原始 Firepower 9300 AC 机箱不包含外部电源开关。使用 CLI 命令重置 Firepower 9300。要以物

理方式重启 9300，您必须拔掉电源线，然后重新插上电源线。

注释

关闭机箱电源（将电源开关切换至“关闭”(OFF) 位置，或拔掉电源线）后，至少等待 10 秒，再

重新开机。

注释

Firepower 9300 机箱在机箱后部具有备用电源开关，可用于控制两个电源模块。您必须先正常关

闭软件应用，再将开关切换至“关闭”(OFF) 位置。

如果将开关切换至“关闭”(OFF) 位置，无论软件状态如何，管理引擎和安全模块的主电源都将关

闭，这不仅会导致所有正在传输的数据发生丢失，而且可能损坏 SSD 中的数据。您必须先正常

关闭软件应用，再将开关切换至“关闭”(OFF) 位置。

警告

正常关闭机箱

您可以从 CLI 或机箱管理器正常关闭机箱。

请参阅FXOS CLI配置指南中系统管理一章中的“关闭Firepower 4100/9300机箱”小节，以获取符

合您软件版本的从CLI关闭机箱的流程。正常关闭通常只需要几秒，但是最长可能需要三分钟。

当屏幕上显示 System Halted 消息时，您可以将机箱后部的电源开关切换至“关闭”(OFF) 位置。

请参阅FXOS CLI配置指南中系统管理一章中的“关闭Firepower 4100/9300机箱”小节，以获取符

合您软件版本的从CLI关闭机箱的流程。完成关机后，您可以将机箱背面的电源开关切换至“关

闭”(OFF) 位置。

当您关闭机箱时，安全模块将自动关闭。

正常关闭安全模块

您可以从 CLI 或机箱管理器单独关闭安全模块，也可以使用每个安全模块正面的电源开关。短

暂按住每个安全模块前面板上的电源按钮。当电源按钮变为琥珀色后，您即可将机箱后部的电

源开关切换至“关闭”(OFF) 位置。

在更换安全模块时，可单独关闭安全模块。

Cisco Firepower 9300 Hardware Installation Guide

Overview

机箱组件

您必须按下安装在9300机箱中每个安全模块上的电源按钮。您最多可以在机箱中安装三个安全

模块。

注释

请参阅FXOS CLI配置指南Security/Module/Engine一章中的“打开/关闭已安装模块/引擎”内容，以

获取符合您软件版本的用主管CLI命令关闭安全模块的流程。当系统对所有插槽显示 Oper Power:

off 后，您可以将机箱后部的电源开关切换至“关闭”(OFF) 位置。

请参阅FXOS CLI配置指南Security/Module/Engine一章中的“打开/关闭已安装模块/引擎”内容，以

获取符合您软件版本的用主管 CLI 命令关闭安全模块的流程。完成关机后，您可以将机箱背面

的电源开关切换至“关闭”(OFF) 位置。

Deployment Options

Here are some examples of how you can deploy the Firepower 9300:

• At the core/aggregation layer of a three-tier data center in a high availability configuration.

• As a dedicated multifunction security service within converged infrastructure stacks (vBlock, FlexPod,

for example) at the access layer.

• As a high-performance data center security appliance between the WAN edge and data center core in an

high availability configuration.

• As a leaf that exclusively offers security functions in a spine/leaf data center design.

装箱清单

下图显示了 Firepower 9300 的装箱清单。请注意，装箱清单可能有所变动，实际配件的数量可能多

于或少于装箱清单上所列的内容。

Cisco Firepower 9300 Hardware Installation Guide

Overview

Deployment Options
