Application Note

Cisco 2650XM Gateway -PBX Interoperability: Lucent Definity

G3r PBX using Analog FXO Interfaces to an H.323 Gateway

Introduction

This document contains the results for PBX interoperability testing between PBXs and the Cisco Network Module with E&M to the FXS

Voice Interface Cards installed in Cisco voice gateways.

Network Topology

The following diagram shows a pair of Cisco voice gateways that are configured for back-to-back VoIP operation. In this example,

connectivity and interoperability is achieved through a Lucent Definity G3r V7 PBX that is connected to a Cisco 3745 back-to-back via an

Ethernet connection to a Cisco 2651XM connected to a Lucent Definity G3r V6 PBX.

Basic Test Configuration

VoIP

Phone A

ext-4004

PBX A

Lucent Definity G3r v7 Phone E

Router-A

C3745 Router-B

C2650XM

Phone F

PBX B

Lucent Definity G3r v6

Phone C

E&M type I I/S CO Trunk

*1xxxx

FXS

E&M type I I/S

Limitations

None

System Components

Hardware Requirements

•Cisco 2651XM gateway

•Lucent Definity G3r PBX, Version 6

Software Requirements

•Cisco IOS Software Release 12.2(15)ZJ (c2600-jsx-mz-v122_15_zj_throttle.0.5.0)

•Lucent Definity PBX Software Release G3r V6

•VIC-VG-2FXS network module

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 2of 9

Configuration

Configuring the Lucent Definity G3r V6

Trunk Group

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 3of 9

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 4of 9

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 5of 9

Configuring the Cisco 2651XM

Router# show running config

Building configuration...

Current configuration : 1591 bytes

version 12.2

service timestamps debug datetime msec

service timestamps log uptime

no service password-encryption

hostname C2651XM

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 6of 9

boot system flash:c2600-jsx-mz-v122_15_zj_throttle.0.5.0

logging queue-limit 100

logging buffered 1000000 debugging

ip subnet-zero

ip tcp synwait-time 13

no ip domain lookup

mpls ldp logging neighbor-changes

voice-card 1

voice call carrier capacity active

no voice hpi capture buffer

no voice hpi capture destination

mta receive maximum-recipients 0

interface FastEthernet0/0

ip address 100.1.1.2 255.255.255.0

no ip mroute-cache

duplex auto

speed 100

interface FastEthernet0/1

ip address 172.20.8.30 255.255.255.0

no ip mroute-cache

duplex auto

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 7of 9

speed auto

ip http server

ip classless

ip route 0.0.0.0 0.0.0.0 FastEthernet0/1

dialer-list 1 protocol ip permit

call rsvp-sync

voice-port 1/1/0

voice-port 1/1/1

mgcp profile default

dial-peer cor custom

dial-peer voice 2 voip

destination-pattern 20..

session target ipv4:100.1.1.1

dial-peer voice 1 voip

destination-pattern 3000

session target ipv4:100.1.1.1

dial-peer voice 3 pots

destination-pattern 26..

prefix 26

dial-peer voice 4 pots

destination-pattern 4000

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 8of 9

port 1/1/0

dial-peer voice 999 pots

incoming called-number .

destination-pattern 26..

direct-inward-dial

dial-peer voice 5 pots

destination-pattern 4004

port 1/1/1

gatekeeper

shutdown

line con 0

exec-timeout 0 0

line aux 0

exec-timeout 0 0

line vty 0 4

exec-timeout 0 0

password c

no login

line vty 5 15

no login

end

Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com

Page 9of 9

Important Information

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE

WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE

ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL

RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL

DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE

OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES.
