Cisco EX60 Manual de usuario

Calling someone Using the list of contacts to call

Initiating a video conference (optional feature)

Keyboard layout

Tap Dialpad, as

outlined.

When the number has

been keyed in, tap the

Call key to place the

call.

Key in the number, as

outlined.

Tap as outlined to go betwen dialpad and alphanumerical

keyboard.

When an entry has been located and

selected the Call menu will appear.

Tap Call to place the call. There are

some options available. These are always

context sensitive, which means that

meaningless options are not shown. For

example Add to Favorites is not available

for entries already residing in the list of

Favorites.

If you are going to

look in a specic

list only, tap the

corresponding

tab rst.

To search for someone, tap here to invoke the virtual keyboard

and then key in the name or number. Matches will appear as you

type. All three lists will be examined for possible matches.

To locate an entry, you may also scroll

through a list as you would do on a

smartphone. Tap to select an entry.

Any matches will

appear here. Tap to

select an entry. The

selected entry will

appear on a blue

background.

Method A (Multisite):

Method B (MultiWay/CUCM):

In a call

tap Add.

In a call

tap Hold.

Search or dial in the usual

way.

Tap + Place New Call

and then search or dial in

the usual way.

Tap ADD to turn the current

call into a conference.

Tap CALL to turn the current

call into a conference.

Tap END to terminate the

conference.

Repeat the procedure to

add more participants.

Tap END to terminate the

conference.

Repeat the procedure to

add more participants.

D1504001 Quick Reference Guide EX60 & EX90, TC6.1, English, May 2013

Tap here to

invoke the

dial pad.

Tap here to

invoke the list

of contacts

including

Favorites,

Directory and

History.

Tap here to

invoke a list

of upcoming

scheduled

meetings.

Tap here to

invoke the

voice mail

system, if

applicable.

Any messages

to you while you

were away will be

indicated here.

Adjust volume

here (tap and

drag).

Tap to

mute /unmute

microphone.

Time of day.

Tap here to

access the

Settings.

Tap here

to activate

self-view.

Tap here

to access

Help desk,

if available.

Tap here

to access

Camera

settings.

Tap here to activate /

deactivate the Do not

disturb feature.

Tap here

to activate /

deactivate

the Standby

feature.

A tour of the Touch padSharing content

You must be in a call to be able to

do this. Make sure your presentation

source is switched on and connected

to the video system before you tap

Presentation .

Tap the touch screen

to wake up the system,

if needed.

Tap a button

to activate its

function.

Scroll in lists

as outlined.

Tap Presentation, as

outlined.

When the presentation is

over, tap Stop Presenting,

as outlined.

Scroll horizontally (a), if

needed, to locate the

required source, as outlined.

Then tap Present (b).

You should now see the

presentation on the screen.

D1504001 Quick Reference Guide EX60 & EX90, TC6.1, English, May 2013

Want to share a document?

Place document

as shown and

tilt camera as

shown to share a

document.

Headset

in use is

indicated

here
