2.
3.
4.Camera: input thevideo signal, normallybe set inthe rear bumper.
5.
Display: Back visiondisplay, distance numeric display, buzzer alarmcircuit , etc,
normally set insidethe driving room.
Control unit: MCU control circuit, normally set inside the trunk, nearby the
backup lights.
Sensor: .Ultrasonic sensor "electronic eye", is the transmisson center for detecting
signals and normallyset at therear or frontof bumper.
Mobile phone handsfree system: Beset inside therear view mirror, connected with
the mobile, bringconvenience and safetyduring circumstance.
TECH DATA
1.
2.
3.
4.
5.
6. Radio frequency: 315MHz/433MHz
7. Camera angle: 92 or 120
Rated voltage : DC12V (24v available)
Power : 3.6W
Workingtemperature: -20 C---70 C
Detecting distance: 0.3-2.0M
Detecting angle: H>60 ,V>60
CISBO RADER SYSTEM USER’S MANUAL
