Cirrus Logic CL-PS7111 Guía de seguridad

Version 1.3 April 1999

CL-PS7111 Development Kit

Software User’s Guide

Embedded Processors Division

This document describes sample code for the CL-PS7111 provided by Cirrus Logic Inc. No warranty is given for

the suitability of the program code described herein for any purpose other than demonstrating functional operation

of the CL-PS7111. The information contained in this document is subject to change without notice.

CL-PS7111 Development Kit – Software User’s Guide

April 1999 2 Version 1.3

CL-PS7111 Development Kit – Software User’s Guide

Version 1.3 3 April 1999

Table of Contents

1. Introduction...........................................................................................................................................................5

2. ARM Software Development Toolkit................................................................................................................... 5

2.1. ARM Project Manager..................................................................................................................................5

2.2. ARM Debugger.............................................................................................................................................6

3. Angel™................................................................................................................................................................. 7

4. Download.exe .......................................................................................................................................................7

5. Board Setup........................................................................................................................................................... 8

6. Lib7111.................................................................................................................................................................9

6.1. adc.c.............................................................................................................................................................. 9

6.1.1. ADCDisable.......................................................................................................................................... 9

6.1.2. ADCEnable........................................................................................................................................... 9

6.1.3. ADCGetData.........................................................................................................................................9

6.2. codec.c ........................................................................................................................................................ 10

6.2.1. CodecDisable ......................................................................................................................................10

6.2.2. CodecEnable .......................................................................................................................................10

6.2.3. CodecPlay ...........................................................................................................................................10

6.2.4. CodecPlayBg.......................................................................................................................................10

6.2.5. CodecRecord....................................................................................................................................... 10

6.3. flash.c.......................................................................................................................................................... 11

6.3.1. FlashEraseChip ...................................................................................................................................11

6.3.2. FlashEraseSector.................................................................................................................................11

6.3.3. FlashNumSectors ................................................................................................................................11

6.3.4. FlashProgramBlock............................................................................................................................. 11

6.3.5. FlashSectorInfo................................................................................................................................... 11

6.4. ir.c ............................................................................................................................................................... 11

6.4.1. IRCharReady.......................................................................................................................................11

6.4.2. IRDisable ............................................................................................................................................12

6.4.3. IREnable..............................................................................................................................................12

6.4.4. IRReceiveChar.................................................................................................................................... 12

6.4.5. IRSendChar......................................................................................................................................... 12

6.5. isr.c.............................................................................................................................................................. 12

6.5.1. InterruptInstallISR............................................................................................................................... 12

6.5.2. InterruptRemoveISR ...........................................................................................................................12

6.5.3. InterruptSetADCHandler ....................................................................................................................12

6.5.4. InterruptSetCodecHandler................................................................................................................... 13

6.6. isrshell.s.......................................................................................................................................................13

6.7. kbd.c............................................................................................................................................................ 13

6.7.1. KbdGetButton..................................................................................................................................... 13

6.7.2. KbdNoButton...................................................................................................................................... 13

6.7.3. KbdRead..............................................................................................................................................13

6.8. lcd.c............................................................................................................................................................. 13

6.8.1. LCDCircle........................................................................................................................................... 13

6.8.2. LCDFillCircle .....................................................................................................................................14

6.8.3. LCDLine .............................................................................................................................................14

6.8.4. LCDPrintChar..................................................................................................................................... 14

6.8.5. LCDPrintCharX2 ................................................................................................................................ 14

6.8.6. LCDPrintString................................................................................................................................... 14

6.8.7. LCDPrintStringX2 ..............................................................................................................................14

6.9. lcd_alps.c ....................................................................................................................................................14

6.9.1. LCDBacklightOff................................................................................................................................14

6.9.2. LCDBacklightOn ................................................................................................................................14

6.9.3. LCDCls ...............................................................................................................................................15

6.9.4. LCDEnable..........................................................................................................................................15

6.9.5. LCDGetPixel....................................................................................................................................... 15

CL-PS7111 Development Kit – Software User’s Guide

April 1999 4 Version 1.3

6.9.6. LCDOff...............................................................................................................................................15

6.9.7. LCDOn................................................................................................................................................ 15

6.9.8. LCDSetPixel .......................................................................................................................................15

6.10. uart.c........................................................................................................................................................15

6.10.1. UARTCharReady................................................................................................................................15

6.10.2. UARTDisable...................................................................................................................................... 15

6.10.3. UARTEnable.......................................................................................................................................16

6.10.4. UARTReceiveChar .............................................................................................................................16

6.10.5. UARTSendChar.................................................................................................................................. 16

7. Samples...............................................................................................................................................................16

7.1. adcsamp....................................................................................................................................................... 16

7.2. audio............................................................................................................................................................16

7.3. flashtst.........................................................................................................................................................16

7.4. irrecv........................................................................................................................................................... 17

7.5. irxmit...........................................................................................................................................................17

7.6. keyboard......................................................................................................................................................17

7.7. screen ..........................................................................................................................................................17

7.8. touchscr....................................................................................................................................................... 17

7.9. uartecho.......................................................................................................................................................17

CL-PS7111 Development Kit – Software User’s Guide

Version 1.3 5 April 1999

1. Introduction

The CL-PS7111 development kit example software is targeted at software developers who plan to port operating

systems and applications to the CL-PS7111. A library of routines is provided which configure and operate all of the

peripherals on the CL-PS7111 evaluation board. Additionally, there is a set of sample programs that use this library

to exercise the peripherals on the board.

To use the CL-PS7111 evaluation kit example software, the ARM® SDT Version 2.11a containing the project

manager, C compiler, assembler, linker, debugger, and ARM instruction set emulator is required. The code in this

kit is intended to be used on a PC running Windows® 95, Windows NT® 3.51, or Windows NT 4.0.

2. ARM Software Development Toolkit

Included on the CD-ROM is a 60-day evaluation version of the ARM SDT Version 2.11a. This is a fully functional

evaluation copy of the SDT that will cease to execute after 60 days. To obtain the full version of the ARM SDT,

contact ARM Ltd. (www.arm.com).

To install the ARM SDT, simply run setup.exe from the sdt211a directory on the CD-ROM and follow the

on-screen directions. If you are unfamiliar with the ARM SDT, be sure to select the online manuals as one of the

components to install.

The evaluation version of the SDT will create a seemingly useless directory called “c_dilla”; if you remove this

directory or its contents, the evaluation version of the SDT will no longer work, will not uninstall correctly, and will

not be able to be installed again on your system.

Once the SDT has been installed, there are two applications that will be used to build and debug applications: the

ARM Project Manager and the ARM Debugger. These applications are described fully in the online manuals, but

brief instructions for basic use of these applications is provided in the following sections.

2.1. ARM Project Manager

The ARM Project Manager is used to develop and build applications for the CL-PS7111 evaluation board. It is

found in the “Start” menu under “Programs” then “ARM SDT v2.11a”. Once run, it will show an empty workspace.

The first thing to do is to open a project file (which has an extension of “.apj”). This is done by selecting “Open”

from the “File” menu.

Once a project has been opened, there are several basic operations that you might perform. They are:

1) Edit the source code. To do this, click on the “+” beside the “ARM Executable Image” line in the project

window, then the “+” next to the “Debug” line, then the “+” next to the “Sources” line, and then double click on

the source file to be edited. The source file will be opened in another window. Standard editing operations can

be performed on the source code in this window.

2) Build the executable. To do this, click on the “Build Debug” button at the bottom of the project window. You

can build either a debug or release version of the executable; selecting the “Debug” or “Release” line from the

project window will change the button at the bottom to “Build Debug” or “Build Release” respectively.

Alternately, you can select “Build” from the “Project” menu or press Shift+F8 to build the executable. The

debug version of an executable contains all the symbolic information needed to debug the executable, while the

release version contains no symbolic information and is fully optimized.

3) Debug the executable. To do this, select “Debug” from the “Project” menu, or press F5. This will launch the

ARM Debugger, load the executable image, and set a breakpoint at the beginning of the “main” function.

4) Run the executable. To do this, select “Execute” from the “Project” menu, or press Ctrl+F5. This will launch

the ARM Debugger, load the executable image, and begin execution of the program.

CL-PS7111 Development Kit – Software User’s Guide

April 1999 6 Version 1.3

2.2. ARM Debugger

The ARM Debugger is used to debug applications on the CL-PS7111 evaluation board. It is found in the “Start”

menu under “Programs” then “ARM SDT v2.11a”. Once run, it will show three windows, the “Execution

Window”, “Command Window”, and “Console Window”. The execution window shows the current execution

context of the target system. The command window allows you to type commands to the debugger, though you will

probably never use this since the functionality can be more easily accessed via the GUI. The console window shows

the output from the target system, including anything printed out from your application.

If the ARM Project Manager launches the ARM Debugger, the image to be debugged will be automatically loaded

into the target system’s memory. Otherwise, the image to be debugged must be loaded manually by selecting “Load

Image” from the “File” menu.

Once an image has been loaded into the target system’s memory, there are several basic operations that you might

perform. They are:

1) View the source files in the program image. Select “Source Files” from the “View” menu, or press Ctrl+F, and

a window will be displayed showing all the source files in the program image. Double clicking on one of the

file names in the “Source Files” window will open a new window that will display the selected source file.

2) Set a breakpoint. In either the “Execution Window” or a source file window, place the cursor on the line where

you want to place a breakpoint. Then select “Toggle Breakpoint” from the “Execute” menu, or press F9.

Performing the same action after selecting a line that already has a breakpoint on it will remove the breakpoint.

3) Run the program. Select “Go” from the “Execute” menu, or press F5. The program will begin executing. It

will run until a breakpoint is reached, the program terminates, or a fatal error occurs.

4) Single-step the program. The program can be single-stepped in three different ways. You can step to the next

point within the program execution, stepping into any procedures called, by selecting “Step In” from the

“Execute” menu, or pressing F8. Think of this as stepping into the called procedure. You can step to the next

point within the program execution, allowing any called procedure to execute to completion, by selecting

“Step” from the “Execute” menu, or pressing F10. Think of this as stepping over any called procedures.

Finally, you can step to the first point within the program execution after the current routine has completed

executing by selecting “Step Out” from the “Execute” menu, or pressing Shift+F7. Think of this as stepping out

of the current procedure.

5) Run the program to a specific line. This is roughly equivalent to setting a breakpoint, running the program, and

then removing the breakpoint. Once a line has been selected in the “Execution Window” or a source file

window, select “Run to cursor” from the “Execute” menu, or press F7.

6) View the ARM registers. Select “Registers\Current Mode” from the “View” menu. This will display a window

with the currently accessible register set. This is the most useful register view for typical use; the other register

views would be useful for OS development.

7) View the local variables of the current procedure. Select “Variables\Local” from the “View” menu, or press

Ctrl+L. Right clicking on the variables will allow you to change the way the variable’s value is displayed, or

change the content of the variable. Double clicking on a pointer variable will open a new window showing the

contents of the memory pointed to by the variable.

8) View the global variables of the current program. Select “Variables\Global” from the “View” menu, or press

Ctrl+G. The global variable window can be manipulated in the exact same way as the local variable window.

9) View the contents of memory. Select “Memory…” from the “View” menu, or press Ctrl+M. A dialog will be

displayed allowing you to specify the memory address you wish to view. Once you select “OK”, a memory

window will be displayed. The memory window will always show 4K worth of data, starting on a 4K

boundary, and display the memory contents as hexadecimal 32-bit words.

CL-PS7111 Development Kit – Software User’s Guide

Version 1.3 7 April 1999

3. Angel™

The example software provided in the evaluation kit is designed to run under control of the Angel debug monitor

from ARM. In order to allow the sample code to handle the IRQ interrupt, the version of Angel provided with the

evaluation kit (based on Angel 1.04) has been slightly modified to allow the interrupt to be hooked by application

code.

There are two versions of Angel provided with the evaluation kit: one communicates with the host system debugger

via UART1 and the other via UART2. The two versions are identical in every other respect. The two versions exist

since the IR port uses UART1, and having Angel communicate with the host via UART1 would prevent the use of

the IR port. The version that uses UART1 is called cl7111_1.rom and the version that uses UART2 is called

cl7111_2.rom. They reside in the ps7111\angel directory of the CD-ROM. The evaluation board is shipped with

cl7111_2.rom programmed into FLASH bank 0.

Also contained in the ps7111\angel directory is the source directory, containing the source code for this version of

Angel. In order for this source code to be built, it must be placed in the same directory into which the ARM SDT

was installed (i.e. in the same directory that contains the “bin”, “cl”, “demon”, “include”, “lib”, etc. directories of

the ARM SDT).

The ARM Project Manager file cl7111.apj under the source\cl7111.b\apm directory can be used to build Angel.

There are two variants of Angel that can be built: Image1 and Image2. The Image1 variant uses UART1 to

communicate with the host debugger and the Image2 variant uses UART2. Once built, the file

source\cl7111.b\apm\image1\cl7111.rom corresponds to the cl7111_1.rom on the CD-ROM, and the file

source\cl7111.b\apm\image2\cl7111.rom corresponds to cl7111_2.rom.

Angel enables the MMU on the CL-PS7111 and uses it to rearrange the memory map of the processor. The main

reason this is done is to provide an additional mapping of DRAM at location 0x08000000. The stack checking code

generated by the ARM compiler produces incorrect results when the stack is located at or above 0x80000000, and

DRAM is located at 0xC0000000, so this re-mapping is done to place DRAM below 0x80000000. The memory

map under Angel appears as follows:

0xC0000000 – 0xC0FFFFFF DRAM Bank 0

0x80000000 – 0x80001800 CL-PS7111 registers

0x70000000 – 0x7000007F On-chip boot ROM

0x60000000 – 0x600007FF On-chip SRAM

0x50000000 – 0x5FFFFFFF Expansion

0x40000000 – 0x4FFFFFFF CL-PS6700 PCMCIA controller

0x30000000 – 0x3FFFFFFF Keyboard scan latch

0x20000000 – 0x2FFFFFFF CS8900A Ethernet controller

0x10000000 – 0x107FFFFF FLASH Bank 0

0x08028000 – 0x08FFFFFF User program space

0x08020000 – 0x08027FFF Angel workspace

0x08000000 – 0x0801FFFF LCD frame buffer

0x00000000 – 0x007FFFFF FLASH Bank 0

When building an application to run under the control of Angel, the read-only base address should be set to

0x08028000.

4. Download.exe

Download.exe is a program used to write boot code into FLASH bank 0. It can be used to download a new version

of Angel into the CL-PS7111 evaluation board. The program is located in the ps7111 directory on the CD-ROM.

The command line syntax for download.exe is as follows:

download <filename> {<baud rate> {<com port>}}

CL-PS7111 Development Kit – Software User’s Guide

April 1999 8 Version 1.3

Where <filename> is the name of the file to be downloaded into FLASH bank 0, <baud rate> is the optionally

specified baud rate to use for the data download, and <com port> is the optionally specified COM port on the host

PC that is used for communication with the evaluation board. The default baud rate used is 115,200, with 9,600,

19,200, 28,800, 38,400, and 57,600 being the other valid options. The default COM port used is COM1, with

COM2, COM3, and COM4 being the other valid options. The COM port is specified as simply the port number (i.e.

“2” for COM2).

In order to use download.exe to write boot code into FLASH bank 0, follow these steps:

1) Connect the supplied NULL modem cable between the “UART1” connector on the evaluation board and any

available COM port on the host system.

2) Place a shunt on jumper JP2 (located directly above the upper left hand corner of the keyboard).

3) Apply power to the evaluation board.

4) Run download.exe.

5) Press the “reset” button on the evaluation board.

6) Press the “wakeup” button on the evaluation board.

7) Download.exe will display its progress as it programs FLASH bank 0. Wait until it says it is done.

8) Remove power from the evaluation board.

9) Remove the shunt from jumper JP2.

At this point the new boot code is programmed into FLASH bank 0. It can then be used in the normal operation of

the board.

5. Board Setup

Follow these steps to setup communication with the evaluation board.

1) Connect the supplied NULL modem cable between the “UART2” connector on the evaluation board and any

available COM port on the host system.

2) Apply power to the evaluation board.

3) Press the “reset” button on the evaluation board.

4) Press the “wakeup” button on the evaluation board.

5) Start the ARM Debugger on the host system.

6) Select “Configure Debugger…” from the “Options” menu.

7) Select “remote_a” as the target environment.

8) Click on the “Configure…” button to select the host COM port to be used. To speed the debugging process,

select a baud rate of 115,200. Click on “OK” when done.

9) Click on “OK”. The ARM Debugger should connect to Angel on the evaluation board and then print out a

message similar to the following in the “Console Window”:

Angel Debug Monitor for CL-PS7111 Eval Kit (Built with Serial(x1-2), no info) 1.04 (Advanced RISC Machines SDT 2.11a)

Angel Debug Monitor rebuilt on Nov 10 1998 at 11:07:40

Serial Rate: 115200

CL-PS7111 Development Kit – Software User’s Guide

Version 1.3 9 April 1999

If there is a problem (such as a bad serial cable, attempting to use the wrong serial port, etc.), the following

message will be displayed:

Cannot open target: the target is not responding.

The ARM Debugger can be changed between debugging programs on the CL-PS7111 evaluation board (via Angel)

and the ARMulator software ARM emulator at any time. Simply select “Configure Debugger…” from the

“Options” menu, select “remote_a” (for the CL-PS7111 evaluation board) or “ARMulate” for the ARMulator as the

target environment, and then click on “OK”.

If there are any communication problems between the host and the CL-PS7111 evaluation board, the ARM tools

might revert to using the ARMulator as a result of an obscurely worded dialog box. If this happens, you will have to

use the “Configure Debugger…” option to switch back to debugging on the CL-PS7111 evaluation board.

6. Lib7111

Lib7111 is a library of routines for accessing the various peripherals on the CL-PS7111 evaluation board. These

routines are not necessarily the most efficient in terms of execution time or code space, they simply demonstrate the

proper operation of the peripherals. The library is divided into separate source files for each peripheral. The

lib7111.h file contains prototypes for all the functions in the library. The lib7111.apj file is the ARM Project

Manager project file used to build the debug and release variants of the library.

The source code for this library is contained in the ps7111\lib7111 directory of the CD-ROM.

6.1. adc.c

This file contains routines for using the synchronous serial interface of the CL-PS7111. The SSI is a master mode

only SPI/Microwire compatible interface; on the evaluation board it is connected to a Maxim MAX148 10-bit ADC.

The MAX148 is powered on and off via bit two of GPIO port E; the ADC is powered on when the bit is driven high

and powered off when the bit is driven low.

6.1.1. ADCDisable

void ADCDisable(void)

This routine powers off the external MAX148 ADC.

6.1.2. ADCEnable

void ADCEnable(void)

This routine configures the SSI for 128kHz operation and powers on the external MAX148 ADC.

6.1.3. ADCGetData

long ADCGetData(long lChannel)

This routine tells the MAX148 ADC to sample data on the specified channel and returns the value of the sampled

data. The following are valid channel values, along with the data that each channel will sample:

0unused

1The VDD voltage.

2The TSPX value from the touch screen interface.

3The TSMX value from the touch screen interface.

CL-PS7111 Development Kit – Software User’s Guide

April 1999 10 Version 1.3

4The potentiometer at R47. This potentiometer is not populated on the evaluation board; populate

it with a 500KΩpotentiometer if desired.

5The VREF voltage.

6The TSMY value from the touch screen interface.

7The TSPY value from the touch screen interface.

6.2. codec.c

This file contains routines for using the codec interface of the CL-PS7111. The codec interface is a bi-directional

8kHz, 8-bit mono serial codec interface; on the evaluation board it is connected to an Oki MSM7702-01MS

telephone codec, which is configured to produce and consume µlaw PCM data. The MSM7702-01MS is powered

on and off via bit 0 of GPIO port E; the codec is powered on when the bit is driven high and powered off when the

bit is driven low.

The analog output of the Oki codec is connected to an Oki MSC1157MS-K amplifier. The MSC1157MS-K is

powered on and off when the codec is powered on and off.

6.2.1. CodecDisable

void CodecDisable(void)

This routine powers off the internal codec interface and the external MSM7702-01MS and MSC1157MS-K. The

codec interrupt is masked and the interrupt handler is removed.

6.2.2. CodecEnable

void CodecEnable(void)

This routine powers on the internal codec interface and the external MSM7702-01MS and MSC1157MS-K. An

interrupt handler is installed to handle the codec interrupts and then the codec interrupt is unmasked. The codec

interrupt handler will read all available data from the codec input FIFO, and will fill the codec output FIFO with

either playback data (if any exists) or silence.

6.2.3. CodecPlay

void CodecPlay(char *pcBuffer, long lLength)

This routine plays the given buffer of data via the codec interface. This routine will not return until the entire buffer

has been played out to the codec interface.

6.2.4. CodecPlayBg

void CodecPlayBg(char *pcBuffer, long lLength)

This routine plays the given buffer of data via the codec interface. This routine will return immediately, playing the

buffer in the background while other processing continues.

6.2.5. CodecRecord

void CodecRecord(char *pcBuffer, long lLength)

This routine records data into the specified buffer via the codec interface. This routine will not return until the entire

buffer has been filled with data read from the codec interface.

Otros manuales para CL-PS7111

Tabla de contenidos

Otros manuales de Microcontrolador de Cirrus Logic

Cirrus Logic

Cirrus Logic CL-PS7111 Manual de usuario

Cirrus Logic

Cirrus Logic CL-PS7500FE Manual de instalación

Cirrus Logic

Cirrus Logic CDB43131-GBK Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
