Introduction
The 56310 Drop Tube Switch is designed for use with any feeding system that carries free flowing feed.
It is designed to be mounted to the Drop Tubes.
The Delay Timer will allow the operator to set the start delay time before the fill time system restarts. This
feature will minimize short-cycling.
Follow Safety Instructions
Carefully read all safety messages in this manual and on your equipment safety signs.
Follow recommended precautions and safe operating practices.
DANGER: Moving Parts
Disconnect electrical power before working on system, equipment may start
automatically. Otherwise personal injury will result.
Severe personal injury will result if the equipment is operated without covers
properly installed.
DANGER: Electrical Hazard
Disconnect electrical power before inspecting or servicing equipment unless maintenance
instructions specifically state otherwise.
Ground all electrical equipment for safety.
All electrical wiring must be done by a qualified electrician in accordance with local and national
electric codes.
Ground all non-current carrying metal parts to guard against electrical shock.
Electrical disconnects and over current protection are not supplied with the equipment.
For additional parts and information, contact your nearest Chore-Time distributor or representative.
Find your nearest distributor at: www.choretime.com/contacts
CTB, Inc.
PO Box 2000
Milford, Indiana 46542-2000 USA
Phone (574) 658-4101 Fax (877) 730-8825
Internet: www.choretime.com
MF2487CJune 2021
Installation and Operators Manual
Installation and Operators Manual
Drop Tube Switch
Part No. 56310
