Chiayo COACH PRO Manual de usuario

CHIAYO ELECTRONICS CO., LTD.

Operation manual

COACH PRO

Personal Wireless PA System

COACH PRO Personal Wireless PA System

Important safety instructions

◼Read all of the instructions before the product is operated.

◼Keep these instructions well for future reference.

◼Follow all of the warnings and instructions when installing, setting up and using the product.

◼Only clean the product when it is not connected to the power supply system. Clean only with

a dry cloth.

◼Keep ventilation openings unblocked and follow with the manufacturer’s instructions for

installation.

◼Do not immerse product in any liquid or expose to heat or moisture

◼Keep the complete polarized or grounding type plug without any modification. A polarized

plug has two blades with one wider than the other. A grounding type plug has two blades and

a third grounding prong. The wider blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

◼Power supply cords should be well routed to prevent from being walked on or pinched by

items placed upon or against them, particularly at plugs, convenience receptacles, and the

point where they exit from the product.

◼Use only manufacturer authorized or recommended accessories.

◼Use only with a cart, stand, tripod or accessories specified or provided by Chiayo. Be careful

when using a cart to avoid injury from tip-over.

◼Unplug the product during an electrical strom or when unused for long periods of time.

◼Never disassemble, modify or service the product. Any unauthorized modifications may result

in personal injury and/or product failure. Additionally, your warranty will be void.

◼Please read and follow the instructions in this manual thoroughly to obtain optimum results

from this unit. We also recommend that you keep this manual handy for future reference.

Operation manual

INDEX

1. Instruction...............................................................................................................................4

1-1. In the box..........................................................................................................................4

1-2. Optional related products .................................................................................................4

1-3. Parts and functions...........................................................................................................5

1-4. Charging the battery.........................................................................................................5

1-5. Connection with external audio sources...........................................................................6

2. Settings and Operations........................................................................................................7

2-1. Using the wired microphone (MIC IN)...............................................................................7

2-2. Using the wireless receiver...............................................................................................8

2-3. Music audio input (AUX IN)- Smart phone / tablet / MP3 player.......................................9

2-4. Using the MP3 player & recorder ...................................................................................10

2-4-1. Parts and functions.................................................................................................10

2-4-2. Operating functions on the panel and the remote...................................................10

2-5. TONE for WIRED and WIRELESS MICROPHONE and MUSIC....................................12

2-6. ECHO for WIRED and WIRELESS MICROPHONE.......................................................12

3. FAQ & useful operation tips................................................................................................13

4. Maintenance-free Lead-acid and Lithium batteries...........................................................15

Instruction

Warning

Please read and follow the instructions in this manual thoroughly to obtain optimum results from

this unit. We also recommend that you keep this manual handy for future reference.

Safety Precautions

◼Be sure to read the instructions in this section carefully before use.

◼Make sure to observe the instructions in this manual as the conventions of safety symbols and

messages regarded as very important precautions are included.

Safety symbols and messages described below are used in this manual to prevent bodily injury

and property damage which could result from mishandling. Before operating your product, read

this manual first and understand the safety symbols and messages so you are thoroughly aware

of the potential safety hazards.

WARNING

Indicates a potentially hazardous situation which, if mishandled,

could result in death or serious personal injury.

CAUTION

Indicates a potentially hazardous situation which, if mishandled,

could result in moderate or minor personal injury, and/or property

damage.

Make sure to observe the following handling precautions so that a fire or personal injury does

not result from leakage or explosion of the battery.

◼Do not short, disassemble, heat or put the battery into a fire.

◼Never charge batteries of the type which are not rechargeable.

◼Do not solder a battery directly.

◼Be sure to use the specified type of battery.

◼Note the correct polarity when inserting a battery in the unit.

◼Avoid locations exposed to the direct sunlight, high temperature and high humidity when

storing batteries.

WARNING

To prevent the electromagnetic wave from badly influencing

medical equipment, make sure to switch off the unit's power when

placing it in close proximity to the medical equipment.

CAUTION

Battery discharge naturally according to a certain pattern even not

in use. For best performance and a prolonged lifespan, battery

should be charged regularly after every use or every month when

the system is in storage and not being used!

CD player optical pick up head is a very delicate device and

sensitive to humidity. Please avoid using it in high humidity area

to avoid damage!

COACH PRO Personal Wireless PA System

1. Instruction

Congratulations and thank you for purchasing this personal wireless PA system. To ensure a

trouble-free operation, please read the manual thoroughly to fully understand its controls and

functions.

This portable amplifier is divided into 2 major sections:

1. Control unit compartment on the rear panel

2. Battery compartment on the bottom

1-1. In the box

COACH PRO amplifier

0-1 handheld / beltpack transmitter

(optional)

Switching power supply

(plug varies from country to country)

operation manual

1-2. Optional related products

▍Transmitters

SQ-5116

Handheld microphone

SM-2016

Belt-pack transmitter

▍Accessories

ST-30

Tripod stand: standard

SB-61

Carrying bag

DM-series

Wired microphone, please refer

to CHIAYO website.

Control unit

compartment

Battery

compartment

Instruction

1-3. Parts and functions

1-4. Charging the battery

If the battery indicator turns solid RED, the battery might not be sustainable for long operation

and needs to be charged.

Battery low indicator Charging indicator

Charging indicator

Condition

Solid RED

During recharging

Solid GREEN

Fully charged

Wireless receiver volume

control (optional)

Wireless receiver channel

selector (optional)

Wireless receiver

ON/OFF indicator

AUX / MP3 player & recorder

volume control (optional)

Charging indicator

DC input jack

AUX OUT socket (6.3mm)

AUX IN socket (3.5mm)

MICROPHONE input (6.3mm)

Master power / MIC

volume control

Emergency alarm (2

sounds for selection)

Battery low indicator

ECHO control

Master volume control

TONE control

MP3 recorder player

Battery compartment

COACH PRO Personal Wireless PA System

1-5. Connection with external audio sources

USB disk

AMPLIFIER

Sound control, e.g., volume and

equalizer, of audio output from

COACH PRO is only operated

on this external amplifier.

TABLET / PHONE

WIRED MIC

Settings and Operations

2. Settings and Operations

2-1. Using the wired microphone (MIC IN)

1 Plug a wired microphone with a 6.3mm plug to MIC IN.

2 Turn ON master POWER and adjust MASTER volume to default level (12 o’clock).

Then adjust PWR/MIC volume control to desired level.

3 LOW-HIGH TONE and ECHO can be adjusted. (refer to P.12)

TONE ECHO

COACH PRO Personal Wireless PA System

2-2. Using the wireless receiver

1 Turn ON master POWER and WR VOL in order, the receiver’s power indicator will

glow RED. After turning ON the transmitter, this LED will turn GREEN.

2 Adjust MASTER volume to default level (12 o’clock). Then adjust WR VOL volume

control to desired level.

3 LOW-HIGH TONE and ECHO can be adjusted. (refer to P.12)

TONE ECHO

Power ON RED

Signal received GREEN

Settings and Operations

2-3. Music audio input (AUX IN)- Smart phone / tablet / MP3 player

1 Connect your device to the 3.5mm jack of AUX IN with a 3.5mm 3-pole stereo audio

cable.

2 Turn ON master POWER and adjust MASTER volume to default level (12 o’clock).

Then adjust AUX/USB volume control to a desired level.

3 LOW-HIGH TONE can be adjusted. (refer to P.12)

TONE
