Chevrolet Traverse 2012 Manual de usuario
Review this Quick Reference Guide for an overview of some important features in your Chevrolet
Traverse. More detailed information can be found in your Owner Manual. Some optional equipment
described in this guide may not be included in your vehicle.
If you have additional questions about the features and controls in your vehicle, press the blue OnStar
button to speak with a customer assistance representative who can provide more information.
2
Cruise Control
Buttons Instrument
Cluster Audio Steering
Wheel Controls✦
Instrument Panel Illumination
Control/Dome Lamp Off Button
Exterior Lamps
Control
Instrument Panel
StabiliTrak/
Traction Control
Charging System
Brake System
Security
Oil Pressure
Airbag Readiness
Engine Coolant
Temperature
Low Tire Pressure
Safety Belt Reminder
Check Engine or
Tighten Gas Cap
Cruise Control Set
Antilock Brake
System
Tilt/Telescopic Steering
Wheel Lever
Symbols
Turn Signal Lever/
Windshield Wipers Lever
3
Note: Refer to your Owner Manual to learn about the information being relayed by the lights, gauges
and indicators of the instrument cluster, as well as what to do to ensure safety and prevent damage.
See Instruments and Controls in your Owner Manual.
Driver
Information
Center Buttons✦
Audio System/
Navigation
System✦
Accessory
Power Outlet
Driver’s
Heated/Cooled
Seat Buttons✦
Rear Wiper Switch/
Traction Control Off Button/
Tow/Haul Mode Button✦/
Power Liftgate Switch✦
Climate
Controls
Hazard
Warning
Flashers Button
Passenger’s
Heated/Cooled
Seat Buttons✦
✦optional equipment
USB Port
(inside storage
compartment)
4
Driver’s Seat
A. Seat Fore/Aft Adjustment
Lift the handle under the front of the
seat to manually slide the seat forward
or rearward.
B. Seat Height Adjustment
Repeatedly rachet the lever on the
outboard side of the seat up to raise
the seat or down to lower the seat.
C. Seatback Recline Adjustment
Lift the lever on the lower outboard
side of the seatback (behind the safety
belt) to manually recline or raise the
seatback.
D. Lumbar Adjustment
Pull up/push down the lever on the
inboard side of the seatback to adjust
the amount of lumbar support.
A. Seat Adjustment
Move the horizontal control to move the
seat forward or rearward and to raise,
lower or tilt the seat.
B. Seatback Recline Adjustment
Move the vertical control to recline or
raise the seatback.
C. Lumbar Adjustment
Press the switch to adjust the amount
of lumbar support.
AB
Manual Driver’s Seat
C
Head Restraint
The head restraint is in a forward position to meet the Insurance Institute for Highway
Safety (IIHS) performance criteria for rear impacts.
• To raise the head restraint, pull it up.
• To lower the head restraint, press the release button on the head restraint post and
push it down.
See Seats and Restraints in your Owner Manual.
D
AB
Power Driver’s Seat (optional)
C
5
A
2nd-Row Seats
Slide the Seat
1. Make sure nothing is on the 2nd-row
seat or the floor in front of or behind
the seat.
2. Fold up the armrest(s).
3. Rotate the release lever (A) on the
upper-outboard side of the seatback
forward.
4. Push the top of the seatback forward.
The seat cushion will fold and the entire
seat will slide forward.
5. After entering/exiting, push the top of
the seatback rearward until the seat-
back and floor tracks lock.
6. Push down at the rear of the seat
cushion to lock it in place.
1. Make sure nothing is on the floor in
front of or behind the 2nd-row seat.
2. Pull outward on the handle (B) on the
outboard side of the seat cushion and
slide the seat forward or rearward.
3. Release the handle.
1. Make sure the seat is all the way
rearward (when folding the seat) and
the armrest(s) are upright.
2. Pull forward on the strap (C) on the
outboard side of the seatback.
3. Fold down or recline the seatback.
B
Fold/Recline the Seatback
C
See Seats and Restraints in your Owner Manual.
Enter or Exit the 3rd-Row Seats
6
Exterior/Interior Lighting
Off/On
AUTO Automatic Headlamp System
Activates the Daytime Running Lamps
(DRLs) in the daytime and the headlamps
and other exterior lamps at night or when
necessary.
Parking Lamps
Manual operation of the parking lamps.
Headlamps
Manual operation of the headlamps.
Instrument Panel Brightness
Turn the small knob to increase or
decrease the instrument panel lighting.
Turn the knob fully to turn on the dome
lamps when all doors are closed.
Dome Lamp Off
Press the button to turn off the dome
lamps. With the button depressed,
the dome lamps will not turn on
when a door is open.
Press the button again to have the dome
lamps turn on when a door is open.
See Lighting in your Owner Manual.
Automatic Headlamp System
Instrument Panel Lighting
Dome Lamp
7
Rear Seat Climate Controls
Front Seat Control
Press the REAR button (A) on the front
climate control panel to turn the rear
climate control system On or Off. The
button indicator will illuminate when the
rear system is On.
• The rear system operates in Mimic
Mode, with the rear settings the same
as the driver’s settings, when the
REAR button is pressed.
• The rear system operates in
Independent Mode when any of the
rear settings are adjusted using the
rear seat controls.
Air delivery modes:
Vent
Bi-level
Floor Temperature
controls
Fan controls
See Climate Controls in your Owner Manual.
Rear climate controls with rear seat audio (optional) shown.
Rear seat occupants can adjust the rear settings at any time by using the rear
controls, regardless of the front control panel REAR setting.
• To turn on the rear system, press any rear control.
• To turn off the rear system, turn the left knob to the Off position, or press the down
Fan Control repeatedly (rear climate controls with rear seat audio).
Dual automatic climate controls (optional) shown.
A
Rear Seat Control
8
Cruise Control
Set Cruise Control
1. Press the On/Off button. The
button indicator will illuminate when the
system is on.
2. When traveling at the desired speed,
press the SET– button to set the speed.
The Cruise Control symbol will
illuminate on the instrument cluster.
Adjust Cruise Control
RES+ Resume/Accelerate
Press to resume a set speed.
When the system is active, press to
increase speed.
SET– Set/Coast
When the system is active, press to
decrease speed.
Cancel
Press to cancel the cruise control
but retain the set speed in memory.
The cruise control set speed is erased
when cruise control or the vehicle ignition
is turned off.
See Driving and Operating in your Owner Manual.
9
Audio SteeringWheel Controls
(optional)
+–Volume
Pull up the + or – button to increase or
decrease the volume.
Next/Previous
Presstheupordownarrowtogotothe
next or previous favorite radio station,
CD track or DVD chapter (optional).
SRCE Source
Press to select an audio source.
Press and hold for one second to initiate
voice recognition on the navigation system
(optional).
Seek
Press to go to the next radio station on the
same band, CD track or DVD chapter
(optional).
Mute/Push to Talk
Press to mute the vehicle speakers.
Press and hold for two seconds to interact
with the OnStar or Bluetooth system.
End
Press to end or reject an OnStar or a
Bluetooth call.
Bluetooth
®
System (optional)
ABluetooth-enabled cell phone must be
paired with the in-vehicle Bluetooth system
before it can be used in the vehicle. Not all
phones will support all functions.
Visit www.gm.com/bluetooth for more
information.
See Instruments and Controls in your Owner Manual.
Note: An iPod®or a USB storage device
connected to the USB port, located in the
upper instrument panel storage compartment,
can be controlled using the audio controls.
10
RearWiper/Washer
Rear Wiper
Press the top of the switch to turn the rear
wiperonoroff.
Washer Fluid
Press the bottom of the switch to spray
washer fluid on the rear window.
See Instruments and Controls in your Owner Manual.
Power Liftgate
(optional)
Power Liftgate Switch
• Press the Power Liftgate OFF switch
to turn off the power liftgate. The
liftgate can only be operated manually
when the power liftgate switch is in the
Off position.
• Press the top of the Power Liftgate
switch to turn on the power liftgate.
Note: If the power liftgate does not open or
close, make sure the power liftgate switch is not
in the Off position.
Open/Close the Power Liftgate
• Press and hold the Power Liftgate
button on the Remote Keyless Entry
transmitter until the liftgate starts
moving.
• Press the top of the Power
Liftgate switch on the center console.
• Press the touchpad (A) above the
liftgate handle to open.
• Press the touchpad (B) next to the
liftgate latch to close.
See Keys, Doors and Windows in your Owner Manual.
AB
