TIME-OUT SETTING
Time-out is the time during which the
control unit is active, from when an opening
or closing order is given. This time must
always be longer than the opening-closing
time of the device being controlled. The
time-out ends after pressing the STOP
button or also after the time set.
From factory setting: 90 seconds. 2 sec
180 s
45 s
90 s
The control unit will keep this setting even after complete
memory clearing!
SWITCH
It is possible to run the motor through a switch connected to the
control unit with a wire (Optional switch).
The switch must be equipped with mechanical or electrical
interlock, to prevent two commands being sent simultaneously.
Furthermore, the switch must be an unstable pushbutton:
releasing it, the switch opens.
20
GB
OPERATION
Pressing one of the two buttons and releasing,
the motor drives to the desired direction until it
reaches the limits.
To stop the motor before
reaching the limits press
again the same button.
If during the movement
the other button is pressed
the motor changes the
direction.
STOP
