Chauvet DMX-2X Manual de usuario

World-wide Headquarters:

3000 North 29th Ct., Hollywood, Florida, USA, FL 33020

Tel: +1-954-929-1115 Fax: +1-954-929-5560

www.ChauvetLighting.com

TTWWOOWWAAYYDDMMXXDDIISSTTRRIIBBUUTTOORR

DMX-2X

User Guide

Please read these instructions carefully before use

Introduction

Congratulations on the purchase of your new Chauvet two way DMX distributor. We are confident that you will enjoy many trouble free

hours with this unit. To assist with the use and care of this unit, we have prepared this short guide.

Operation

The DMX-2X has a 110v/220v selector switch. You must ensure that it is set for the appropriate input voltage. The DMX-2x has one input

and two outputs. The inputs and outputs are electronically isolated. Each DMX output has a separate driver. Only one of the output jacks

from each pair can be used at any time. Each output has a polarity switch that is used when non-standard DMX fixtures are utilized

Note: The maximum number of DMX fixtures is 32 per output.

Cleaning

The body of the unit may be cleaned with a soft damp cloth. We recommend internal cleaning be carried out by a fully qualified technician.

Maintenance & Servicing

Work on internal parts should be carried out by a qualified technician. Removal of any covers other than the “Fuseholder” is considered a

breach of warranty an will not be covered under any such agreement unless authorized by CHAUVET.

No user serviceable parts inside, please refer to CHAUVET for service.

USA

Technical Assistance: 1-800-762-1084 (954) 929-1115

E-Mail [email protected]

POWER 120V~/60Hz / 230V~50Hz

INTERNAL FUSE 5mmx 20mm (x3) F500mA 250v

DIMENSION 10.04in x 6.76in x 2.95in 245mm x 165mm x 72mm

WEIGHT 4.18lbs / 1.9kg

User Information (Please complete for your records)

Date Purchased: / /

Serial No: ________________ Dealer Stamp

Model: DMX-2X Distributor
