Channel Vision 6401 Manual de usuario

CHANNEL VISION

Limited Warranty

Channel Vision Technology will repair or replace any defect in

material or workmanship which occurs during normal use of this

product with new or rebuilt parts, free of charge in the USA, for two

years from the date of original purchase. This is a no hassle warranty

with no mail in warranty card needed. This warranty does not cover

damages in shipment, failures caused by other products not supplied by

Channel Vision Technology, or failures due to accident, misuse, abuse,

or alteration of the equipment. This warranty is extended only to the

original purchaser, and a purchase receipt, invoice, or other proof of

original purchase date will be required before warranty repairs are

provided.

Mail in service can be obtained during the warranty period by calling

(800) 840-0288 toll free. A Return Authorization number must be

obtained in advance and can be marked on the outside of the shipping

carton.

This warranty gives you specific legal rights and you may have other

rights (which vary from state to state). If a problem with this product

develops during or after the warranty period, please contact Channel

Vision Technology, your dealer or any factory-authorized service

center.

500-0

7RevB

Color Mini Cone Camera

234 FISCHER AVENUE •C

(714) 424-6500 • (800) 840-0288 • (714) 424-6510 fax

www.channelvision.com • email: [email protected]

OSTA MESA, CA 92626

Model 6401

Model

6401

Coax extension

(not included)

Mounting hole

Dimensions

Power supply

(included)

To Monitor

Video distribution

Power

2-Conductor power

supply extension

(not included)

Crimp-on splice

connectors

(not included)

Video

(BNC Connector)

Installation:

Attach the camera mount to a flat surface using the

mounting hole shown above.

Drill a hole in the wall or ceiling for wiring (see diagram).

If necessary, attach the camera’s video output to a coax

extension that is long enough to reach your monitor or

video distribution equipment.

If necessary, cut the connector off of the end of the power

supply and splice in an extension using crimp-on

connectors.

Features:

1/3” Sharp Color CCD

380 Lines Of Resolution

0.4 Lux Sensitivity

3.8mm Lens

Power Supply Included

Mount Included

Ultra Compact Design

Specifications:

Camera Lens:

Resolution:

S/N Ratio:

Min Illumination:

Power Supply:

Power Consumption:

Video Output:

Dimensions:

Operating Temp:

3.8mm

380 lines

More than 48 dB

0.4 LUX @ F2.0

12VDC regulated

120 mA

1 Vp-p @ 75 ohms

(see diagram)

-10°C to 50°C (14°F to 122°F)

Specifications subject to change without notice.
