Chamberlain 890MAX Manual de usuario

3-BUTTON REMOTE CONTROLS

MODELS 890MAX, 893MAX, AND 895MAX

To prevent possible SERIOUS INJURY or

DEATH from a moving gate or garage door:

• ALWAYS keep remote controls out of

reach of children. NEVER permit children

to operate or play with remote controls.

• Activate gate or door ONLY when it can be

seen clearly, is properly adjusted and there

are no obstructions to door travel.

• ALWAYS keep gate or garage door in sight

until completely closed. NEVER permit

anyone to cross path of moving gate or

door.

LED

Locate the Program button on

the remote control.

Locate the Learn

button on the garage

door opener.

NOTE: Your garage door

opener may look different.

OR OR

Learn

LED Learn

LED

Learn

LED

Green

Red/Orange Purple Yellow

Program Button

2Press and release the remote control

button you wish to use the number of

times that corresponds with the garage

door opener type:

4Press and release the Learn

button on the garage door

opener.

3To exit programming mode,

press any remote control button

except the button that was just

programmed.

Install the visor clip

(not applicable for

Model 890MAX).

Press the remote control button

programmed in step 2 until the

garage door opener lights ﬂash

or two clicks are heard.

To test, press the programmed

button on the remote control...

Within 30 seconds...

The Learn LED will light.

Press and hold the program button

the remote control until the LED on

the front of the remote control turns on.

Safety Pin or

Paper Clip

Visor Clip

Learn

Button

# of Presses Garage Door Opener Type

Security+ 2.0TM (Yellow Learn Button)

315 MHz Security+®(Purple Learn Button)

390 MHz Security+®(Red/Orange Learn Button)

390 MHz Billion Code (Green Learn Button)

Click

The garage door

opener will activate.

MODEL 893MAX

MODEL 890MAX

PREPARE

PROGRAMMING THE REMOTE CONTROL

893MAX

890MAX

MODEL 895MAX

895MAX

LEDs

890MAX

895MAX

893MAX

Can be used as a replacement remote control for 80

Series, 970 Series, and 370 Series LiftMaster remote

controls.

Compatible with 315 MHz or 390 MHz garage door

openers manufactured after January 1, 1993. Make

sure the garage door opener has a working light bulb

because it is a programming indicator.

For use with gate operators, commercial door

operators, or other products that are 315 MHz or 390

MHz and have a Learn button. Refer to your product

manual for the location of the Learn button.

WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer or birth defects

or other reproductive harm. For more information go to www.P65Warnings.ca.gov

BATTERY

The LED(s) on your remote control will stop flashing when the battery is low and needs to be

replaced. To replace battery, open the case as shown. Insert battery positive side up (+). Replace

the battery with only 3V CR2032 or 3V CR2016 coin cell batteries (depending on the model).

Dispose of old battery properly. To prevent possible SERIOUS INJURY or

DEATH:

• NEVER allow small children near batteries.

• If battery is swallowed, immediately notify

doctor.

To reduce risk of fire, explosion or chemical

burn:

• Replace ONLY with 3V CR2032 or 3V

CR2016 coin batteries.

• DO NOT recharge, disassemble, heat

above 212° F (100° C) or incinerate.

1.800.528.9131

REPLACEMENT PARTS

3V CR2032 Lithium Battery (Models 893MAX & 890MAX). . . . . . . 10A20

3V CR2016 Lithium Battery (Model 895MAX) . . . . . . . . . . . . . . . . . 10A19

Visor Clip (Model 893MAX). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29B137

Visor Clip (Model 895MAX). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29C151

WARRANTY

LiftMaster.com

ONE YEAR LIMITED WARRANTY

LiftMaster warrants to the first consumer purchaser of this product that

it is free from defect in materials and/or workmanship for a period of 1

year from the date of purchase.

Pry open the case with a

screwdriver blade.

890MAX

Pry open the case ﬁrst in the

middle (1), then at each side

(2 and 3) with the visor clip.

893MAX

Remove the two screws

and open the case.

895MAX

3V CR2032 3V CR2016

Additional buttons on the remote control can be programmed to operate

up to 3 devices such as additional garage door openers, light controls,

gate operators or access control systems.

Press and hold the button down until the door or gate starts to move.

The remote control will operate from up to 3 car lengths away on typical

installations. Installations and conditions vary, contact an installing dealer

for more information.

HOW TO USE THE REMOTE CONTROL

NOTICE: To comply with FCC and or Industry Canada rules (IC),

adjustment or modifications of this receiver and/or transmitter

are prohibited, except for changing the code setting or replacing

the battery. THERE ARE NO OTHER USER SERVICEABLE

PARTS.

This device complies with Part 15 of the FCC rules and IC RSS-

210. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.
