INSTRUCTION MANUAL

#21057-DS

60AZ

WARNING

•Never look directly at the Sun with the naked eye or with a telescope (unless you have the proper solar filter). Permanent and irreversible eye

damage may result.

•Never use your telescope to project an image of the sun onto any surface. Internal heat build-up can damage the telescope and any accessories

attached to it.

•Never use an eyepiece solar filter or a Herschel wedge. Internal heat build-up inside the telescope can cause these devices to crack or break,

allowing unfiltered sunlight to pass through to the eye.

•Do not leave the telescope unsupervised, either when children are present or with adults who may not be familiar with the correct operating

procedures of your telescope.

SOME OF THE MANY STANDARD FEATURES OF THE

POWERSEEKER INCLUDE:

•All coated glass optical elements for clear, crisp images.

•Smooth functioning, rigid altazimuth mount with easy pointing to located objects.

•Preassembled aluminum tripod ensures a stable platform.

•Quick and easy no-tool set up.

•BONUS universal smartphone adapter (part #81060) for taking images of what you see!

•FREE Starry Night Software download with included code.

•FREE Sky Portal APP for your smartphone gives you an interactive map of the night sky.

•All models can be used terrestrially as well as astronomically with the standard accessories included.

INTRODUCTION

Congratulations on your purchase of a PowerSeeker 60AZ Telescope with Smartphone

Adapter. The PowerSeeker Series is made of the highest quality materials to ensure

stability and durability. All this adds up to a telescope that gives you a lifetime of

pleasure with a minimal amount of maintenance.

The PowerSeeker line of telescopes was designed for the ﬁrst time buyer offering

exceptional value. The PowerSeeker series features a compact and portable design with

ample optical performance to excite any newcomer to the world of amateur astronomy.

In addition, your PowerSeeker telescope is ideal for terrestrial observations which will

open your eyes with its superb high power viewing. PowerSeeker telescopes carry a

two year limited warranty. For details see our website at www.celestron.com.

Take time to read through this manual before embarking on your journey through the

Universe. It may take a few observing sessions to become familiar with your telescope,

so you should keep this manual handy until you have fully mastered your telescope’s

operation. The manual gives detailed information regarding each step as well as needed

reference material and helpful hints to make your observing experience simple and

pleasurable as possible.

Your telescope is designed to give you years of fun and rewarding observations.

However, there are a few things to consider before using your telescope that will

ensure your safety and protect your equipment.

Figure 1-1 PowerSeeker 60AZ Refractor

1 Objective Lens

2 Telescope Optical Tube

3 Finderscope

4 Eyepiece

5 Diagonal

6 Focus Knob

7 Altitude Slow Motion Rod Assembly

8 Accessory Tray

9 Tripod

10 Alt-Az Mount

11 Altitude Locking Knob

12 Azimuth Lock

13 Smartphone Adapter

ATTACHING THE TELESCOPE TUBE TO THE MOUNT

1 Objective Lens

2 Telescope Optical Tube

3 Finderscope

4 Eyepiece

5 Diagonal

6 Focus Knob

7 Altitude Slow Motion Rod Assembly

8 Accessory Tray

9 Tripod

10 Alt-Az Mount

11 Altitude Locking Knob

12 Azimuth Lock

13 Smartphone Adapter

ASSEMBLY

This section covers the assembly instructions for your PowerSeeker telescope. Your

telescope should be set up indoors the ﬁrst time so that it is easy to identify the

various parts and familiarize yourself with the correct assembly procedure before

attempting it outdoor.

Your PowerSeeker 60AZ telescope comes in one box. The pieces in the box are the

optical tube, altazimuth mount, 20mm eyepiece, 4mm eyepiece, 3x Barlow lens, erect

image diagonal, and a universal smartphone adapter.

SETTING UP THE TRIPOD

1. Remove the tripod from the box (Figure 2-1). The tripod

comes preassembled so that the set up is very easy.

2. Stand the tripod upright and pull the tripod legs apart

until each leg is fully extended and then push down

slightly on the tripod leg brace (Figure 2-2). The very top

of the tripod is called the tripod head.

3. Next, we will install the tripod accessory tray (Figure 2-3)

onto the tripod leg brace (center of Figure 2-2).

4. On the bottom of the tripod tray is a screw attached to

the center. The screw attaches into a threaded hole in

the center of the tripod leg brace by turning it clockwise.

NOTE: Pull up slightly on the tripod leg brace to

make it easy to attach.

Continue turning the tray until hand tight – don’t over

tighten the tray.

5. The tripod is now completely assembled (Figure 2-4).

6. You can extend the tripod legs to the height you desire.

At the lowest level, the height is about 27” (69 cm) and

extends to about 47” (119 cm). You unlock the tripod leg

lock knobs at the bottom of each leg (Figure 2-5) by

turning them counterclockwise and pull the legs out to

the height you want and then lock the knobs securely.

A fully extended tripod looks similar to the image in

Figure 2-6.

7. The tripod will be the most rigid and stable at the

lower heights.

Figure 2-4

Figure 2-2

Figure 2-3

Figure 2-5 Figure 2-6

Figure 2-3a

Figure 2-1

ATTACHING THE TELESCOPE TUBE TO THE MOUNT

MOVING THE TELESCOPE MANUALLY

The telescope optical tube attaches to the altazimuth mount with the

altitude slow motion rod assembly and the respective knobs. Before starting,

remove the objective lens cap. To mount the telescope tube to the mount:

1. Remove the protective paper covering the optical tube.

2. Put the telescope optical tube inside the yoke

(altazimuth) mount so that the altitude slow motion rod

assembly is on the same side as the altitude locking

screw (see Figure 1-1).

3. Thread the altitude locking knob out so the hole is clear

in the eyebolt (see Figure 2-8).

4. Put the rod of the assembly through the eyebolt and

then tighten the altitude locking knob – Figure 2-9.

5. Thread the two knobs (one on either side of the mount)

through the top of the mount into the threaded holes in

the optical tube and tighten – Figure 2-7.

The PowerSeeker Alt-Az mount is easy to move wherever you want to point it.

The up and down (altitude) is controlled by the altitude locking knob (Figure

2-12). The side-to-side (azimuth) is controlled by the azimuth lock knob (Figure

2-12). When both knobs are loose, you can ﬁnd your objects easily (through the

ﬁnderscope) and then lock the controls.

For ﬁne adjustments in altitude, you turn the knurled ring of the altitude slow

motion rod (when the altitude lock is tight) in either direction – see Figure 2-9.

NOTE: Before tightening the altitude locking knob, the location you are

seeking should be located in the ﬁnderscope.

Figure 2-12

Figure 2-7 Figure 2-8

Figure 2-9

ALT

INSTALLING THE DIAGONAL AND EYEPIECE (REFRACTOR)

INSTALLING AND USING THE BARLOW LENS

The diagonal is a prism that diverts light at a right angle to the light path of the

refractor. This allows you to observe in a position that is more comfortable than if you

had to look straight through. This diagonal is an erect image model that corrects the

image to be right side up and oriented correctly left-to-right which is much easier to

use for terrestrial observing. Also, the diagonal can be rotated to any position which is

most favorable for you. To install the diagonal and eyepiece:

1. Insert the small barrel of the diagonal into the 1.25”

eyepiece adapter of the focus tube on the refractor –

Figure 2-13. Make sure the two thumbscrews on the

eyepiece adapter do not protrude into the focuser tube

before installation and the plug-up cap is removed from

the eyepiece adapter. Once in place, tighten the

thumbscrews to hold the diagonal in place.

2. Put the chrome barrel end of one of the eyepieces into

the diagonal and tighten the thumb screw. Again, when

doing this make sure the thumbscrew is not protruding

into the diagonal before inserting the eyepiece.

3. The eyepieces can be changed to other focal lengths by

reversing the procedure in step 2 above.

Your telescope also comes with a 3x Barlow Lens which triples the magnifying

power of each eyepiece. To use the Barlow lens, remove the diagonal and insert

the Barlow directly into the focuser tube. You then insert an eyepiece into the

Barlow lens for viewing. You can also, insert the diagonal into the Barlow lens

and then use an eyepiece in the diagonal, but you may not be able to reach

focus with all eyepieces.

NOTE: Start by using a low power eyepiece as it will be easier to focus.

Figure 2-13

Figure 2-16

3x Barlow Lens

INSTALLING THE FINDERSCOPE

To install the ﬁnderscope:

1. Locate the ﬁnderscope (it will be mounted inside the ﬁnderscope bracket) –

see Figures 1-1 and 1-2.

2. Remove the knurled nuts on the threaded posts on the optical tube –

see Figure 2-17.

3. Mount the ﬁnderscope bracket by placing it over the posts protruding from

the optical tube and then holding it in place thread on the knurled nuts and

tightening them down.

4. Note that the ﬁnderscope should be oriented so that the larger diameter lens

is facing toward the front of the optical tube.

5. Remove the lens caps from both ends of the ﬁnderscope.

Figure 2-17

ALIGNING THE FINDERSCOPE

Use the following steps to align the ﬁnderscope:

1. Locate a distant daytime object and center it in a low power (20mm)

eyepiece in the main telescope.

2. Look through the ﬁnderscope (the eyepiece end of the ﬁnderscope) and

take notice of the position of the same object.

3. Without moving the main telescope, turn the adjustment thumb screws

located around the ﬁnderscope bracket until the crosshairs of the

ﬁnderscope are centered on the object chosen with the main telescope.

Eyepiece

Objective

Lens

Adjustment

Screws

Finderscope

Bracket

Figure 2-18

USING THE BASIC SMARTPHONE ADAPTER

1. Lift the bungee straps and slide your smartphone between the straps and the

adapter so that the camera is looking through the camera opening. The straps

should give plenty of tension to hold the device against the adapter and the

black rubberized surface will give enough friction to prevent the phone from

sliding around.

HINT: Depending on the design of your smartphone, the camera may be in

the middle of the device or in one corner. You may want to change

the angle of the bungee straps to better secure the phone. There

are six different anchor points to choose from around the edge of

the adapter. Simply reposition them to different anchor points to

achieve the best results.

2. Turn the adapter over and make sure your camera lens is centered in the

opening in the lens cap. The better you have this centered, the easier it will

be to take images through the telescope.

Product design and speciﬁcations are subject to change without

prior notiﬁcation.

Designed and intended for those 13 years of age and older.

For complete speciﬁcations and product information, visit: www.celestron.com

celestron.com/pages/technical-support

2835 Columbia Street • Torrance, CA 90503 USA

3. Take the 1.25” eyepiece and if necessary remove the rubber eyecup by pulling it straight

off the eyepiece body.

4. Loosen the set screws located on the eyepiece holder on the inside of the adapter. Place

the black portion of the eyepiece into the eyepiece holder and tighten the screws to

secure the eyepiece in place.

5. Now take the adapter with the phone and eyepiece attached and insert the chrome

barrel of the eyepiece into the diagonal on the back of the telescope’s focuser. Secure it

in place by tightening the set screws on the diagonal.

6. Activate your camera app on your smartphone and adjust the focus, just as you would

the eyepiece, this time using the image that appears on your screen.

NOTE: Make sure you turn the phone’s ﬂash off.

7. When the image appears sharp snap your image. It is best to try this in the daytime ﬁrst,

then, once everything is setup correctly, take it outside and try shooting the Moon. Once

you have practiced and are comfortable using the low power eyepieces, try using the

camera adapter with a more powerful eyepiece for higher magniﬁcation.

SPECIFICATIONS

Optical Design Refractor

Aperture (mm) 60mm (2.36”)

Focal Length (mm) 700mm (28”)

Optical Coatings Fully coated

Focal Ratio 12

Focal Length of Eyepiece 1 20mm (0.79”)

Magniﬁcation of Eyepiece 1 35x

Focal Length of Eyepiece 2 4mm (0.16”)

Magniﬁcation of Eyepiece 2 175x

Finderscope 5x24

Star Diagonal 1.25” Erect image diagonal

Highest Useful Magniﬁcation 142x

Limiting Stellar Magnitude 11.4

Resolution (Rayleigh) 2.32 Arc seconds

Resolution (Dawes) 1.93 Arc seconds

Light Gathering Power 73x

Optical Tube Length 711mm (28”)

Barlow Lens 3x

Star Diagonal 1.25” Erect image diagonal

Highest Useful Magniﬁcation 142x

Tube Color Black

Total Telescope Kit Weight 7 lb (3.18kg)

Software Starry Night Basic Software

Otros manuales para PowerSeeker 60AZ

Tabla de contenidos

Otros manuales de Telescopio de Celestron

Celestron

Celestron AstroMaster 130EQ Manual de usuario

Celestron

Celestron PowerSeeker 50 Manual de usuario

Celestron

Celestron NexStar SLT Series Manual de usuario

Celestron

Celestron StarSense Explorer DX Manual de usuario

Celestron

Celestron FirstScope 76EQ Hoja de especificaciones

Celestron

Celestron NexStar 60 Manual de usuario

Celestron

Celestron ROWE-ACKERMANN F/2.2 SCHMIDT ASTROGRAPH 36... Manual de usuario

Celestron

Celestron FirstScope 114 Manual de usuario

Celestron

Celestron PowerSeeker 70AZ Manual de usuario

Celestron

Celestron Travel Scope 60 Manual de usuario

Celestron

Celestron NexStar GPS 93507 Manual de usuario

Celestron

Celestron 60EQ Manual de usuario

Celestron

Celestron Travel Scope 50 Manual de usuario

Celestron

Celestron 114AZ-SR Manual de usuario

Celestron

Celestron Ultima 8 Manual de usuario

Celestron

Celestron NexStar 5 SE Manual de usuario

Celestron

Celestron 80LCM Manual de usuario

Celestron

Celestron advanced VX Series Manual de usuario

Celestron

Celestron StarSeeker Manual de usuario

Celestron

Celestron LandScout Manual de usuario

Celestron

Celestron POPULAR SCIENCE TRAVEL SCOPE 60 Manual de usuario

Celestron

Celestron NexStar 8 Manual de usuario

Celestron

Celestron ASTRO FI 22201 Manual de usuario

Celestron

Celestron PowerSeeker 114EQ Manual de usuario

Manuales populares de Telescopio de otras marcas

Meade

Meade 81005 Condor Manual de usuario

Meade

Meade 114 EQ-DS Manual de usuario

Meade

Meade LX200 CLASSIC Manual de usuario

Leica

Leica 82 HD Manual de usuario

EASTCOLIGHT

EASTCOLIGHT 9920 Manual de usuario

zoomion

zoomion Genesis 200 EQ Manual de usuario

TEC

TEC APO 140 Manual de usuario

Orion

Orion 7832 Manual de usuario

Carson

Carson Skelescope SK-100 Manual de usuario

SKY-WATCHER

SKY-WATCHER VIRTUOSO Manual de usuario

Orion

Orion EZ Finder 7228 Manual de usuario

cassini

cassini C-JRS Manual de usuario

nedis

nedis SCTE5060WT Manual de usuario

Meade

Meade Polaris 60EQ-D Manual de usuario

PlaneWave

PlaneWave CDK700 Manual de usuario

William Optics

William Optics Synta Crayford Manual de usuario

Orion

Orion FUNSCOPE Manual de usuario

Levenhuk

Levenhuk Skyline Travel Manual de usuario
