A22K
High Security Access Control
2-Door/4-Reader Module
ENCRYPTED
FULLY
2cdvigroup.com
A22K
High Security Access Control 2-Door Module
Copyright (C) 2019 CDVI. All rights reserved. ATRIUM Access Control is protected by copyright law and international treaties.
Unauthorized reproduction or distribution of this product, or any portion of it, may result in severe civil and criminal penalties,
and will be prosecuted to the maximum extent possible under law.
All other brand and product names are trademarks or registered trademarks of their respective companies.
The information contained in this publication is subject to change without notice.
1] PRODUCT PRESENTATION........................................................3
2] NOTES AND RECOMMENDATIONS..................................................6
FCC & IC Compliance ......................................................... 6
UL Compliance.............................................................. 6
UL 294 Compliance Notice ..................................................... 6
Free Technical Support ........................................................ 6
Recommended Wiring......................................................... 7
Specications .............................................................. 7
3] PACKAGE CONTENTS ............................................................9
Location and Mounting ....................................................... 10
4] MOUNTING INSTRUCTIONS .....................................................11
Installing the Tamper Switches ................................................. 11
Installing the box lock ....................................................... 14
Fixing the Box to its Location .................................................. 15
Installing the A22K PC board .................................................. 16
5] WIRING DIAGRAM .............................................................15
A22K NETWORK Connectivity wiring diagram ....................................... 16
Box Tamper Switches ........................................................ 18
Readers and Keypads ........................................................ 19
Inputs ................................................................. 21
Door Lock Devices .......................................................... 24
Power supply.............................................................. 26
Battery Backup ............................................................ 29
LED Indicators............................................................. 30
Ethernet Network Connection & RS485 BUS ........................................ 31
Reset to Factory Default ...................................................... 33
RS485 BUS Topologies ....................................................... 34
System Overview........................................................... 35
6] PROGRAMMING ...............................................................36
Card Enrollment Procedure (Add or Delete Cards without a computer). ..................... 36
7] WARRANTY - TERMS & CONDITIONS .............................................37
Thank you for buying our products and for
3
cdvigroup.com
A22K
High Security Access Control 2-Door Module
1] PRODUCT PRESENTATION
The A22K is ATRIUM’s powerful Web-Based high security module. The exibility of the A22K module allows it
to be set either as a 2-door controller or expander (2 in 1). The A22K includes an embedded web server that
combines performance and simplicity enabling you to manage Users/Cards, lock or unlock doors, view and print
system events and display controller information from any place in the world! Industry-unique and eortless
card enrollment mode minimizes system start up and simplies your life. A pre-assembled universal power
supply is included with every A22K making this unit an industry leader in eciency and simplicity.
(Wiegand or Auto-recognition High Security RS485 port)
ENCRYPTED
FULLY
4cdvigroup.com
A22K
High Security Access Control 2-Door Module
D1
D0
GND
12V
USB Backup Port
(Future use for disaster
recovery, user photos &
video clips)
New Microprocessor
•HTTPS enabled
• IPV6 ready
Increased Memory
Provides space for future
expansion and integration
CDVI Encryption
• RS-485 encrypted reader BUS using CDVI KRYPTO reader
• Supports 2 readers per port (Entry/Exit)
• OSDP-2 Compatible
AES 256 Encryption
Military grade Ethernet Port
AES 128 Encryption
(using Mifare DESFire EV2 card)
SSL/TLS
ENCRYPTION
A22K
ENCRYPTED 2-DOOR / 4-READER IP CONTROLLER
WHAT’S NEW
• CompatiblewithATRIUMA22Kcontroller
• FULLYsecureRS-485connection(4wires)
• Reads13.56MHzMifare®ClassicandDESFireEV1/EV2
• OSDP-2compatible
• NFCcompatible(mobilecredentialready)
• Upto10cm(4in)readrange
• Powerrequirements:12VDC
K1
KRYPTOHighSecurityCardReader
WARRANTY
YEAR
5
5
cdvigroup.com
A22K
High Security Access Control 2-Door Module
LAN or WAN RS485(4wires)IP(Ethernet)
A22K
ATRIUMController
K1
KRYPTOCardReader
TAG-EV2
MifareDESFireEV2
AES256
ENCRYPTION
AES256
ENCRYPTION
Say“NO”tocardcloningwithATRIUM’suniqueKRYPTOhighsecuritysolution.Eliminatecomplexandarduous
programmingusingtheATRIUMA22Kcontroller,CDVIMifareDesFireEV2credentialsandK1readers.
System-wideAESencryptionstopscardcloningandprovidesend-to-endsecurity.Whetheryouremoteinfrom
theinternetorconnectonyournetworkyoucanbesureKRYPTOhasyoucovered.
SSL/TLS
ENCRYPTION AES128
ENCRYPTION
Instant
High Security
Out of the Box
6cdvigroup.com
A22K
High Security Access Control 2-Door Module
2] NOTES AND RECOMMENDATIONS
This device complies with Part 15 of the FCC rules Class A. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received
including interference that may cause undesired operation. This class A digital apparatus meets all requirements
of the Canadian Interference Causing Equipment Regulations. The ATRIUM A22K is also compliant with
EN55022:1998, amendment 1:1995, Class A.
To comply with UL listings, the following requirements must be met:
• Use of UL listed readers
• Use of a UL recognized tamper switch on every housing cabinet for the A22K
• Use only UL listed cables
• Use only UL listed adaptors
Note: All circuits are power limited.
CDVI declared the following levels: Destructive Attack Level I, Line Security Level IV, Endurance Level IV,
Standby Power Level IV.
• Use only UL listed power supply
• Connect CDVI LED status indicator, part number 7020-0001-0000, to the DC Input gray terminals of
the A22K.
Backup battery provides operation of up to 12 hours but has been tested for 4 hours per Section 33 of
UL 294, fth edition.
The system’s location and wiring methods shall be in accordance with the National Electrical Code,
ANSI/NFPA 70.
For technical support in Canada or the U.S., call 1-866-610-0102, Monday to Friday from 8:00 a.m. to 8:00
p.m. EST. For technical support in your area, refer to the last page of this document or visit our website: www.
cdvigroup.com.
7
cdvigroup.com
A22K
High Security Access Control 2-Door Module
RECOMMENDED WIRING
Wire Type
RS485 Card Reader
(High Security Reader) 4 conductors, copper 26AWG (0.40mm) to
18AWG (1.02 mm) 1220m (4000ft.)
Wiegand card reader
and keypad
4 to 8 conductors, stranded, shielded (foil), drain
conductor. For example: Alpha 5196, 5198, 5386,
5388, Belden 9553
22AWG (0.64mm) to
18AWG (1.02mm) 150m (500ft.)
Zone input 2 conductors, copper 22AWG (0.64mm) 22AWG (0.64mm) 600m (2000ft.)
Door strike 2 conductors, solid copper 18AWG (1.02mm) 18AWG (1.02mm) 150m (500ft.)
Power Supply* 3 conductors, solid copper 18AWG (1.02mm) 14AWG (1.63mm)* 8m (25ft.)
Ethernet CAT 5/5e - 100m (300ft)
RS485 bus, Star or
Daisy Chain (no BIAS/
EOL required)
CAT 5/5e or 4 pairs 24AWG (0.51mm)
1220m (4000ft.)
4 conductors, copper 26AWG (0.40mm) to
18AWG (1.02 mm)
* The Minimum Size Equipment Conductors for the AC mains required are 14 AWG if made of Copper or 12
AWG if made of Aluminium or Copper-Clad Aluminium. Do not use any switch-controlled outlets to power the
system.
Doors 2 (expandable to 10 doors)
Cards / users 10,000 cards / users
Schedules 250 Schedules each supporting up to 100 time periods (dd, hh:mm)
Buered Events 25,000 events
Holidays 100 holidays
Access Levels 1000 access levels
Operating Temperature -20°C to +70°C (-4°F to +158°F)
Humidity 0% to 85% (non condensing)
System Autonomy Full Distributed Architecture (100% O-line Operation)
Firmware Online Upgradeable
PCB Dimensions 19.9cm (7.83”) x 12.38 cm (4.875”)
Cabinet Dimensions 29 cm (11.4”) high, 28 cm (11”) wide, 8 cm (3.15”) deep
Inputs
Readers
2 x Wiegand Readers with Multiple Protocol Support (Wiegand 26-bit, 30-bit & 44-bit)
or
4 x Auto-recognition High Security RS485 ports (if set as entry/exit door)
Keypads 2 x Wiegand Keypad with Multiple Protocol Support (Wiegand 8-bit & 26-bit)
Multi-Purpose Inputs 6 zone inputs (up to 12 using ZONE DOUBLING) supporting individual WIRE CUT &
WIRE SHORT supervision.
Box Tamper Normally Closed (N.C.) contact
8cdvigroup.com
A22K
High Security Access Control 2-Door Module
LOCAL BUS RS485 @ 57600Baud supporting star and/or daisy chain topologies up to 4000ft (1220 meters)
ETHERNET 10/100 Base-T, Auto Sensing, 100m(300ft)
AC Power 120-240Vac
Frequency 50Hz/60Hz
Output 24Vdc, 2.5A
AC Terminal Fuse 250Vac, 2.5 A, Time Lag, Slow Blow, Operating Temperature: -55oC to +125oC
Power Loss Indicator Yes (DC IN)
Do Not Connect to a Receptacle Controlled by a Switch.
Other 24Vac, 75VA 50/60Hz UL/ULC certied transformer can be used.
LK1, LK2 12Vdc @ 750mA
AUX 12Vdc @ 1A
Battery Against reversal, short, current limited/monitored
Battery Backup
Battery Capacity One 12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12
recommended, Europe: CDVI B7AH recommended). Ensure proper polarity.
Charging Current 250mA (default), 500mA, or 1A. Refer to the ATRIUM system manual to modify the battery
charging current.
Low Battery @ 11.8Vdc
Low Battery Restore @ 12.2Vdc
Low Battery Cut-O @ 10.5Vdc
Lock Output LK1 Maximum Current 750mA each
Lock Output LK2
Reader 1
Maximum Current 1000mA
Reader 2
Zone Inputs
LOCAL BUS
Outputs
RLY1, RLY2 Form C Relay, 5A @ 250Vac, 7A @ 125Vac, 7A @ 30Vdc
9
cdvigroup.com
A22K
High Security Access Control 2-Door Module
3] PACKAGE CONTENTS
This chapter details how to install and setup the ATRIUM A22K .
The A22K contains:
• One A22K module in its cabinet with connection diagram label
• Pre-assembled universal power supply with AC power cord plug
• USB Key (Software)
• Programming and master cards
• Credentials (pack of 25)
• Metal Box kit (See below)
• Installation kit (See below)
Kit
and
Bolts and Nuts
Spacer
Support
enclosure
lock and key
1 3 2 each 1 1 1 4 1
Installation
Kit
Red and black
backup battery
1K Resistor 2.2K Resistor
for DC door
strikes or
door strikes or
(PCB Holder)
1 pair 22 10 2 2 7
If any item is missing, please notify your distributor immediately.
10 cdvigroup.com
A22K
High Security Access Control 2-Door Module
The cabinet is designed to be installed indoors, in a safe and secure location. Suggested locations include
electrical rooms, communication equipment rooms, closets or in the ceiling. To save time, wiring and facilitate
testing, install the cabinets at an equal distance between its controlled doors. Normal temperature and humidity
levels should be maintained.
Please note that other approved cabinets with approved tamper switch on the front cover and rear
surface can be used.
Cabinet Dimensions:
29 cm (11.4”) high, 28 cm (11”) wide, 8 cm (3.15”) deep
The Cabinet Can Accommodate:
One 12Vdc @ 4.5AH or 7AH, gel cell type batteries and wiring connections (15cm (6”) high,
6cm (2.5”) wide, 9 cm (3.54”) deep)
Battery Model Capacity Width Height
YUASA #NP7-12 12 Volt 7 Ah 151mm (5.94”) 65mm (2.56”) 97.5mm (3.84”)
YUASA #NP4-12 12 Volt 4.5 Ah 90mm(3.54”) 70mm (2.76”) 106mm (4.17”)
Multiple Conduit Knock-outs:
Two 19.05mm (0.75”) on each side and one 12.7mm (0.5”) on top
Minimum Clearance For Cabinet:
25cm (10”) clear space around all sides
38cm (15”) clear space in front of cabinet
Minimum Clearance From Electrical Interference:
2.4m (8ft.) from high voltage equipment or wiring and from electrical equipment likely to
generate interference
1.2m (4ft.) from telephone equipment or lines and 8m (25ft.) from transmitting equipment
The system’s location and wiring methods shall be in accordance with the National Electrical Code,
ANSI/NFPA 70.
Otros manuales para ATRIUM A22K
4
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Unidad de control de CDVI
Manuales populares de Unidad de control de otras marcas
Festo
Festo Compact Performance CP-FB6-E Manual de lista de piezas
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manual de usuario
JS Automation
JS Automation MPC3034A Manual de usuario
JAUDT
JAUDT SW GII 6406 Series Guía rápida
Spektrum
Spektrum Air Module System Manual de usuario
BOC Edwards
BOC Edwards Q Series Manual de usuario
