CDI6371

Integrated dishwasher

Use and maintenance

Contents

3 Important information and notes

6 Recommendations and before ﬁrst use

7 Control panel

7 Selecting a programme and feature information

9 Starting a programme

10 Changing and cancelling programme

11 Buzzer sound control

11 Save Power mode

12 Detergent information

14 Salt information

15 Softener adjustment

17 Direct wash feature

18 Rinse aid

20 Dishwasher basket information

20 Loading information

21 Adjustable racks and cutlery tray information

22 Standard loading and test data

23 Programme listing

24 Care and Maintenance

26 Error codes

27 Troubleshooting

28 Electrical Information

30 Installation

32 Installation diagrams

33 Fitting a non-standard decor door (additional to template)

34 Warranty and service

Important

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

EU Declarations of Conformity:

This product meets the requirements of all applicable EU directives

with the corresponding harmonised standards, which provide for CE

marking.

Availability of this manual in an alternative format:

A soft copy of this manual is available for download from www.cda.eu.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services. Disposing of a household appliance

separately avoids possible negative consequences for the

environment and health. It also enables the constituent materials to

be recovered, saving both energy and resources. As a reminder of

the need to dispose of household appliances separately, the product

is marked with a crossed-out wheeled dustbin.

Please note:

•Read the instructions prior to installation and use of the

appliance.

•Do not lean or climb on the open dishwasher door to

prevent damage.

•Close the dishwasher door after use to prevent accidents.

•Use only detergents, salt and rinse aid speciﬁcally

designed for dishwashers.

•Do not put solvents in the dishwasher detergent

compartment to prevent risk of explosion

•Only put dishwasher safe items into the dishwasher. If in

doubt, check with the manufacturer of the items.

•Take care when loading the dishwasher to observe the

recommendations for best loading practice, and also to

ensure that sharp objects such as knives are placed blade

down to prevent accidents.

•Do not open the dishwasher door when a programme

is running. If it is necessary to do so, then open it only

slightly to allow the dishwasher to pause the programme

and prevent any water spilling out. Remember that

the water in the dishwasher can be very hot when the

programme is running.

•When the dishwasher is not in use, we recommend

that you turn o the water supply at the supply tap and

disconnect the mains supply.

•If you are leaving the dishwasher for an extended period

you should leave the door slightly open to prevent the

formation of unpleasant smells.

•The plastic housing on the water inlet pipe contains an

electrically operated valve. The wires that connect to this

valve are inside the inlet hose. Do not cut through the

inlet hose, and do not put the plastic housing in water.

•Children could get locked inside the appliance. Therefore

when disposing of an old appliance, cut o the plug and

set aside, and damage the door lock so that the door can

no longer be closed.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

Recommendations

•To reduce energy and water consumption, remove all dirt residues

from the dishes prior to loading the dishwasher.

•Loading the dishwasher to the capacity indicated by the

manufacturer will save energy and water.

•Place hollow items (bowls, glasses and pans) face down in the basket.

•Do not put dishes, cutlery or other items with tobacco ash, wax,

lubricating grease or paint residues in the dishwasher.

• It is not recommended to pre-rinse the tableware, as this leads to an

increase in water and energy consumption.

• Washing tableware in a household dishwasher usually uses less

energy and water than washing up by hand.

Before ﬁrst use

•Remove all the packaging materials from the interior of the dishwasher.

•Set the water softener level as required by the water hardness in the

area (page 16).

•Add 1kg of salt into the salt compartment and then ﬁll with water to the

top of the salt compartment.

•Fill the rinse aid compartment (page 18).

•Run a hot programme without any dishes in the dishwasher.

Control Panel

Programme display (1)

The programme display shows the selected programme and the

remaining time to run. If there is a fault on the dishwasher, the fault

code will show on the display.

On/O button (2)

• To switch the dishwasher on or o, press the On/O button. When

you switch on the dishwasher, two dashes appear on the display.

Please note: The interior light will work automatically when the

dishwasher is switched on.

Programme selection button (3)

• To select a programme, press the programme selection button (3).

The dishwasher will store in its memory the last programme used.

Half Load Button (4)

•Press the Half Load button to select the area of the dishwasher

that contains the dishes to be washed. You can select both

baskets, the upper basket only, or the lower basket only.

12 3 4 5 6 7 8

C60

Upper basket Lower basket Extra Silent

Extra Fast

Extra Drying

2345678

Fig. 1

Press the button until the LED (9) corresponding to the basket

contaning the dishes to be washed illuminates. Dishes in other

areas will not be washed. For more info see page 17.

Delay timer indicator (5)

The dishwasher is equipped with a variable timer of up to 19 hours

duration at hourly intervals.

• To set the delay timer, press the delay timer button (5). This will

switch the timer on for one hour.

• To change the delay duration, press the delay timer button again

until the required delay duration is shown on the display.

• To cancel the delay timer, press the delay timer button again

until the display counts down through 3-2-1 or alternatively turning

o the machine will cancel the delay timer.

Options button (6)

Press the Options button once to activate the Extra Silent option and

the corresponding LED (7) will illuminate. This will decrease the water

pressure, therefore providing a more sensitive and silent wash. This

option can only be selected at the beginning of a programme.

Pressing the Options button twice will activate the Extra Dry option

and the corresponding LED (7) will illuminate. Selecting the Extra Dry

option adds extra drying steps to a programme in order to obtain drier

dishes. This option increases the water temperature in the ﬁnal rinse

phase and increases the duration of the drying phase.

Pressing the Options button for a third time will activate the Extra Fast

option and the corresponding LED (7) will illuminate. Selecting the

Extra Fast option will reduce the programme duration. The washing

temperature and pressure will increase to ensure an improved

washing quality in a shorter duration. This option can only be selected

at the beginning of a programme.

Salt and rinse aid warning lights (8)

When the dishwasher salt or rinse aid begins to run out, the warning

light will illuminate to advise that it needs reﬁlling

Starting a programme

• Press the On/O button. The Display (3) will show ‘- - ‘

• Press the Programme Selection button until the required

programme is shown on the display.

• If required, set the delay timer by pressing the Delay Timer button

• Once a programme is selected, the end of programme light will

switch o.

• When you close the dishwasher door, the programme will start

automatically.

Additional information

To cancel the selection of any extra function, press the speciﬁc extra

function button until the indicator light for that function goes out.

At the end of a programme

If possible, do not open the dishwasher door once the programme

has started.

During the programmes cycle the InfoLed will illuminate a red light

underneath the appliance door on to the ﬂoor. Once the program has

ﬁnished the light illumination will be green.

Changing a programme

It is possible to change the programme if necessary once the

programme has started.

• First open the door slightly to reduce the risk of water spillage.

• Press the Programme Selection button until the required

programme is shown on the display.

• Then close the door. The dishwasher will begin the new

programme from the point at which the old programme stopped.

Cancelling a programme

It is possible to cancel the programme once is has started.

• First open the door slightly to reduce the risk of water spillage.

• Press and hold in the Programme Selection button until the display

shows 1, then close the door.

• The dishwasher will run a drain cycle which will take approximately

30 seconds. Once this is complete, the dishwasher will beep 5

times.

Switching the dishwasher o

• Once the dishwasher beeps and the end of programme light

switches on, the dishwasher can be switched o by pressing and

holding the On/O button for 3 seconds.

• Then turn o the water tap and remove the plug from the power

socket.

Please note: the dishwasher will automatically continue on the

programme it has started if the door is opened and closed or in the

event of a power cut.

Tabla de contenidos

Otros manuales de Lavavajillas de CDA

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario
