The BT-505 is a dual-mode(BR/EDR + Low Energy) USB Adapter and using Realtek
RTL8761BUV chip complies with Bluetooth 5. It combines a BT Protocol Stack for LM,
LL, L2CAP, GATT, RFCOMM, SPP and LE.
The BT-505 is compatible with previous versions, including v2.1 + LE. For BR/EDR, it
allows multiple avtive links in either slave mode or master mode. For Low Energy, it
supports multiple states and allows multiple active links in slave mode. A BR/EDR link
and an LE link can be active at the same time.
CC&C
TECHNOLOGIES
8F, No. 150, Jian Yi Road,
Zhonghe District,
New Taipei City,
Taiwan 235, R.O.C.
Tel : 886-2-8226 5088
Fax : 886-2-8226 5077
Specificationsaresubjecttochangewithoutnotice
FEATURES
Bluetooth 5 specification compliant
Supports Bluetooth classic (BR/EDR)
Supports Bluetooth Low Energy (BLE)
Single-end RF radio output with high performance up to
10dBm
Supports Power Control
Fast AGC control to improve receiving dynamic range
SPECIFICATIONS Model Name BT-505
Product Name Bluetooth5.0Dual‐modeDongle
Standard Bluetooth 5 dual mode
Frequency Band 2.4~2.4835GHz unlicensed ISM band
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)
Transfer Rates 2Mbps data rate
RF Output Power Up to +10 dBm
Sensitivity TBD
Input power DC 5V (via USB Port)
I/O Interface
USB
LED Indicator Configurable
OS Support Linux
Environment Operation temperature: 0 ~
+ 60 degree
Environment
Size
Storage temperature: -20 ~ +70 degree
Humidity: 5 ~ 90% non-condensing
22.3 x 15 x 8 mm (L x W x H)
