Casio EX-M20 - 2 Manual de usuario

PLAYBACK

Use [] (forward) or [] (back) to scroll

through files on the monitor screen.

NOTES

•Holding down [] or [] scrolls images at high

speed.

•In order to allow for faster playback image scrolling,

the image that initially appears on the monitor screen

is a preview image, which is of somewhat lower

quality than the actual display image. The actual

display image appears a short while after the preview

image. This does not apply to images copied from

another digital camera.

You can use the camera’s built-in monitor screen to view

images after you record them.

Basic Playback Operation

Use the following procedure to scroll through files stored in

the camera’s memory.

Press the power button

to turn on the camera.

•This causes an image or a

message to appear on the

monitor screen.

Align the mode selector

with “ ” (PLAY).

•This enters the PLAY

mode.

Power button

Mode selector

ON/OFF

PLAYBACK

Playing an Audio Snapshot (EX-M20 Only)

Perform the steps below to display an audio snapshot

(indicated by a indicator) and play its audio.

In the PLAY mode, use [] and [] until the

image you want is displayed.

Press [SET].

•This plays back the

audio that accompanies

the displayed image.

•You can perform the

following operations

while audio is playing.

IMPORTANT!

•Audio volume can be adjusted only when playback is

being performed or is paused.

•When you have the LCD remote controller connected

to the camera, audio is output through the stereo

headphones (page 160) instead of the camera’s

speaker. Output through the headphones is

monaural.

•The volume of audio recorded with the camera

cannot be adjusted using the LCD remote controller.

Use the camera’s controller to adjust volume level in

this case.

To do this:

Fast forward or fast reverse

the audio

Pause and unpause audio

playback

Adjust audio volume

Cancel playback

Do this:

Hod down [] or [].

Press [SET].

Press [] or [].

Press [MENU].

PLAYBACK

DISP

Flipping the Display

The following procedure flips the image 180 degrees. This

comes in handy when you want to show someone standing

in front of you an image on the monitor screen.

In the PLAY mode, use [] and [] to scroll

through images on the monitor screen and

display the one you want.

Press the shutter release button and [SET] at

the same time.

•This flips the image 180 degrees. The histogram or

any other display information you had displayed is

cleared automatically whenever you flip the image.

•While an image is flipped, you can use [] and [] to

scroll to another image, if you want.

To return the image to its normal orientation,

press any button other than [], [], [], or

[].

IMPORTANT!

•Note that you cannot play a movie, an audio

snapshot (EX-M20 only), or a voice recording file

(EX-M20 only) on the monitor screen while a flipped

image is displayed.

•You cannot use the above procedure to flip an image

while a zoomed image, calendar screen image, a

movie image, an audio snapshot (EX-M20 only), or a

voice recording file image (EX-M20 only) is on the

display.

[SET]

Shutter release

button

PLAYBACK

To scroll the image

on the display, press

[SET], and then press

[], [], [], or [].

•To display the indicator

for further zooming,

press [SET] again.

Press [MENU] to return the image to its

original size.

IMPORTANT!

•You cannot enlarge a movie image.

•Depending on the original size of the recorded

image, you may not be able to zoom a display image

the full four times its normal size.

Zooming the Display Image

Perform the following procedure to zoom the image

currently on the monitor screen up to four times its normal

size.

In the PLAY mode, use [] and [] to display

the image you want.

Press [] ( ) to

enlarge the image.

•This displays an

indicator that shows the

current zoom factor.

Current zoom factor

PLAYBACK

Resizing an Image

You can use the following procedure to change a snapshot

image to either SXGA size (1280 x 960 pixels) or VGA size

(640 x 480 pixels).

•VGA is the optimum image size for attachment to e-mail

messages or incorporation into Web pages.

In the PLAY mode, press [MENU].

Select the “PLAY”

tab, select “Resize”,

and then press [].

Use [] and [] to scroll through images and

display the one you want to resize.

IMPORTANT!

•Resizing an image creates a new file that contains

the image in the size you select. The file with the

original image also remains in memory.

•Images smaller than 640 x 480 pixels cannot be

resized.

•An image recorded using the 1600 x 1072 (3:2) pixel

size cannot be resized.

•Note that you can resize snapshots recorded with

this camera only.

•If the message “This function is not supported for this

file.”appears, it means that the current image cannot

be resized.

•The resize operation cannot be performed if there is

not enough memory to store the resized image.

Use [] and [] to select the setting you

want, and then press [SET].

To do this:

Resize to 1280 x 960 pixels (SXGA)

Resize to 640 x 480 pixels (VGA)

Cancel the resizing operation

Select this:

1280 x 960

640 x 480

Cancel

PLAYBACK

Cropping an Image

Use the following procedure when you want to crop a

portion of an enlarged image and use the remaining part of

the image as an e-mail attachment, Web page image, etc.

In the PLAY mode, use [] and [] to scroll

through images and display the one you want

to crop.

Press [MENU].

Select the “PLAY”

tab, select

“Trimming”, and then

press [].

•This causes a cropping

boundary to appear.

Use [] and [] to make the cropping

boundary smaller or larger.

•The size of the cropping boundary depends on the

size of the image on the display.

When the cropping

boundary is the size

you want, press [DISP]

to lock it.

•After pressing [DISP] to

lock the size of the

cropping boundary, you

can press [DISP] again to

unlock it. After that, you

can repeat steps 4 and 5

to change the cropping

boundary size.

Use [], [], [], and [] to move the

cropping boundary up, down, left, or right

until the area of the image you want to extract

is within the boundary.

Press [SET] to extract the part of the image

enclosed in the cropping boundary.

•If you want to cancel the procedure at any point,

press [MENU].

PLAYBACK

Playing a Movie

Use the following procedure to play back a movie that was

recorded in the movie mode.

In the PLAY mode,

press [] and [] to

scroll through images

until the movie you

want to play is

displayed.

Press [SET].

•This start playback of the movie.

Movie icon

IMPORTANT!

•Cropping an image creates a new file that contains

the cropped image. The file with the original image

also remains in memory.

•An image recorded using the 1600 x 1072 (3:2) pixel

size cannot be cropped.

•Movie and voice recording file images (EX-M20 only)

cannot be cropped.

•An image recorded using another camera model

cannot be cropped.

•If the message “This function is not supported for this

file.”appears, it means that the current image cannot

be cropped.

•The cropping operation cannot be performed if there

is not enough memory to store the cropped image.

PLAYBACK

IMPORTANT!

•You cannot repeat play a movie. To play a movie

more than once, repeat the steps of the above

procedure.

•The EX-M20 can also play back audio recordings.

Note the following points when playing back audio.

—Audio volume can be adjusted only when

playback is being performed or is paused.

—When you have the LCD remote controller

connected to the camera, audio is output through

the stereo headphones (page 160) instead of the

camera’s speaker. Output through the

headphones is monaural.

—The volume of audio recorded with the camera

cannot be adjusted using the LCD remote

controller. Use the camera’s controller to adjust

volume level in this case.

•You can perform the following operations while a

movie is playing.

To do this:

Fast forward or fast reverse

the movie

Pause and unpause movie

playback

Skip forward or back one

frame while paused

Cancel playback

Adjust audio volume

(EX-M20 only)

Do this:

Hold down [] or

[].

Press [SET].

Press [] or [].

Press [MENU].

Press [] or [].

PLAYBACK

•Pressing [] while the date selection cursor is

located anywhere in the top line of the calendar

causes the previous month to appear.

•Pressing [] while the date selection cursor is

located anywhere in the bottom line of the calendar

causes the next month to appear.

•To exit the calendar screen, press [MENU].

•is displayed in the calendar screen to indicate

voice recording file images (page 95, EX-M20 only).

•appears in place of the image when the date

contains data that cannot be displayed by this

camera.

To view the large version of a date’s image,

move the date selection cursor to the date,

and then press [SET].

•This displays the first image that was recorded on

the selected date.

Displaying the Calendar Screen

Use the following procedure to display a 1-month calendar.

While the calendar is on the display, you can select a date,

which displays the first image recorded on that date. This

helps to make it easy to find the images you want.

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Calendar”, and

then press [].

Use [], [], [], and

[] to move the date

selection cursor.

•Use the procedure

under “Changing the

Date Format”on page

120 to specify the date

format.

•The image displayed on

the calendar for each

date is the first image

that was recorded on

that date.

Month/Year

Date selection cursor

PLAYBACK

Use [] and [] to select “Start”, and then

press [SET].

•This starts the slide show.

To stop Slide Show, press [SET].

•The slideshow will also stop automatically after the

amount of time you specified for “Time”elapses.

Configure the slideshow settings.

•See the pages indicated below for more information.

For information about

configuring this setting:

Images

Time

Interval

Go here:

“To specify the slideshow

images”on page 88

“To specify the slideshow

time”on page 89

“To set the slideshow

interval”on page 90

Playing a Slide Show

Slide Show automatically plays back images in sequence

at a fixed interval.

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Slideshow”,

and then press [].

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Casio

Casio

Casio QV-700 Manual de usuario

Casio

Casio EXILIM EX-ZS10 Manual de usuario

Casio

Casio Exilim EX-Z4U Manual de instrucciones y seguridad

Casio

Casio EX-TR10 Manual de usuario

Casio

Casio QV-3000Ir Manual de usuario

Casio

Casio Exilim EX-Z750 Manual de usuario

Casio

Casio QV-2000UX/Ir Manual de usuario

Casio

Casio QV-3500EX Manual de usuario

Casio

Casio QV-R40 Manual de usuario

Casio

Casio QV-3000EX/Ir Manual de usuario

Casio

Casio EX-Z800BE Manual de usuario

Casio

Casio LV-10 Manual de usuario

Casio

Casio Exilim EX-FH100 Manual de usuario

Casio

Casio EXILIM EX-Z16 Manual de usuario

Casio

Casio Exilim EX-Z60 Manual de usuario

Casio

Casio EX-Z100BE - EXILIM ZOOM Digital Camera Manual de usuario

Casio

Casio EXILIM EX-S9 Manual de usuario

Casio

Casio EX-M1 - EXILIM Digital Camera Manual de programación

Casio

Casio GZE-1 Manual de usuario

Casio

Casio EXILIM K860PCM1DMX Manual de usuario

Casio

Casio EXILIM Exilim EX Z 2 Manual de usuario

Casio

Casio QV-770 Manual de usuario

Casio

Casio EX-Z550BE Manual del propietario

Casio

Casio EX-TR60 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
