CAS CI-2001A Manual de usuario
CI-2001A/B
Weighing Indicator
OWNER’S MANUAL
CONTENTS
PRECAUTIONS 4
INTRODUCTION 6
THE FEATURES OF CI-2001A/B 6
TECHNICAL SPECIFICATION 7
DIMENSIONS 8
FRONT PANEL(CI-2001A) 9
FRONT PANEL(CI-2001B) 11
REAR PANEL 13
INSTALLATION 14
TEST MODE 15
CALIBRATION MODE 18
SET MODE 21
SERIAL INTERFACE 25
ERROR MESSAGE AND
TROUBLE SHOOTING 29
4
PRECAUTIONS
Place the indicator on a flat and stable
surface. Do not use inflammable materials in
cleaning.
Do not severely press because the light
pressing of keys can incite the operation. Keep the main body from rain and
keep in dry area.
5
Do not subject the scale to sudden
temperature changes.
Keep the scale away from strong EMI noises may cause incorrect weight
readings.
6
INTRODUCTION
THE FEATURES OF CI-2001A/B
We greatly appreciate your purchase of the CAS industrial indicator. These
goods perform excellently and exhibit splendid properties through strike tests.
CAS indicator (CI-series) is delicately designed to coincide with the special
requirements of several industrial fields and includes many functions and various
external interfaces. Also, it is programmed for the user's convenience and
contains help display functions that are easily accessible.
Before using CI-2001A/B, It is recommended that you read this manual
carefully so you may use this device to its full potential.
1. Features
Appropriate for weight and measurement system.
Easy operation and various options.
Simple full digital calibration.
(SPACTM : single pass automatic span calibration)
WATCHDOG circuitry (system restoration).
Weight back-up (power on actual weight).
Wall mount type (CI-2001A/B) - standard
Panel mount type (CI-2001A/B(P)) - optional
2. Main Function
Various specification of weight conversion speed. (Digital Filter Function)
Various printer connection. (RS232 Serial printer - optional)
Users can set the max. weight which users want to and division at one's
disposal.
Self hardware test.
Prompt A/S is available for test of each part of the module.
7
TECHNICAL SPECIFICATION
DC 5V, up to 4 350 load cells
20mV, including dead load
0.05mV 5mV
2 V/D(NTEP, OIML)
0.5 V/D(Non NTEP, OIML)
Within 0.01% of FS
Approximately 200,000 counts
5,000 dd(NTEP, OIML)
30,000 dd(Non NTEP, OIML)
10 times/sec
Load cell excitation
voltage
Full scale input signal
Zero adjust range
Input sensitivity
System linearity
A/D internal resolution
A/D external resolution
A/D conversion speed
Analog Part
Span calibration
Display
Size of letter
Display below zero
Additional symbols
AC adapter
Power consumption
Operating temperature
Overall dimensions
Weight
Digital Part
Full Digital Calibration: SPACTM
(Single pass automatic span calibration)
CI-2001A LED(6 digit)
CI-2001B LCD(5 digit)
CI-2001A 14mm(Height)
CI-2001B 25mm(Height)
"-" minus signal
CI-2001A Zero, Tare, Gross,
Net, Stable, lb, kg
CI-2001B Zero, Net, Stable, lb, kg
AC 110V/220V(DC 12V, 850mA)
CI-2001A 10W
CI-2001B 1W
-10°C 40°C
85mm 186mm 58mm
0.5kg
8
Serial Interface: RS-232
Serial Interface: RS-422/485
Panel Mount Bracket
Inner Clock (only CI-2001B)
Standard
Option-1
Option-2
Option-3
Option Part
DIMENSIONS
1. CI-2001A/B Wall Mount Type
58
228
186
85
120
STABLE
ZERO
NET
CI-2001B
III
ZERO TARE PRINT LIGHT
CAPACITY
GROSS
NET kg
lb
2. CI-2001A/B(P) Panel Mount Type
Cutting Size: 166mm 76mm
186
85
89
58
STABLE
ZERO
NET
CI-2001B
III
ZERO TARE PRINT LIGHT
CAPACITY
GROSS
NET kg
lb
9
FRONT PANEL(CI-2001A)
ZERO
TARE
GROSS
NET
CI-2001A
CAPACITY
ZERO TARE PRINT ENTER
GROSS
NET kg
lb
STABLE
lb
kg
III
1. Display lamp( )
lb lamp: ON when the weight unit is pound [lb]
kg lamp: ON when the weight unit is kilogram [kg]
STABLE lamp: ON when the weight is stable.
TARE lamp: ON when the tare weight is stored.
GROSS lamp: ON when the current weight is GROSS weight.
NET lamp: ON when the current weight is NET weight.
ZERO lamp: ON when the current weight is 0kg(0lb).
2. Keyboard
Available keys instead of numeric keys.
:Change the set value.
Increase the first place value to 1.
Usage-input the numeric value in TEST, CAL, SET mode.
:Change the digit of the set value.
Move to the left by 1 place.
Usage-input the numeric value in TEST, CAL, SET mode.
Returns the display to 0.
ZERO
10
Use container in weighing.
Current weight is memorized as tare weight.
If you press TARE key in unload condition, Tare setting is released
automatically.
Use this key to switch from gross to net weight.
GROSS lamp on - gross weight
NET lamp on - net weight
In case tare weight is REGISTERED, tare and item's total weight is G. weight
and only item's weight is N. weight.
Toggles between lb and kg units.
Used to print the present weighing value.
Total weighing value print key.
HOLD key.
In CALIBRATION, TEST, SET mode.
: Store current condition and exit.
Set in F09.
3. How to enter TEST mode
Turn on the power while pressing the "PRINT" key and TEST mode starts.
4. How to enter SET mode
Turn on the power while pressing the "ENTER( )" key and SET mode starts.
5. How to enter CAL mode
Turn on the power while pressing the CAL switch on the rear panel of the
indicator and CAL mode starts.
TARE
GROSS/NET
kg/lb
PRINT
ENTER
11
FRONT PANEL(CI-2001B)
1. Display lamp( )
lb lamp: ON when the weight unit is pound [lb]
kg lamp: ON when the weight unit is kilogram [kg]
STABLE lamp: ON when the weight is stable.
ZERO lamp: ON when the current weight is 0kg(0lb).
NET lamp: ON when the current weight is NET weight.
2. Keyboard
Available keys instead of numeric keys.
:Change the set value.
Increase the first place value to 1.
Usage-input the numeric value in TEST, CAL, SET mode.
:Change the digit of the set value.
Move to the left by 1 place.
Usage-input the numeric value in TEST, CAL, SET mode.
Returns the display to 0.
ZERO
