CAS Scale ND 300 Manual de usuario

PRECAUTIONS................................................4

PREFACE..............................................................6

NAMESAND FUNCTIONS.....................6

INSTALLATIONS...........................................8

OPERATIONS..................................................11

1. General Weighing...........................................11

2. Weighing with Tare........................................11

ERROR MESSAGE......................................13

SPECIFICATIONS........................................13

CONTENTS

PRECAUTIONS

PREFACE

Thank you for purchasing our CAS ND-300 Series.

These series have been designed with CAS reliability, under rigid quality control

and with outstanding performance. Your specialty departments can enjoy these

high quality reliable CAS products.

We believe that your needs will be satisfied and you will have reliability.

This manual will help you with proper operation and care of the ND-300 Series.

Please keep this handy for future reference.

NAMES AND FUNCTIONS

OVERALL VIEW

PREFACE & NAMESAND FUNCTIONS

DISPLAYAND KEYBOARD

■ND-300

■ND-300E, ND-300H

■KEY FUNCTIONS

KEYS FUNCTIONS

Used to correct the zero point.

Used to enter a tare weight.

Used to cancel a tare weight.

Whenthe weight is not stable,the display showstheaverageweight.

Turnson or offthedisplay.

PREFACE & NAMESAND FUNCTIONS

ND-300

1.Fix with bolts andnuts after insertingthe load

cellcableto support pole.andthen pleasefix

theground wirewith a boltandfix the bolthat

upit.

2.Pleaseinsert support coverintothe support

pole.

3.Pleasefix the headguide withbolt. 4.Pleaseconnect head partto Head guide

andfixit withStopbolt.

5.Pleaseinsert to supportcablehole after

connectingtheload cell cableandshield

cabStickthe power code tothe back of

theHeadpart.

INSTALLATIONS

ND-300H

1.Insertthe powerlineintothe support.

Fastenwithbolts andnuts. 2.Fixaground wire with bolt then arrangethe

powerlineandloadcell line.

3.Attachthe support coverto the support. 4.Attach the headto the supportthen fastenwith

stopbolt.

INSTALLATIONS

ND-300E

1.Insertthe powerlineintothe support.

Fastenwithbolts andnuts. 2.Fixaground wire with bolt then arrangethe

powerlineandloadcell line.

3.Attachthe support coverto the support. 4.Attach the headto the supportthen fastenwith

screw.

INSTALLATIONS

OPERATIONS

■When you turn on the power switch, the scale will count "00000" to "99999",

then the scale will read "0.0" on the display. This is called the ZERO state.

If the scale is not ZERO state though there is nothing on the platter, press the

ZERO key.

■If the weight is not stable, press the HOLD key. Then you will see the

average weight.

■The display indicates if the scale is at ZERO or if there is a TARE entered into

the scale by way of a ZERO and NET lamps.

1. General Weighing

■Wait until the display shows zero.

①Placeacommodityon

theplatter. ②Removethe commodity

fromtheplatter.

N▶OTE: The symbol represents the lamp on the display above.◀

OPERATIONS
