Cartoni FOCUS 22 Manual de usuario

PROFESSIONAL CAMERA SUPPORT

USER’S MANUAL & Maintenance

Index

Safety & Set-UpIntrodUctIon 5

operatIng elementS 6

procedUreS 8

SpecIfIcatIonS 9

maIntenance 10

Warranty 10

acceSSorIeS & prodUct lIne 11

CARTONI ®

Manual Version: 2.3

Issue date: March 2020

1. Safety & Set-UpIntrodUctIon

The FOCUS 22 Fluid Head is specically designed to support the wide

variety of new ENG cameras, so compact yet so fully accessorized, featur-

ing the patented CARTONI “wing” connuously adjustable counterbalance.

With its broad range of payloads – 3 kg (6.6 lbs) to 22 kg (49.0 lbs) - The FO-

CUS 22 is the ideal partner for all news gathering and outdoor shoong jobs.

Rugged but easy to operate the Fluid Head has all the ergonomic set-

ngs at the right place. Fluid drag in both pan and lt feature the disncve

renowned CARTONI patented innitely adjustable labyrinth system.

Posive locks, wide range sliding plaorm incorporang the European

style quick release plate, a switchable illuminated spirit level completes the

operang specs.

FOCUS 22, weighs only 3,9 kg (8.6 lbs) thanks to the extensive use of

extremely lightweight magnesium alloys.

The FOCUS 22 interfaces with all 100 mm bowl base tripods. In the

FOCUS 22/150 version, it interfaces with the all 150 mm bowl base Tri-

pods and with Pedestals through the standard Vinten 4 bolts.

Before using the product read this user manual.

Before installing the Fluid Head on the Tripod check the Tripod sta-

bility.

Verify that the Camera payload (including lenses and accessories) is

lower than the maximum capacity of the Fluid Head.

Before installing the Camera make sure that the Fluid Head is in good

condions and bares no evident damages.

Camera plate

Sliding Camera plaorm

Pan bar aachment

Pan bar extension

Pan drag selector

Pan brake lever

Tilt brake lever

❶ ❷

❸ ❺❹ ❼

2. operatIng elementS

❻

Tie down knob

Removable e down sha

Camera plate release lever

Safety buon

Sliding plaorm lock

Tilt drag selector

Illuminated spirit level

Counterbalance selector

Pan bar

⓮ ❽

⓬ ⓫ ❿ ⓰

⓭ ❻

⓯

❾

Place the FOCUS 22 on your Tripod by loosening the e-down knob

(8) under the Fluid Head and level using the illuminated spirit level

(14). In low light condions, press buon for light.

Connect the Pan bar (16) to the Fluid Head ghtening the lever (3) on

the Pan bar aachment and select your desired operang angle. The

telescopic Pan bar length can be adjusted via lever (4).

Lock both Pan and Tilt brakes (6 & 7), turn both Tilt drag selector (13)

and Counterbalance knob (15) to the minimum.

Open the Camera plate release lever (10) completely to release the

Camera

plate (1).

Remove the Camera plate (1) from the sliding Camera plaorm (2)

by squeezing simultaneously Camera plate

release

lever (10) and the

safety buon (11). Aach the Camera plate (1) to the boom of the

Camera and ghten the clamping screw to secure the Camera. Try to

center the Camera plate on the Camera, keeping the center of gravity

(CG) posion in mind.

Lock the sliding plaorm lever (12), click the Camera into the quick

release sliding plaorm (2), the plate will lock into place.

Hold the Camera in horizontal posion with the Pan bar (16) and re-

lease the Tilt brake lever (7). Release the sliding plaorm lever (12) and

nd the correct center of gravity (CG) posion, by sliding the Camera

plaorm (2) back and forth unl you have achieved the correct bal-

ance. Lock the sliding plaorm lock (12).

3. procedUreS

Set the Counterbalance system by turning the balance knob clockwise

(15) to appropriate tension. The Camera has to stay at any lt angle.

Eventually ne-tune by adjusng the sliding plate.

Unlock the Pan brake lever (6) and set the Fluid drag control by adjust-

ing selectors (5 & 13).

The FOCUS 22 can be aached to most of the sliders via a 3/8” tread-

ed hole under the Head. Remove the e down sha (9) with a M10

key and nd the hole underneath.

When the illuminated spirit level light fails it is me to replace the

baeries (14). Pull out the baery tray.

Minimum payload 3 Kg 6.6 lbs

Maximum payload 22 Kg 49 lbs

Weight Focus 22 3,9 Kg 8.6 lbs

Weight Focus 22/150 4,9 Kg 10.8 lbs

Camera Aachment Euro-Style quick release

Bowl diameter 100 mm/150/Flat

Fluid Drag Connuous

Counterbalance Connuous

Pan range 360°

Tilt range +-90°

Temperature range -40 /+60 °C -40 /+140 °F

4. SpecIfIcatIonS

5. maIntenance

6. Warranty

With indoor use - when needed - just clean the FOCUS 22 and Tripod

with a so cloth. Dirt accumulated during storage may be removed using a

brush or Air spray.

CARTONI products main mechanisms are sealed as they are also built

for professional outdoor use.

However, use under rough condions will require special care. Salt water

is very corrosive and can cause extreme damages. In atempt to avoid fur-

ther damage the Fluid Head should be washed o with fresh water at the

earliest opportunity and dried before storage.

Sand and dirt are abrasive and should be removed using a semi-s

brush or Air spray.

Disconnect the illuminated spirit level baery during long term storage.

All CARTONI Fluid Heads & Pedestals have a free of charge three (3)

year warranty. Register your product at www.cartoni.com within 30 days

from date of rst purchase/invoice to receive further two (2) year warranty

for the unsurpassed free ve (5) year warranty.

Tripods, spreaders, dollies and all accessories are guaranteed one (1)

year from the date of rst purchase/invoice.

CARTONI warrant that the product supplied will - under proper use -

be free from defects in workmanship and materials and agrees that it will,

at its opon, either repair or replace any defecve part within duraon of

warranty from date of rst purchase with no labour charge.
