CarShow Multimedia Navigation System Manual de usuario
Navigation
Bluetooth Hands-Free (For use with Sync)
iPod®and MP3 compatible (For use with Sync)
Back-up camera included Play Audio CDs and MP3 Discs
Play Audio CDs and MP3 Discs (For use with Sync)
Supports steering wheel controls
Customizable backgrounds
Satellite Radio (For use with Sync)
Multimedia
Navigation
System Owner’s Manual
Ford Mustang
*FOR MODELS WITH FORD SYNC®ONLY
Operational Panel
Button Functions
1) DISP Button:
1
2
3
4
• Press this button to dim backlight.
• Press this button to turn display off.
2) NAV Button:
• Press this button to enter naviation mode; press again to
return to current source.
3) MENU Button:
• Press this button to access the MENU option of the
particular source.
4) Micro SD Card Slot:
• Holds Micro SD card that contains Navigation software.
AM/FM Source
23 4 5
67
8
9
11
10
1) Settings Button - This will take you to the settings page.
2) EQ Button - Enable/Cycles the EQ Menu.
3) RDS Text Organization- Cycles the organization of RDS text.
4) System Time Display
5) The current playing station
6) Temperature
7) Compass
8) Seek Up key- Next Station
9) Preset Channels
10) Source shortcut keys
11) Seek Down key - Previous Station
1
Scanning
Touch the current station to activate/deactivate scanning mode.
Step Tuning
1. Touch the [AM/FM] key to select radio band (FM1>FM2>AM1)
2. Long touch the [<<] / [>>] key to search to the next strong signal station.
3. Short touch the [<<] / [>>] key to tune backward or forward one step.
Preset List
Touch a preset key for 3 seconds to store a new channel.
SAT Source
1) Settings Button - This will take you to the settings page.
2) EQ Button - Enable/Cycles the EQ Menu.
3) RDS Text Organization- Cycles the organization of RDS text.
4) System Time Display
5) The current playing station
6) Temperature
7) Compass
8) Seek Up key - Next Station
9) Preset Channels
10) Source shortcut keys
11) Seek Down key - Previous Station
123 4 56 7
8
9
10
11
Scanning
Touch the current station to activate/deactivate scanning mode.
Step Tuning
1. Touch the [SAT] key to select radio band (SAT1>SAT2>SAT3)
2. Short touch the [<<] / [>>] keys to tune backward or forward one station
Preset List
Touch a preset key for 3 seconds to store a new channel.
CD Source
1 2 3 4 5 6
7
8
9
10
11
12
13
14
1) Settings Button - This will take you to the settings page.
2) EQ Button - Enable/Cycles the EQ Menu.
3) Song info text organization
4) System Time Display
5) Temperature
6) Compass
7) Next Track
8) Pause/Play
9) Source shortcut key
10) Previous Track
11) Seek Down [Only for folders]
12) Seek Up [Only for folders]
13) Scan Enable/ Disable Scan feature
14) Eject Disc
SYNC Line In Source
1 2 3 4 5 6
7
9
11
12
13
14
15
1) Settings Button - This will take you to the settings page.
2) EQ Button - Enable/Cycles the EQ Menu
3) Song info text organization- Not Used
4) System Time Display
5) Temperature
6) Compass
7) Displays current SYNC source - SYNC Line In
8) Next Track - Not Used
9) Pause/Play - Not Used
10)Source shortcut key
11) Previous Track - Not Used
12) Seek Down - Not Used
13) Seek Up - Not Used
14) Folder - Not Used
8
10
15) Source- This button cycles SYNC Line In, SYNC USB, and Bluetooth
Streaming
SYNC USB Source
1 2 3 4 5 6
7
9
11
12
13
14
15
8
10
1) Settings Button - This will take you to the settings page.
2) EQ Button - Enable/Cycles the EQ Menu
3) Song info text organization
4) System Time Display
5) Temperature
6) Compass
7) Displays current SYNC source - SYNC USB
8) Next Track
9) Pause/Play
10)Source shortcut key
11) Previous Track
12) Seek Down [Only for folders]
13) Seek Up [Only for folders]
14) Folder
15) Source- This button cycles SYNC Line In, SYNC USB, and Bluetooth
Streaming
Bluetooth Streaming Source
1 2 3 4 5 6
7
9
11
12
13
14
15
8
10
1) Settings Button - This will take you to the settings page.
2) EQ Button - Enable/Cycles the EQ Menu
3) Song info text organization
4) System Time Display
5) Temperature
6) Compass
7) Displays current SYNC source - Bluetooth Streaming
8) Next Track
9) Pause/Play
10)Source shortcut key
11) Previous Track
12) Seek Down [Only for folders]
13) Seek Up [Only for folders]
14) Folder
15) Source- This button cycles SYNC Line In, SYNC USB, and Bluetooth
Streaming
Please note that your phone must be paired in order to enable BT streaming
