Carrier LonWorks i-Vu Link Guía de configuración rápida

-V

u®

A member of the United Technologies Corporation family · Stock symbol UTX · Catalog No. 11-808-430-01 · 5/24/2018

Verify that you have the most current version of this document from

www.hvacpartners.com

or your local Carrier

office.

Important changes are listed in

Document revision history

at the end of this document.

Corporation. All other trademarks are the property of their respective owners.

Contents

Overview ....................................................................................................................................................................... 1

Before-you-begin checklist.......................................................................................................................................... 2

Assumptions..........................................................................................................................................................2

Items to be installed at the job site ...................................................................................................................2

Other items needed for the integration ............................................................................................................3

1Create a control program in Snap.......................................................................................................................... 4

To format a LonWorks address ..........................................................................................................................4

2 Assign and download custom control programs and views to the i-Vu® Link/Open Link............................... 5

3Configure LonWorks points using the LonWorks Integration Tool...................................................................... 6

To edit an integration point address..................................................................................................................8

4Connect an SLTA-10 to each i-Vu® Link/Open Link on the LonWorks network segment ................................ 9

5Set up the driver properties..................................................................................................................................10

6Verify the controller is set up correctly ................................................................................................................12

To capture communication using PuTTY ....................................................................................................... 12

Appendix A - Common HVAC SNVT's........................................................................................................................14

Appendix B - Obtain network, device, and network variable information.............................................................20

Option 1: Using an Echelon® U10/U20 USB Network Interface............................................................... 20

Option 2: Using an SLTA-10 Network Adapter ............................................................................................. 22

Option 3: Using an iLon10 Ethernet Adapter ............................................................................................... 24

Document revision history ........................................................................................................................................26

Follow the steps in this document to integrate one or more third party LonWorks controllers using an i-Vu®

Link/Open Link. See the i-Vu® Link/Open Link Installation and Start-up Guide for installation and networking

instructions.

i-Vu® Link/Open Link

LonWorks port S2

Module driver drv_ivulink_lon_6-00-082*

drv_ivuopenlink_std_6-00-082*

Read/write capability Can read from and write to the third-party equipment

Third party points supported 500

Third party

Supported equipment Any device that supports the LonWorks protocol using

SNVT's**

Network media type EIA-232 to SLTA-10 network adapter

Quantity of devices you can

physically connect to the i-Vu®

Link/Open Link

1 LonWorks network segment with up to 64 LonWorks

devices, daisy-chained

You can download the latest drivers from the Carrier Control Systems Support Site

http://www.hvacpartners.com/. Check the latest bulletin releases for new or updated drivers.

** UNVT's and nci SNVT's are proprietary and not supported.

The i-Vu® Link/Open Link drivers support LonWorks devices connected to Port S2 and BACnet or Modbus devices

connected on the Ethernet port simultaneously. The third party point count for the i-Vu® Link/Open Link is the

total of the 2 ports.

Overview

Before-you-begin checklist

Assumptions

You know how to create custom control programs in Snap.

You know how to install, wire, set up, and download memory to the i-Vu® Link/Open Link.

The LonWorks network/devices have been commissioned by the third-party representative

using LonMaker.

Items to be installed at the job site

Item

Notes

i-Vu® Link/Open Link

LonWorks module driver drv_ivuopenlink_<latest version>.driver.

Echelon®SLTA-10 Serial LonTalk®

Adapter

•#73351 for FT-10 networks

•#73352 for TP-78 networks

•#73353 for TP-1250 networks

•

#73354 for RS-485 networks

You need 1 adapter for each i-Vu® Link/Open Link

that is connected to a LonWorks network segment.

Make sure you order the model that matches your

network topology. See the Echelon website

(http://www.echelon.com) for your local Echelon

sales contact.

Echelon®power supply (part# 78010)

CAUTION!

You can damage the SLTA-10 if it does not have its

own isolated power supply.

EIA-232/RS-232 straight-through cable

with 9-pin connectors

and an S2-DB9 adapter (purchase S2-

DB9 from Carrier)

18-22 AWG, 4-conductor cable and a

DB9 male adapter

To connect the i-Vu® Link/Open Link to its SLTA-

10. You can buy an EIA-232/RS-232 cable with

connectors or buy 4-conductor cable and wire your

own connections.

Custom control programs (.equipment

files) and graphics (.view files)

Before-you-begin checklist

Other items needed for the integration

Item

Notes

LonWorks Integration Tool Install from the i-Vu®

Tools

DVD.

Network variable information

(.xif file) for each type of LonWorks

device. For example, VAV Controller or

Fan Coil Controller.

Get from:

•the third-party representative

•www.lonmark.com

•the LonWorks device. See Appendix B (page

20).

Device address information

(domain, index, subnet, and node

address)

Get from:

•the customer

•the third-party representative

•a .log file obtained from the LonWork's device.

See Appendix B (page 20).

Manual for each type of LonWorks

device

Get from the third-party representative or the third-

party website.

1Create a control program in Snap

When you create a control program for each type of LonWorks device, use the following Network I/O microblocks:

•One ANI, ANI2, BNI, or BNI2 to read each element of interest in an nvo SNVT

•One ANO, ANO2, BNO, or BNO2 to write to each element of interest in an nvi SNVT

TIP

The SNVT definitions in Appendix A (page 14) may help you determine whether you need an analog or binary

microblock.

To format a LonWorks address

All Lonworks addresses should be assigned to "lonworks://" only when setting up address strings in

EquipmentBuilder. The

LonWorks Integration Tool

is used to define these addresses.

An example of a LonWorks address:

lonworks://0/1/2/3ff5/108/0/0/0

Details:

lonworks://domain_index/subnet/node/nv_Number(Selector in HEX)/SNVT Type/NV Element/ Property/group

•group is always 0(zero)

•Property = 1for ANI/BNI

•Property = 0 for ANO/BNO

NOTE

Carrier does not support a Domain Length of 0(zero)

1Create a control program in Snap

2 Assign and download custom control programs and views to the i-Vu® Link/Open Link

1 If using the i-Vu® or Field Assistant application, go to

Devices

page >

Manage

tab and select the i-Vu®

Link/Open Link in the navigation tree.

2 Click the

Add Control Program

button on the right. A dialog window appears.

3 Enter a

Display

Name

. Select the i-Vu® Link/Open Link from drop-down list under

Programmable Controller

4 Click

Add New

under

Control Programs

. A second dialog window will appear.

5 Browse to the .equipment file that you created in

Snap

and click

Continue

6 When message appears

File added successfully

, click

7 To upload a graphic, click

Add New

under

Views

and browse to your .view file. A second dialog window

appears.

8 Browse to the .view file that you created in

ViewBuilder

and click

Continue

9 When message appears

File added successfully

, click

10 Click

11 Repeat steps 3 - 12 to add additional control programs and views.

12 In the navigation tree, select the i-Vu® Link/Open Link in the router list on the right and click

Download All

Content

NOTE

This loads the control programs and graphics into the i-Vu® Link/Open Link.

To edit your control program in Snap

Follow these steps to edit an existing control program:

1 Log in to the i-Vu® or Field Assistant application.

2 Double-click the third party controller in the navigation tree. A dialog window appears.

3 Click

Edit Existing

under

Control Programs

. A new dialog window appears.

4 Save file to a location of your choice.

5 Click

6 Start

Snap.

7 Select

File

Open

and open the .equipment file that you saved.

8 Edit the control program and save to your computer.

9 Start the i-Vu® or Field Assistant application.

10 Double-click the third party controller in the navigation tree. A dialog window appears.

11 Click

Add New

button under

Control Programs

. A new dialog window appears.

12 Browse to your edited control program and click

Continue

. When message appears

File added successfully

click

Close.

13 Click

2 Assign and download custom control programs and views to the i-Vu®

Link/Open Link

3Configure LonWorks points using the LonWorks Integration Tool

PREREQUISITES

•The LonWorks Integration Tool installed on your computer

•A *.xif file from www.lonmark.com, the third-party representative, or from the LonWorks device (see Appendix

•The Domain Index, Subnet, and Node ID from the third-party vendor or from the LonWorks device (see

Appendix A)

1 Log in to the i-Vu® or Field Assistant application.

2 Double-click the third party controller in the navigation tree. A dialog window appears.

3 Click

Export

under

Integration Points

4 Click

Save

5 Browse to a location on your PC to save the file. (The file will have a .erl extension.)

6 On the Windows Task Bar, select

Start

All Programs

i-Vu Tools

LonWorks Integration Tool

7 Click the wand icon to start the wizard.

8 Follow the wizard's instructions to create your microblock addresses.

NOTES

○If you obtained your Domain Index, Subnet, and Node from the LonWorks device (Appendix B (page 20)),

you will find this information in your .log file.

3Configure LonWorks points using the LonWorks Integration Tool
