Carmanah SPEEDCHECK-12 Manual de usuario

SpeedCheck®

APPLIED INFORMATION (AI) INTEGRATION INSTALL GUIDE

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupp[email protected] | carmanah.com

For the SPEEDCHECK-12

90063_INSTALL-GUIDE_SPEEDCHECK-12-AI-Integration-Kit_RevB

SPEEDCHECK-12

(Battery/Solar)

SPEEDCHECK-12

(AC)

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 2

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

This page left intentionally blank.

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 3

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

Table of Contents

Table of Contents .....................................................................................................................................................3

1.0 Warnings and Precautions ................................................................................................................................4

1.1 Warranty Disclaimer ...................................................................................................................................4

1.2 Standards ...................................................................................................................................................4

1.3 Safety and Usage Precautions...................................................................................................................4

1.4 Applications ................................................................................................................................................5

2.0 System Components..........................................................................................................................................6

3.0 Tools and Materials Required ...........................................................................................................................6

4.0 Installation...........................................................................................................................................................7

4.1 Opening Rear Enclosure ............................................................................................................................7

4.2 AI 500-070 Field Control Unit (FCU) ..........................................................................................................8

4.3 Solar Version Only................................................................................................................................... 11

4.4 Testing AI FCU ........................................................................................................................................ 12

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 4

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

1.0 Warnings and Precautions

The following symbols indicate important safety warnings and precautions throughout this guide:

WARNING indicates that serious bodily harm or death may result from failure to adhere to the

precautions.

CAUTION indicates that damage to equipment may result if the instructions are not followed.

NOTE suggests optimal conditions and provides additional information.

1.1 Warranty Disclaimer

This manual will familiarize you with the features, operation standards and installation of Carmanah’s

SPEEDCHECK-12 Applied Information (AI) Integration Kit. Failure to comply with the use, storage, maintenance,

installation or placement instructions detailed in this manual could void the warranty.

1.2 Standards

Perform all installation, wiring, grounding and maintenance in conformance with local building and electrical

codes. Adherence to the National Electrical Code (NEC) is mandatory to comply with any certification markings.

Non-adherence to code may void the warranty.

1.3 Safety and Usage Precautions

Batteries are shipped fully charged. Use extreme caution when handling the batteries as they can

generate hazardous short-circuit currents. Remove all jewelry (bracelets, metal-strap watches,

etc.) before handling the batteries.

Solar panels produce DC electricity when exposed to light and can therefore produce an

electrical shock or burn. To render solar panels inoperative, remove them from sunlight or fully

cover their front surface with an opaque material.

Before lifting any heavy or bulky equipment, ensure the load is secured so moving parts do not

shift, and that it can be lifted as far as needed without back strain or loss of grip. Installation may

require more than one person.

Ensure the equipment is not powered during installation and wiring of the system.

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 5

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

Recheck all completed wiring for proper polarity prior to energizing the system.

Changes or modifications to Carmanah equipment not expressly approved by Carmanah could

void both the user's authority to operate the equipment and the warranty.

Product can have sharp edges. Accidental movement of hinged components can cause injury.

This guide is specific to the SPEEDCHECK-12 AI Integration Kit installation and is not a

replacement for the complete SPEEDCHECK-12 product user manual.

Visit support.carmanah.com to download the complete product user manual.

1.4 Applications

For Carmanah SPEEDCHECK-12 radar speed signs, the AI Integration Kit allows for remote system monitoring,

scheduling and control.

The SPEEDCHECK-12 AI Integration Kit is available in two different states of assembly described below:

•If ordered with a SPEEDCHECK-12 system: the display enclosure harnessing is assembled in the

factory, creating an “AI-ready” SPEEDCHECK-12 system. The AI Integration Kit comes as parts to be

installed by the user following all installation steps provided.

•If ordered separately: the SPEEDCHECK-12 display enclosure must be replaced prior to following these

installation steps. See the note below.

If installing into an existing system that was not ordered with the AI Integration Kit, you will require

a new display enclosure. Contact Carmanah for more information.

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 6

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

2.0 System Components

The SPEEDCHECK-12 Applied Information (AI) Integration Kit consists of the following items:

1. Mount plate, AI FCU (1)

2. Harness, AI FCU to bulkhead (1)

3. Harness, solar monitoring, 8’ (1)

4. Nut, nyloc, 1/4”-20 (4)

5. Cable tie, 4-way, mounting base (2)

6. Cable tie, 4” (4)

7. Cable tie, 7”, #8 screw mount (1)

8. Screw, #8-32 x 1/4”, pan head (3)

9. Screw, #8-32 x 3/8”, pan head (1)

10. Adapter, 90°, SMA male to SMA female (2)

3.0 Tools and Materials Required

The following tools and materials may be required to install the AI Integration Kit into your SPEEDCHECK-12

system:

1. Drill and 17/32” drill bit

2. Deburring tool or similar

3. Crescent wrench

4. Side cutters

5. Multi-bit screwdriver

6. Socket set

7. 18/19mm wrench or 3/4” fuel inject socket

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 7

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

4.0 Installation

4.1 Opening Rear Enclosure

1. To open SPEEDCHECK-12, insert included key into lock and rotate clockwise.

2. Apply diagonal pressure to the bottom right corner of the sign face then PULL on the key.

3. Once unlocked, the key can be removed.

4. Swing the display enclosure away from the rear enclosure.

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 8

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

4.2 AI 500-070 Field Control Unit (FCU)

If a second battery is installed in the upper part of the rear enclosure it will need to be removed to

fit the AI Field Control Unit (FCU). Remove the upper battery, battery bracket and battery shelf

prior to installing the FCU mounting plate.

1. Disconnect power to the system by opening all battery fuse holders or switch off the breaker (to the right).

2. Install the AI FCU mounting plate into the rear enclosure and secure with three nyloc nuts in the locations

outlined below.

3. Drill a 17/32” hole in the top corner of the rear enclosure at the half shear location. Deburr both sides of

the hole and remove all metal chips.

4. Remove jam nut and washers from antenna. Install coax cables through previously drilled hole. Install

plastic washer, lock washer and nut as shown below. Ensure the antenna is flush with the rear enclosure

and tighten nut with a 19mm wrench.

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 9

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

5. Install two cable tie holders onto the mounting plate as shown below.

6. Route coax cables from antenna to cable tie mounts and loop cables around 2-1/4 turns clockwise.

Secure with four cables ties.

Coax cable connectors should end up approximately in the left of the rear enclosure.

7. Install 16-pin and 4-pin harnesses into the AI FCU.

8. Thread two 90° coax adapters onto antenna connectors. Orient as shown below.

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com 10

APPLIED INFORMATION (AI) INTEGRATION

INSTALL GUIDE

9. Install AI FCU onto mounting plate with three #8-32x1/4” screws.

10. Install screw mount cable tie around harness wires end secure to lower-left mounting plate standoff with

one #8-32x3/8” screw.

11. Install harness ground ring terminal onto stud shown and fasten with one nyloc nut. Orient as shown.

12. Thread GPS and LTE antenna coax harness connectors onto correct connectors on the AI FCU (not

shown below).

Yellow sensor wire will remain unterminated for AC-powered systems. For solar-powered

systems this will mate with the yellow wire from the solar kit. See Section 4.3 for more

information.

13. Connect the 2-pin and 4-pin AI FCU connectors to the open receptacles on the display enclosure as

shown below. All 2-pin connectors are interchangeable.

Battery Only or AC w/ AI FCU Solar Kit w/ Battery & AI FCU

Cell –Front

GPS –Rear
