TH TUNE

AUTONOMOUS DEVICES WATER-AIR

USER MANUAL

09.16 207683 Rev.100

09.16 207683 Rev100

INDEX

INSTALATION INSTRUCTIONS..................................................................................................................................3

OPERATING MANUAL ................................................................................................................................................4

ON / OFF....................................................................................................................................................................................4

TEMPERATURE SETTING.........................................................................................................................................................4

SYSTEM MODES.......................................................................................................................................................................4

CALIBRATION OF THE THERMOSTAT PROBE........................................................................................................................4

FAN VENTILATION / AUTOFAN.................................................................................................................................................4

POWER SUPPLY.........................................................................................................................................................4

DESCRIPTION OF ALARM CODES............................................................................................................................5

TIME SCHEDULE AND FUNCTIONS..........................................................................................................................6

DEFINITION OF THE TIME PHASES SCHEDULE ICONS.........................................................................................................6

09.16 207683 Rev100

INSTALATION INSTRUCTIONS

09.16 207683 Rev100

OPERATING MANUAL

ON / OFF

Hold the button (On / Off) for two seconds to turn on or turn off the thermostat.

The word “OFF” will be shown on the screen when the thermostat is turned off.

NOTE: If the on-off remote contact is opened, the thermostat will show “OFFd” on the

screen.

TEMPERATURE SETTING

Adjust the set point temperature (SETPOINT) by turning the center button.

SYSTEM MODES

Press the (Mode) button to toggle between the available operating modes.

Available operating modes:

Cold –The screen will show the icon

Heat –The screen will show the icon

Automatic –The screen will show the word “Auto”, but the screen will show "Auto" but the

active mode at the moment will be indicated on the bottom of the thermostat.

Just fan –The screen will show the icons and

CALIBRATION OF THE THERMOSTAT PROBE

Press FAN+ON/OFF and hold them to access in the thermostat menu.

For the calibrating of the probe we access with the password 22 to the PCAL option.

FAN VENTILATION / AUTOFAN

Press the button (Fan), to switch between auto fan or continuous ventilation fan.

Available fan modes:

With automatic fan –The screen will show “Auto Fan”.

The fan works only when there is a request of cold or heat.

Without automatic fan –The screen will show “Fan”.

The fan works in a continuous mode.

POWER SUPPLY

The thermostat can operate at 50Hz and at 60Hz, and the voltage tolerances are ± 20%.

AUTOMATIC

OPERATION

INTERIOR FAN

SELECTION

09.16 207683 Rev100

DESCRIPTION OF ALARM CODES

RESET IN THE ALARM CODES

Press the central button until it appears RES

(only available when there is at least one

active alarm).

All the alarms whose causes have disappeared or have been solved,

are canceled.

Turn the central button to go from 0 to 1.

Press the central button one time.

When the reset is completed, the text will change to OK.

After the reset, the thermostat will automatically return to normal, displaying the temperature.

IMPORTANT:

All serious alarms cause the stop of the unit and trigger an output signal through a relay.

DESCRIPTION OF THE ALARM CODES

CODIGO

DESCRIPCIÓN

AL01

Probe alarm B1 disconnected

AL06

Probe alarm B6 disconnected

ALPA

High pressure switch alarm circuit 1

ALPB

Low pressure switch alarm circuit 1

ALF7

Thermal alarm of the interior fan

ALF6

Thermal alarm of the compressor 1

ALPM

Minimum pressure switch alarm

ALRF

Lack of refrigerant alarm

AL11

Probe alarm B11 disconnected

AL12

Probe alarm B12 disconnected

ALH1

Antifreeze alarm 1

ALH2

Antifreeze alarm 2

ALH3

Antifreeze alarm 3

ALH4

Antifreeze alarm 4

A2PA

High pressure switch alarm circuit 2

A2PB

Low pressure switch alarm circuit 2

A2PM

Minimum pressure switch alarm circuit 2

A2RF

Lack of refrigerant alarm circuit 2

A2F7

Thermal alarm of the external fan 2 (machine 2 circuits)

A2F8

Thermal alarm of the interior fan (machine 2 circuits)

AL02

Probe alarm B2 disconnected

AL03

Probe alarm B3 disconnected

ALIF

Flow switch alarm

09.16 207683 Rev100

TIME SCHEDULE AND FUNCTIONS

CLOCK BUTTON (1):

Normal / Short press: the function activate and deactivate the time schedule. A clock icon

appears when the time schedule is activated.

Long press: It has effect only when we have the time schedule off, when the clock icon is not

on the screen... Its function is to time the thermostat and schedule the time phases.

CENTRAL BUTTON (2):

Rotating movement: This function is used to select the possible values of the time phases.

Normal press: Function used to enter the selected values (enter).

DEFINITION OF THE ICONS IN THE TIME PHASES SCHEDULE

SUN

Time phase 1

MOON

Time phase 2

Ex.: From 08:00 am

Ex.: From 15:00 pm

OFF

Ex.: To 13:00 pm

OFF

Ex.: To 20:00 pm

NOTE: Out of phase the machine is always OFF (with the time schedule enabled).
