CaptiveWorks CW-3000HD Manual de usuario
CW-3000HD
User Manual
Version 0.6
PAGE 1 BACK TO TOC
Safety Precautions
Electrical Safety
●To prevent electrical shoc hazard, disconnect the power cable from the electrical outlet
before relocating the system
●When adding or removing signal cables or devices from the system ensure that the
power cable is unplugged before doing so.
●See professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
●Do not attempt to repair or modify the power supply. Doing so could create the ris of
electrical shoc or fire.
Operational Safety
●Before operating the system, carefully read the manual that came with the system.
●Before using the system ensure that all cables are correctly connected and there is no
damage to the power or signal cables. If any damage is detected, contact the dealer
immediately.
●To avoid short circuits, eep paper clips, screws, staples and, other metallic devices
away from connectors and ventilation openings.
●Avoid dust, humidity and, temperature extremes. Do not operate the system in any area
that may become wet.
●Place the system on a stable surface
●Do not bloc ventilation holes in the system. The system requires ventilation to ensure
proper operation.
●If technical problems are encountered with the system, contact a qualified service
technician or the retailer where the product was purchased.
Table of Contents
System Specifications...................................................................................................................................6
Hardware................................................................................................................................................6
System Software......................................................................................................................................6
Multimedia Software................................................................................................................................7
Dimensions.............................................................................................................................................7
Pac age Contents.....................................................................................................................................8
System Placement....................................................................................................................................8
Remote Control Unit................................................................................................................................8
Cable Connections...................................................................................................................................9
Rev. 1.................................................................................................................................................9
Rev. 2..............................................................................................................................................10
DVB & ATSC..................................................................................................................................11
Rev 1...........................................................................................................................................11
Rev 2...........................................................................................................................................1
DUAL DVB.....................................................................................................................................13
Rev 1...........................................................................................................................................13
Rev 2...........................................................................................................................................14
PAGE 2 BACK TO TOC
Quic Start Guide.......................................................................................................................................15
System Bootup...........................................................................................................................................17
System Setup.............................................................................................................................................18
Main Menu...........................................................................................................................................18
Admin Menu....................................................................................................................................19
Updates Menu.............................................................................................................................. 0
Date........................................................................................................................................ 1
Downloading Updates..............................................................................................................
Adding And Editing An Updates Server............................................................................... 3
Installing Updates.................................................................................................................... 4
Chec ing System Version........................................................................................................ 5
Bac up Settings....................................................................................................................... 6
Restore Settings....................................................................................................................... 6
Configuration Menu..................................................................................................................... 7
Adapter Setup......................................................................................................................... 8
Display Setup.......................................................................................................................... 9
Size Setup..........................................................................................................................30
Timeout Setup....................................................................................................................31
Themes Setup.....................................................................................................................3
Networ Setup........................................................................................................................33
Audio Setup............................................................................................................................34
Storage Setup..........................................................................................................................35
Shared Folders........................................................................................................................37
Satellite TV Setup...................................................................................................................39
Weather Setup.........................................................................................................................40
Antenna Menu.............................................................................................................................41
Satellite Setup.........................................................................................................................4
Adding A Satellite..............................................................................................................44
Satellite Scanning...............................................................................................................45
Editing Channels............................................................................................................46
Motor Support....................................................................................................................47
ATSC Scanning..................................................................................................................51
Edit ATSC.....................................................................................................................5
Cable Scanning...................................................................................................................53
Edit QAM.....................................................................................................................54
Profiles Menu..............................................................................................................................55
Adding A Profile.....................................................................................................................56
Editing A Profile.....................................................................................................................57
Assigning Antenna Channels....................................................................................................58
Assigning IP Channels.............................................................................................................59
Configure IP Channels.............................................................................................................60
Add IP Channel..................................................................................................................61
Assigning Applications............................................................................................................6
PAGE 3 BACK TO TOC
System Operation.......................................................................................................................................63
Profiles.................................................................................................................................................63
Profile Applications..........................................................................................................................64
IPTV...........................................................................................................................................65
IPTV Channel Pac ages...........................................................................................................65
IPTV Channel Categories.........................................................................................................66
TV..............................................................................................................................................67
Navigating Through The On Screen Menus...............................................................................68
The Grid Program Guide..........................................................................................................69
The "Schedule" Menu..............................................................................................................70
Selecting A Channel................................................................................................................71
Selecting Audio Trac s............................................................................................................71
Instant Recording....................................................................................................................7
Pausing Live Video.................................................................................................................7
Replaying A Recording............................................................................................................73
Replay Control........................................................................................................................73
Editing Recordings..................................................................................................................74
Explained...........................................................................................................................74
Quic Mini-Howto..............................................................................................................75
Programming The Timer..........................................................................................................76
Video..........................................................................................................................................78
Video Selection.......................................................................................................................78
Video Viewer Keys.................................................................................................................80
Pictures.......................................................................................................................................81
Picture Viewer Keys................................................................................................................8
Web............................................................................................................................................83
DVD...........................................................................................................................................84
DVD Viewer Keys..................................................................................................................84
Music..........................................................................................................................................85
Music Player Keys...................................................................................................................87
Roaster........................................................................................................................................88
Prepare DVD..........................................................................................................................89
Prepare Video.........................................................................................................................91
Burn DVD..............................................................................................................................9
Burn Video.............................................................................................................................93
Games.........................................................................................................................................94
CD..............................................................................................................................................95
CD Player Keys.......................................................................................................................95
PAGE 4 BACK TO TOC
Appendix...................................................................................................................................................96
External USB Device Connection...........................................................................................................96
Keyboard / Mouse Connection................................................................................................................97
Networ ing With Windows PC's............................................................................................................98
Seeing Files Over The Networ .........................................................................................................98
Enabling More Shared Folders...........................................................................................................98
Playing Your Recordings Over The Networ ......................................................................................98
Remote Control - Keyboard Cross-reference...........................................................................................99
Troubleshooting.......................................................................................................................................100
Accessing Logs...................................................................................................................................100
BIOS Settings.....................................................................................................................................100
Display Diagnostics.............................................................................................................................101
Remote Control Diagnostics.................................................................................................................10
Roaster Diagnostics.............................................................................................................................10
Satellite TV Diagnostics......................................................................................................................103
Shared Folders Diagnostics..................................................................................................................104
Software License......................................................................................................................................106
Warranty Information...............................................................................................................................107
Technical Support....................................................................................................................................107
PAGE 5 BACK TO TOC
System Specifications
Hardware
●Processor:
●Sempron 3000+ 64Bit CPU AM2 Soc et (CW-3000HD rev. 1)
●Athlon X2 4000+ 64Bit CPU AM2 Soc et (CW-3000HD rev. 2)
●Memory: 512MB DDR2 RAM Expandable to 8GB
●Flash Drive: 1 GB System Flash
●Hard Drive: Not Included
●Video:
●Nvidia GeForce 6150 (CW-3000HD rev. 1)
●Nvidia GeForce 7050 (CW-3000HD rev. 2)
●Satellite Tuner:
○Input terminal: F-type 75 Ohm
○Receiving frequency: 950~2150 MHz tuning range
○Input level: -65~-25dBm
○Support MCPC and SCPC
○Symbol rate: 2~45 Msps
○FEC Codes: 1/2,2/3,3/4,5/6,7/8 and Auto
○QPSK
●ATSC Tuner
○Latest LG 5th generation tuner for enhanced reception
○Supports QAM 64 and QAM 256 Cable signals
○One TV antenna 75 ohm reception port
●Video Output: VGA/HDMI or DVI/Component/S-Video
●Audio Ouput: Analog and SPDIF Dolby Digital Audio output
●USB Ports: 4 USB v2.0 ports on bac panel and 2 USB v2.0 ports on front pane
●Media Reader: All In One Media Reader. Supports most popular flash cards
●Ethernet Port: RJ-45 10/100/1000 Mbits compatible
●DVDRW: Read/Write DVDs and CDs
System Software
●Linux Operating System based on 2.6.21 Kernel
●Graphical X-Windows Environment
●Java 1.4.2 Based Graphical User Interface
●Software Upgradeable Via Internet and/or USB Storage Device
●Networ sharing to Des top computers using Samba (3)
●All software is 100% Open Source with the exception of the Java user interface
PAGE 6 BACK TO TOC
Multimedia Software
●Satellite TV
○DVB-S Free To Air using Video Dis Recorder (VDR)
○ATSC Reception using Video Dis Recorder (VDR)
○Grid And List Style Electronic Program Guides (EPG)
○Customizable User Interface Through Themes
○Comprehensive Digital Video Recording Functionality - Stored on Hard Drive (1)
○Automatic Timer Recording For Series and Daily/Wee ly Programs (1)
○Pause Live TV With Full Fast-Forward and Rewind Capability (1)
○Timer Recording Through Program Guide (1)
●IP TV - Internet TV Streaming Video Player (2)
●P2P TV - Peer To Peer TV Streaming Video Player (2)
●Video - Viewer for popular video formats li e AVI, MPG and even DVD-ISO
●DVD – Viewer for DVD movie media
●Music - Player for popular audio formats including MP3 and WMA
●Pictures - Viewer with popular functions including Slide-show, Zoom and Rotate
●Roaster (1)
○Prepare DVD - Convert HD and SD recordings to DVD-ISO image
○Prepare Video - Create HD or SD MPG-ISO image of recordings
○Burn - Burn DVD-ISO and MPG-ISO images
○Bac up – Create bac ups of CD/DVD media (not currently active)
●Web - Mozilla web browser with support for popular plug-ins including Flash (2)(4)
●Games - Mame game support (1)(5)
●Expandable With Hundreds of Linux Applications
(1) Requires the addition of a Hard Drive.
(2) Networ connection with Internet access required.
(3) Internal networ connection to a PC through a router or crossover networ cable
required
(4) Requires eyboard and mouse
(5) Requires an external download and pac age installation
Dimensions
●The CW-3000HD is 14" wide by 5.5" tall by 15" deep Physical Installation
PAGE 7 BACK TO TOC
Package Contents
1. CW-3000HD Multimedia System
2. Remote Control Unit
3. A/V Connection Cable
4. Power Cable
5. (2) AAA Batteries for Remote Control Unit
6. CD containing system restore image and user manual
System Placement
●Place the system on a stable surface. The unit can be damaged or cause damage if it
were to fall to the floor.
●Place the system in a well ventilated area. The system will generate heat and needs to
have free air movement to eep internal devices from overheating.
●Do not bloc the vents in the case. This is required to allow for free air movement.
●Do not place the system on a carpeted surface. System needs to be on a solid surface.
●System should be placed close to the display device. Optionally, an Internet connection
and satellite feed should be in close proximity to the installation location to use IPTV
and satellite functions of the system.
●If system requires extension cables or cable installation, consult a qualified installer to
ensure signal integrity to the system.
Remote Control Unit
●The remote control unit is used to control all system functions.
●Do not allow the remote control unit to be used in a wet environment. Allowing the
remote control unit to become wet can damage the unit.
●Remove the battery compartment cover on the bac of the unit and insert the included
batteries the remote control unit paying close attention to the battery orientation pictures
inside the battery compartment.
PAGE 8 BACK TO TOC
Cable Connections
Rev. 1
●6 pin DIN Keyboard and Mouse connectors are for use with an optional eyboard/mouse.
●The 4 USB-2 connectors are for connecting external devices to the CW-3000HD. This
allows external USB memory stic s, DVD/CDROM drives, or other USB devices to be
used.
●RJ-45 Networ connector for standard 10/100/1000 connection.
●The green 1/8” mini-jac connector is the stereo analog audio output jac .
●The RCA composite connector is for use with a SDTV.
●The 4 pin DIN S-Video connector is suitable for SDTV.
●The RGB-Video analog connectors for VGA output for use on a suitably equipped HDTV
or computer style monitor.
●The 15pin D-Sub connector is a standard VGA output for use on a suitably equipped
HDTV or computer style monitor.
●The 24 pin DVI-D connector is suitable for 1920x1080P, 1920x1080i, 1280x720P HDTV.
NOTE: It is recommended to use a quality DVI cable no longer than 9 feet.
PAGE 9 BACK TO TOC
Cable Connections
Rev.
●6 pin DIN Keyboard and Mouse connectors are for use with an optional eyboard/mouse.
●The 4 USB-2 connectors are for connecting external devices to the CW-3000HD. This
allows external USB memory stic s, DVD/CDROM drives, or other USB devices to be
used.
●RJ-45 Networ connector for standard 10/100/1000 connection.
●The green 1/8” mini-jac connector is the stereo analog audio output jac .
●The RCA composite connector is for use with a SDTV.
●The 4 pin DIN S-Video connector is suitable for SDTV.
●The RGB-Video analog connectors for VGA output for use on a suitably equipped HDTV
or computer style monitor.
●The 15pin D-Sub connector is a standard VGA output for use on a suitably equipped
HDTV or computer style monitor.
●The 19pin Type-A HDMI connector is suitable for 1920x1080P, 1920x1080i, 1280x720P
HDTV.
NOTE: It is recommended to use a quality HDMI cable no longer than 9 feet.
PAGE 10 BACK TO TOC
Tabla de contenidos
Otros manuales de Receptor de CaptiveWorks
