Caple E72A Manual de usuario

MODEL: E72A

BUILT-IN ELECTRIC OVENS

Installation and operating instructions

Dear Customer,

Thank you for selecting one of our products. We are certain it will respond fully to

your needs and expectations, giving perfect results every time.

Please read this manual carefully. The instructions it contains will enable you to

use the appliance correctly and to best advantage.

The manufacturer accepts no liability for damage to persons or property caused by

incorrect and unsuitable installation.

The manufacturer reserves the right to apply such modifications to the appliance

as are deemed appropriate, without any obligation to notify customers in advance.

-To avoid any possible hazard, the appliance may be installed by qualified personnel

only.

-Any repairs by unqualified persons may result in electric shock or short circuit. In

order to avoid possible injuries to your body or to the appliance, do not attempt

any repairs by qualified service personnel.

-Hot fat is highly inflammable, so pay extra attention when preparing food with

greas or oil.

-Warning! Never let small children in the vicinity of the oven; they are not yet

aware of danger of burns. Older children may use the appliance only under your

surveillance.

-The inside of the oven, also places of potential danger for children.

-Danger of burns! Oven and cooking accessories may become very hot during

operation. To avoid burns use kitchen clothes and gloves when handling hot parts

or utensils.

-Mains leak of adjacent appliances may be damaged by hotplates or if stuck

between the oven doors, and produce short circuit, therefore keep them at safe

distance from the appliance.

-Take extra precautions when grilling. Intensive heat from infrared heater

makes the oven and the accessories extremely hot. Use protective gloves

and barbecue accessories!

-Perforated roast may produce spurting of hot grease (sausages). Use long

grill tongs to prevent skin burns and protect your eyes.

-Supervise the grill at all times. Excessive heat may quickly burn your roast

and provoke fire!

-Do not let the children in the vicinity of the grill.

SAFETY PRECAUTIONS

The oven data plate remains accessible following installation, and is exposed to

view simply by opening the door.

It shows all details needed to identify the appliance, and these must be indicated

when ordering replacement parts.

Given the type and height of this built-in oven, it can be installed only in a full-height

kitchen unit.

Particular care must be given to the instructions on installing the oven in the unit,

especially the indications regarding the size and position of the ventilation opening,

which is essential for proper cooling of the enclosure and of the oven itself.

To guarantee the safety of the user, the unit housing the oven must be manufactured

from materials able to withstand temperatures up to 90 °C. This includes core

materials, laminates, facings and adhesives.

MADE IN EUROPE NUM.

TYPE:

MOD.: E72A V kW

CE M

GENERAL INFORMATION

CONTROL PANEL

- 4 functions (4F+ ø) Electronic Programmer

Electronic programmer

Thermostat Selector Thermostat Selector

- 7 functions (7F+ ø) Electronic Programmer

Thermostat Selector Thermostat Selector

Alarm Timer

Red Orange

light light

Red Orange

light light

- 4 functions (4F+ ø) Timer 0-60

- 7 functions (7F+ ø) Timer 0-60

- 4 functions (4F+ ø) Timer 0-120

- 7 functions (7F+ ø) Timer 0-120

- 4 functions (4F+ ø) Electronic Programmer

- 7 functions (7F+ ø) Electronic Programmer

Cooking Timer

Electronic programmer

TOP OVEN

The oven offers a basic choice between two types of cooking:

A) conventional oven cooking

B) grill (infrared radiant heat)

Selector functions:

Position 0:The oven is swiched OFF

Position 1: Oven interior light (turn to the right)

Position 2: Lower heating element

Set the required temperature between 50 and 250 °C. This setting

is used typically for food to be reheated or warmed.

Position 3: Conventional cooking

Set the required cooking temperature between 50 and 250 °C. The

red light will go out as soon as the selected temperature has been

reached. The oven should be heated before any food is put in to

cook.

Position 4: Grill

Set the thermostat at a temperature between 50 and 250 °C.

The red light will go out as soon as the selected temperature has

been reached.

The oven should be heated for a few minutes before food is put

under the grill. Keep the door closed.

Oven accessories:

Oven grid

Flat biscuit tray

MAIN OVEN

The oven offers a choice between two types of cooking:

A) fan-assisted oven cooking

B) grill (infrared radiant heat).

Selector functions: 4 functions (4F+ ø)

Position 0:The oven is swiched OFF

Position 1: Oven interior light

Position 2: Defreezing

The oven interior light and the orange warning light remain on — as

is normally the case during all other functions of the oven — and

the fan will come into operation, though without any heat being

generated (thermostat off). The oven door must be kept closed.

Using the oven in this way, food will defreeze in a third of the time

normally needed.

Position 3: Fan-assisted cooking

The fan and the relative heating element come into operation, and

heat will be distributed uniformly around the entire chamber at the

temperature selected with the thermostat, between 50 and 250 °C.

The oven should be heated before any food is put in to cook. Different

types of food can be cooked simultaneously.

Position 4: Grill

Set the thermostat at a temperature between 50 and 250 °C.

Keep the oven door closed. This type of grilling is especially suitable

for small quantities of food. Keep the door closed.

Oven accessories:

Oven grid

Grill pan with grid

Handles for grill pan - For removing pan from the oven

Selector functions: 7 functions (7F+ ø)

Position 0:The oven is switched OFF

Position 1: Oven interior light

Position 2: Conventional cooking

Set the required cooking temperature between 50 and 250 °C. The

red light will go out as soon as the selected temperature has been

reached. The oven should be heated before any food is put in to

cook.

Position 3: Traditional cooking + Fan assisted

Set the thermostat between 50 and 250°C.

This cooking mode integrate natural convection and fan.

Cooking mode suited to bake bread, pizzas and lasagne.

Position 4: Fan + Bottom heating element

Set the desired temperature for this very delicate and slow cooking

mode. We suggest you do not pre-heat the oven.

Position 5: Middle Grill

Use the thermostat to the desired temperature between 50 and

250 °C, while keeping the oven door closed. This cooking mode is

ideal for small amounts of food. Keep the door closed.

Position 6: Fan + Double Grill

Set the thermostat to the desired temperature between 50 and 250

°C. Fan operation combined with the grill lets you cook particular

foods quickly and deeply. We suggest you pre-heat the oven for a

few minutes before inserting food. Keep the door closed.

Position 7: Fan-forced cooking

The fan and the relative heating element come into operation, and

heat will be distributed uniformly around the entire chamber at the

temperature selected with the thermostat, between 50 and 250 °C.

The oven should be heated before any food is put in to cook. Different

types of food can be cooked simultaneously.

Oven accessories:

2 x wire shelves

1 x grill pan

COOKING TABLE FOR TOP OVEN - CONVENTIONAL COOKING

IN HEATING SYSTEM WITH TOP AND BOTTOM HEATERS OPERATING. It is

recommended to preheat the oven 10 min.

DISHES LEVEL TEMPERATURE COOKING TIME

Yorkshire Puddin 1 225°C30 - 40 min

Fatless Sponge Cake 1 180°C25 - 30 min

Small Cakes 2 190°C15 - 20 min

Fruit Plate Tart 1 200°C40 - 45 min

Scones 2 220°C10 - 15 min

Rich Fruit Cake 1 140°C2- 3 hours

COOKING TABLE FOR THE TOP OVEN

WITH INFRARED HEATER OPERATING

Grilling is carried out at the door closed. 5 minutes oven preheating is recommended.

Setting possibility from 50 - max (250)°C. Food is placed on the backing pan grid.

DISHES LEVEL TEMPERATURE COOKING TIME

Side 1 Side 2

Pork steaks, Chops (4 pcs) 3 250°C12 min 10 min

Grilled Sausages (6 pcs) 3 250°C6min5min

Toast (6 pcs) 3 250°C

1 min/25 sec. 1 min/10 sec.

COOKING TABLE FOR THE MAIN OVEN

WITH INFRARED HEATER OPERATING

Grilling is carried out at the door closed. 5 minutes oven preheating is recommended.

Setting possibility from 50 - max (250)°C. Food is placed on the backing pan grid.

DISHES LEVEL TEMPERATURE COOKING TIME

Side 1 Side 2

Pork steaks, Chops (4 pcs) Topmost 4 225°C12 min 10 min

Roast beef (4pcs) Topmost 4 225°C10 min 8 min

Grilled Sausages (6 pcs) Topmost 4 225°C 9min 6 min

Toast (6 pcs) Topmost 4 225°C

1 min/50 sec. 1 min/30 sec.

Set the selector for the type of cooking required.

Preheat the oven, setting the thermostat to the required temperature. Once the

oven has heated to the selected temperature, the orange warning light will go out.

This same light will appear again automatically during operation of the oven to

indicate that the heating elements are on.

Remove the drip tray when using the oven for conventional baking, roasting etc.

The tray should be left in place only when using the grill, as its purpose is to catch

falling droplets of fat. Food should be placed in oven dishes with raised edges and

positioned centrally under the grill. If fan-forced operation is selected, foods of

different types can be cooked simultaneously (e.g. meat and fish), although in this

case the respective cooking time must be observed.

If selecting the position, temperatures must be set 10 to 20°C lower than

indicated in the table.

Sweets

Short pastry flan base

Fruit pie/tart

White leavened bread per 1 kg flour

Shortcake biscuits

Savoury biscuits

Lasagne

Meat (cooking time based on thickness)

Slow roast

Quick roast

Meat loaf

Poultry

Duck 1.5 -2 kg

Goose 3 kg

Roast chicken

Turkey 5 kg

Game

Hare

Leg of roebuck

Haunch of venison

Vegetable

Vegetable soufflé

Fish

Pizza

Grills

Pork chop

Sausage

Grilled chicken

Cooking temperatures and times

Temperature

in degrees centigrade

Approximate cooking

time in minutes

175 160

200 190

225 210

175 170

200 190

200 170

200 180

200 190

175 150

200 180

175 175

200 180

180 170

210 200

55-65

8-10

25-35

30-50

10-15

15-20

40-50

12-15

30-40

120-180

150-210

60-90

240 ca.

60-90

90-150

90-180

40-45

20-25

8-12

10-12

25-35

Dish

USING THE OVENS

Tabla de contenidos

Otros manuales de Horno de Caple

Caple

Caple C2160 Manual de usuario

Caple

Caple C2239 Manual de usuario

Caple

Caple C2900 Manual de usuario

Caple

Caple C2234 Manual de usuario

Caple

Caple C2100 Manual de usuario

Caple

Caple C 205 SS Manual de usuario

Caple

Caple BOG623E00X Hoja de especificaciones

Caple

Caple C2512 Manual de usuario

Caple

Caple C2234 Manual de usuario

Caple

Caple C3248 Manual de usuario

Caple

Caple C2401GM Manual de usuario

Caple

Caple LIBERTY C210 F/A Manual de usuario

Caple

Caple C 100 S/W Manual de usuario

Caple

Caple C3400 Manual de usuario

Caple

Caple C2214SS Manual de usuario

Caple

Caple C2471 Manual de usuario

Caple

Caple SO110SS Manual de usuario

Caple

Caple C2231 Manual de usuario

Caple

Caple C2238 Manual

Caple

Caple SO209WH Manual de usuario

Caple

Caple SO110GM Manual de usuario

Caple

Caple C2282 Manual de usuario

Caple

Caple C3371 Manual de usuario

Caple

Caple FAN OVENS Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
