Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk
Built-under larder freezer
instruction manual
RBF4
RBF4 - Instruction Manual.indd 1 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
2
CONTENTS
Warnings 3
Installation warnings 7
Before using your freezer 10
How to operate 10
Food storage 11
Cleaning and maintenance 12
Defrosting the freezer 13
Troubleshooting 14
Energy saving tips 16
Parts of the appliance 17
Installation instructions 18
Electrical connection 26
Technical product fiche 27
Caple contact details 28
RBF4 - Instruction Manual.indd 2 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
3
WARNING:
-Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
-Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
-Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
-Do not damage the refrigerant circuit.
-To avoid a hazard due to the instability of the
appliance, it must be fixed in accordance with
the instructions.
WARNING:
-This appliance uses R600a as a refrigerant. You
should be careful during shipment and installation to
prevent your appliance’s cooler elements from being
damaged. R600a is an environmentally friendly and
natural gas however it is explosive. In the event of a
leak caused by damage to the cooler elements, move
your fridge from open flames or heat sources and
ventilate the room where the appliance is located for
a few minutes.
-Whilst carrying and positioning the fridge, take care
not to damage the cooler gas circuit.
RBF4 - Instruction Manual.indd 3 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
4
-Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
-This product is not designed for commercial use, it is
a household appliance only. It is not intended to be
used in:
• Staff kitchen areas in shops, offices and other working
environments.
• Bed and breakfast type environments.
• By clients in hotels, motels and other residential type
environments.
-If the socket does not match the refrigerator plug, it must
be replaced by a Caple approved engineer or similar
qualified persons in order to avoid a hazard.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
-A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be used
with a specially grounded socket of 13 amps. If there is
no such socket in your house, please have it installed by
an authorized electrician.
-This appliance can be used by children aged from 8
RBF4 - Instruction Manual.indd 4 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
5
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazard involved.
-Children should not play with the appliance.
-Cleaning and user maintenance should not be made by
children without supervision.
-If the supply cord is damaged, it must be replaced by a
Caple approved engineer or similar qualified persons in
order to avoid a hazard.
NOTE:
-Please read the instruction manual carefully before
installing and using your appliance.
-Caple can not be held responsible for damage incurred
due to misuse.
-Follow all instructions on your appliance and instruction
manual, and keep this manual in a safe place to resolve
problems that may occur in the future.
-This appliance is produced to be used in only a domestic
environment and for the specified purposes. It is not
suitable for commercial or common use. Such use will
cause the guarantee of the appliance to be invalid and
Caple will not be responsible for losses incurred.
RBF4 - Instruction Manual.indd 5 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
6
SAFETY WARNINGS
-Do not use multiple sockets or an extension cord.
-Do not plug in damaged, torn or old plugs.
-Do not pull, bend or damage the cord.
-This appliance is designed for use by adults, do not allow
children to play with the appliance or hang on the door.
-Do not plug-in or pull out the plug from the socket with
wet hands to prevent electrocution!
-Do not place glass bottles or beverage cans in the
freezer. Bottles or cans may explode.
-Do not place explosive or flammable material in your
freezer for your safety. Place drinks with higher alcohol
amount vertically and by closing their necks tightly in the
freezer.
-When taking out ice made in the freezer, do not touch it
with bare hands. Ice may cause ice burns and/or cuts.
-Do not touch frozen goods with wet hands! Do not eat
ice-cream and ice cubes immediately after you have
taken them out of the freezer!
-Do not re-freeze frozen goods after they have melted.
This may cause health issues like food poisoning.
-Do not cover the body or top of freezer with lace. This
affects the performance of your freezer.
-Fix the accessories in the freezer during transportation to
prevent damage to accessories.
RBF4 - Instruction Manual.indd 6 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
7
INSTALLATION WARNINGS
Before starting to use your freezer, you should pay
attention to the following points:
-Operating voltage for your freezer is 220-240 V at 50Hz.
-The plug must be accessible after installation.
-There may be an odour when you first switch on the
appliance. It will disappear after the appliance starts to
cool.
-Before making the connection to the power supply,
ensure that the voltage on the rating plate corresponds
to the voltage of electrical system in your home.
-Insert the plug into a socket with an efficient ground
connection. If the socket has no ground contact or the
plug does not match, we suggest you call an authorised
electrician for assistance.
-The appliance must be connected with a properly
installed fused socket. Power supply (AC) and voltage at
the operating point must match with the details on the
rating plate of the appliance.
-We do not take responsibility for damages that occur
due to ungrounded usage.
-Place your freezer in a place where it won’t be exposed
to direct sunlight.
-Your freezer should never be used outdoors or left in the
rain.
RBF4 - Instruction Manual.indd 7 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
8
-Your appliance should be at least 50cm away from hobs,
Gas ovens and heater cores, and should be at least 5cm
away from electrical ovens.
-When your freezer is placed next to a deep freezer,
there should be at least 2cm between them to prevent
humidity on the outer surface.
-Do not place heavy items on the appliance.
-Clean the appliance thoroughly, especially in the interior,
before use (See Cleaning and Maintenance).
-Installation procedure into the kitchen unit is given in the
installation manual. This product is intended to be used
in proper kitchen units only.
-The adjustable front legs should be adjusted to make
sure your appliance is level and stable. You can adjust
the legs by turning them clockwise (or in the opposite
direction). This should be done before placing food in
the fridge.
-Before using your freezer, wipe all parts back with warm
water added with a tea spoonful of sodium bicarbonate,
and then rinse with clean water and dry. Replace all
parts after cleaning.
-The freezer should be placed against a wall with a free
distance not exceeding 75 mm.
RBF4 - Instruction Manual.indd 8 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
9
-ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice. This appliance is marked according to the European directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The symbol
on the product indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this
product, please contact your local council, your household waste disposal service or
the retailer where you purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies
with all applicable legislation, Low Voltage Directive (LVD) and Electromagnetic
Compatibility (EMC).
RBF4 - Instruction Manual.indd 9 23/10/2017 14:28
Instruction manual RBF4
Please keep this instruction manual for future reference
10
BEFORE USING YOUR FREEZER
-When the appliance is situated for the first time or after
transportation, keep your fridge in the upright position for 12 hours
before connecting to the mains electricity. Otherwise, you may
damage the compressor.
-Your fridge may have a smell when it is operated for the first time;
the smell will fade away when your fridge starts to cool.
HOW TO OPERATE THE APPLIANCE
Thermostat setting
The freezer thermostat automatically regulates the inside temperature of the
compartments. By rotating the knob from position 1 to 5, colder temperatures
can be obtained. “•” position shows thermostat is closed and no cooling will be
available.
IMPORTANT NOTE:
Do not try to rotate knob beyond 1 position it will stop your appliance.
Freezer thermostat setting;
1 - 2 : For short-term storage of food in the freezer compartment,
you can set the knob between minimum and medium position.
3 - 4 :For long-term storage of food in the freezer compartment,
you can set knob to medium position.
5 : For freezing fresh foods. The appliance will run for colder temperatures.
NOTE:
The ambient temperature, temperature of the freshly stored food and how often
the door is opened, affects the temperature in the freezer compartments.
If required, change the temperature setting.
RBF4 - Instruction Manual.indd 10 23/10/2017 14:28
Otros manuales para RBF4
1
Tabla de contenidos
Otros manuales de Congelador de Caple
Caple
Caple RI7305 Manual de usuario
Caple
Caple CAFF42 Manual de usuario
Caple
Caple RI5505 Manual de usuario
Caple
Caple RIF1796 Manual de usuario
Caple
Caple RFF730 Manual de usuario
Caple
Caple RIF88 Manual de usuario
Caple
Caple RI555 Manual de usuario
Caple
Caple RI556 Manual de usuario
Caple
Caple C125F Manual de usuario
Caple
Caple CAFF205WH Manual de usuario
Caple
Caple RI5500 Manual de usuario
Caple
Caple CAFF45GM Manual de usuario
Caple
Caple RIF89 Manual de usuario
Caple
Caple RBF5 Manual de usuario
Caple
Caple RIF892 Manual de usuario
Caple
Caple RI734 Manual de usuario
Caple
Caple RI5506 Manual de usuario
Caple
Caple RIF125 Manual de usuario
Caple
Caple RI737 Manual de usuario
Caple
Caple RI7305 Manual de usuario
