User Guide

Canon CR-50 Check Scanner

Updated: 8/18/2014

Other brand and product names are trademarks or registered trademarks of the respective holders.

Canon CR-50 User Guide

Introduction

The Canon CR-50 Check Scanner is one of the newest scanners sold by Shelby Systems. With its combination

of functionality, size, and speed, the Canon CR-50 check scanner is ideal for improving check processing

efficiency at your organization. All of our new scanners offer unmatched image quality and reliability for check

capture at the first point of presentment. This document introduces some of the features of the Canon CR-50

unit and provides an overview of installation and use of the interface with Shelby v.5.

Features

Double-Sided Image Scanning

When the CR-50 check scanner detects a check MICR (Magnetic Ink Character Recognition) number, the

scanner will automatically scan both sides of the check. The endorsement side can easily be viewed in the

Shelby v.5 interface simply by clicking the image and then clicking the Next button.

Electronic Check Processing using Shelby Teller

The Canon CR-50 check scanner integrates fully with Shelby Teller. Shelby Teller is a complete, Check 21-

compatible, electronic, check processing software that fully integrates with your Shelby v.5 data. This unique

system scans and captures images of both the front and back of checks, tithing envelopes, or other financial

documents and allows you to remotely deposit those scanned monies in the bank. For more information or to

purchase Shelby Teller, contact Shelby Systems at (800) 877-0222.

Precise MICR Read

The CR-50 check transport is equipped with a patented magnetic head for high precision MICR reading. It

takes MICR accuracy further by combining MICR reading with OCR processing (MOCR) for a higher level of

accuracy. These capabilities ensure high read rates that mitigate risks associated with digitizing checks.

Electronic Endorsements when using Shelby Teller

A digital endorsement message is added horizontally across the back of check images. The message is

completely customizable; you can choose any endorsement information or instructions. Using this

functionality leaves no risk of questions from the bank regarding smudged or illegible endorsements.

Page 2

Canon CR-50 User Guide

Inherited Cross Check Features

In addition to electronic processing using Shelby Teller, the Canon CR-50 check scanner employs a single

check-by-check feed mode which enables the unit to function similarly to the Cross Check and Cross Check

Plus systems. As with these other models, the CR-50 is used to process donations in the Contributions and

Donors & Gifts applications, process checks in the Accounts Receivable application, reconcile your bank

statement in the Bank Reconciliation application, and process apportionments in the Remittances application.

Installation

Included with the Canon CR-50 Unit

•Ranger Driver and Software CD

•USB Cable

•Power cord

•Power supply

•One ink cartridge

•One-year maintenance agreement

Before You Begin

Before you begin using the Canon CR-50 interface, you must first load the Activation Key for the CR-50 unit

into your Shelby v.5 database. The activation key is sent to each customer via email upon purchasing the

product, or is included with the Shelby Systems software CD for new customers. Loading instructions also

accompany the activation key.

If you need assistance obtaining your activation key or help loading the key, have your official Shelby Systems

Contact (the individual in your organization authorized to interact with Shelby Systems) call Shelby Systems

Support toll-free at (888) 697-4352.

Page 3

Canon CR-50 User Guide

Load Software

1. Insert the Ranger driver and software CD into your computer’s CD-ROM drive.

2. Browse to your CD-ROM drive within My Computer or Windows Explorer.

3. Double-click on the Ranger folder.

4. Double-click on the Setup executable.

5. Follow on-screen instructions and complete the installation wizard.

Connect Scanner

1. Connect power cord to scanner.

2. Connect USB cable to scanner and computer.

3. The LED on the front of the scanner should be lit and the scanner should now be operational. If the LED

is not lit, flip the power switch on the back of the unit by the AC adapter.

Page 4

Canon CR-50 User Guide

Set up Canon CR-50 Scanner in Shelby v.5

Before using the Canon CR-50 check scanner, you must configure the scanner software to accept

supplemental documents (such as giving envelopes) as well as configure the CR-50 Shelby v.5 interface. The

Shelby v.5 configuration utility can be accessed through Contributions, Donors & Gifts, Bank Reconciliation,

Remittances, or Accounts Receivable. The configuration utility is the same in each application, but the

methods of getting to it differ. We will first go over how to get to the utility in each application, and then go

over the configuration process one time.

Configure the Scanner Software

1. Click Start>Programs>Silver Bullet Technology.

2. Click RangerFlex for CR-50_CR-80.

3. Click the Options menu and then Settings.

4. Click on the MICR tab and remove the check from Infrared Double Feed Detection and click OK.

Page 5

Canon CR-50 User Guide

Contributions and Donors & Gifts

1. Open the Contributions/Donors & Gifts application.

2. Click on Contribution Processing (or Gift Processing in Donors & Gifts).

3. Click the Preferences button at the top of the screen.

4. Place a check next to Use Cross Check in the Preference grid.

5. Click on the Test Cross Check tab.

Page 6

Canon CR-50 User Guide

6. Click on the Configure button by the Cross Check field… see “Configuring the Canon CR-50 Check

Scanner” on page 10.

Bank Reconciliation

1. Open the Bank Reconciliation application.

2. Click on the Utility menu and select Preferences.

3. Select Reconcile using Cross Check.

4. Click on the Configure button by the Cross Check field... see “Configuring the Canon CR-50 Check

Scanner” on page 10.

Page 7

Canon CR-50 User Guide

Remittances

1. Open the Remittances application.

2. Click on Remittance Processing.

3. Click the Preferences button at the top of the screen.

4. Place a check next to Use Cross Check in the preference grid.

5. Click on the Configure button by the Cross Check field… see “Configuring the Canon CR-50 Check

Scanner” on page 10.

Page 8

Canon CR-50 User Guide

Accounts Receivable

1. Open the Accounts Receivable application.

2. Click on the Utility menu, then Set Up Information and select Preferences.

3. Place a check next to the Use Cross Check option.

4. Click on the Configure button.

Page 9

Canon CR-50 User Guide

Configuring the Canon CR-50 Check Scanner

1. Click on the Ranger image to select your Canon CR-50 Check Scanner. If you have a check loaded in the

scanner, it will scan automatically and the check information and image will be displayed.

2. Click the Use This Unit button at the upper right. This will return you to the previous screen, and also

pull another item through your scanner.

3. At this point, the scanner is ready for use in the module in which it was configured. Click OK, if

applicable.

Page 10
