Canon TR4600 Series Manual de usuario

입문 가이드

안전 및중요 정보(부록)를먼저 읽으십시오.

入門指南

請首先閱讀「安全與重要資訊」(附錄)。

Hướng dẫn bắt đầu

Trước tiên đọc Thông tin an toàn và quan trọng

(phụ lục).

Mari Memulai

Baca Keamanan dan Informasi Penting (lampiran)

terlebih dahulu.







Getting Started

Read Safety and Important Information

(addendum) rst.

프린터 설치하기...................................................................................................................1페이지

컴퓨터, 스마트폰 또는 태블릿에 연결하기...................................................4페이지

프린터 들기

安裝印表機..................................................................................................................................... 第1頁

連接至電腦、智慧型手機或平板................................................................................. 第4頁

握持印表機

Cài đặt máy in..........................................................................................................................trang 1

Kết nối với máy tính, smartphone hoặc máy tính bảng......................trang 4

Giữ máy in

Memasang Pencetak.........................................................................................................halaman 1

Menghubungkan ke Komputer, Ponsel Pintar atau Tablet........................halaman 4

Memegang Pencetak

..................................................................................................................1

......................................4



Installing the Printer................................................................................................................... page 1

Connecting to a Computer, Smartphone or Tablet ...............................................page 4

Holding the Printer

ENGLISH

Setting Up the Printer

1. Box Contents

•

Ink Cartridges

Color Black

•

Power Cord

•

Phone Cable

•

Setup CD-ROM (E4500 series only)

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing the Orange Tape

1 Remove the orange tape.

2 Open the front cover, and then open the paper

output tray.

3 Open the paper output cover, and then remove

the orange tape.

4 Close the paper output tray and the front cover.

3. Turning on the Printer

1 Connect the power cord.

Back

2 Press the ON button.

For Setup, visit the URL

https://ij.start.canon

or scan the code with your mobile device

•

Follow the instructions below if you do not have an internet connection.

Setting Up the Printer

3 When the following screen appears, use the [

and ]buttons to select a language, and then

press the OK button.

Important

If an error appears on the screen, see "If an error message

(support code) appears on the screen" on page 3 and

follow the instructions.

4 If the following screen appears, select your

country or region, and then press the OK

button.

4. Installing the Ink Cartridges

1 Open the front cover, and then open the paper

output tray.

2 Open the paper output cover.

Caution

Do not touch the ink cartridge holder until it stops moving.

3 Lower the ink cartridge lock lever on the left-

hand side.

4 Remove the Color ink cartridge from the

package and remove the orange tape.

Important

• Do not touch the ink on the orange tape. It could stain your

hands or surrounding objects.

• Do not touch the areas shown in the ﬁgure.

Otherwise, the printer may not print correctly.

5 Insert the Color ink cartridge in the ink cartridge

holder.

Important

Do not bump the ink cartridge. Doing

so may cause a malfunction.

ENGLISH

6 Raise the ink cartridge lock lever.

7 Repeat steps 3 to 6 and install the Black ink

cartridge on the right-hand side.

8 Close the paper output tray and the front cover.

9 Follow the on-screen instructions, and then

press the OK button.

Select the connection method that best matches how you

will use the printer.

• To use the printer without connecting to any other

devices

Setup is now complete.

To set up a fax, see "Using Fax Function" on page

• To use the printer connecting to a computer or

smartphone

Proceed to the next page.

Check the support code, and then follow the

instructions if the displayed code is written below.

• 1890

Protective material remaining.

"2. Removing the Orange Tape" on page 1

• 168A

Ink cartridges are not installed correctly.

"4. Installing the Ink Cartridges" on page 2

For all other cases, refer to the Online Manual.

If an error message (support code) appears on

the screen

Support code

5-a

Setting Up the Printer

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from your computer.

2 Select Set Up.

3 Enter your printer's model name and click Go.

4 Click Start, and then select Connecting to a Computer/Smartphone.

• The following steps are for Windows users.

5 Click Download.

6 Run the downloaded le.

• Follow the on-screen instructions. This may take some time.

• To connect to a smartphone as well, see "5-b. Connecting to a Smartphone" on page 5.

• Once you have added your printer, you can print from your Computer. To print, see "Loading Paper"

on page 6.

• To set up a fax, see "Using Fax Function" on page 5.

What device are you connecting?

5-a Connecting to a Computer

Using the Setup CD-ROM (E4500 series only)

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install the

printer driver.

5-b

ENGLISH

5-b. Connecting to a Smartphone

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Search for "Canon PRINT" in App Store, or Google Play.

• Access the Canon website to download the app.

2 Open the installed app, and follow the on-screen instructions in the app to add your

printer.

• Once you have added your printer, you can print from your smartphone. To print photos, see

"Loading Paper" on page 6.

• To set up a fax, see "Using Fax Function" on page 5.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Using Fax Function

The fax function of your printer requires setup. Refer to FAX Setup Guide.

1 Access the Canon website.

Loading Paper

If Print Results Are Unsatisfactory

Perform Print Head Alignment if straight lines are crooked or colors are inconsistent, or print results are otherwise not what you

expected.

For details, click Maintenance on the Online Manual and refer to If Printing Is Faint or Uneven > Aligning the Print Head.

Refer to the back cover for how to access the Online Manual.

■Lines Are Misaligned ■Uneven or Streaked Colors

1 Open the front cover.

2 Slide the right-hand side paper guide to the far

right.

3 Load several sheets of paper with the print side

facing down, and slide the paper guide against

the edge of the paper stack.

• Push the paper all the way into the cassette.

4 Open the paper output tray.

5 Pull out the paper output support of the paper

output tray.

6 Open the output tray extension.

7 When the following screen appears, press the

OK button.

8 Select the paper size and type, and press the OK

button.

ภาษาไทย



1

•





•



•



•



•

 

•

 

2

1 



2    

3   



4   

3

1 

 

2  







  

•

  



3   

 []

 OK



  

  

3

4  

  OK

4 

1    

2  

 



3   



4 







• 





• 

  

5  





 
