PIXMA iP5300

Service Manual

Revision 0

QY8-13BB-000

󲩷

Scope

This manual has been issued by Canon Inc., to provide the service technicians of this product with the

information necessary for qualified persons to learn technical theory, installation, maintenance, and

repair of products. The manual covers information applicable in all regions where the product is sold. For

this reason, it may contain information that is not applicable to your region.

Revision

This manual could include technical inaccuracies or typographical errors due to improvements or

changes made to the product. When changes are made to the contents of the manual, Canon will release

technical information when necessary. When substantial changes are made to the contents of the manual,

Canon will issue a revised edition.

The following do not apply if they do not conform to the laws and regulations of the region where the

manual or product is used:

Trademarks

Product and brand names appearing in this manual are registered trademarks or trademarks of the

respective holders.

translated into another language without the written permission of Canon Inc., except in the case of

internal business use.

󲩷

CANON INC.

Inkjet Device Quality Assurance Div. 2

451, Tsukagoshi 3-chome, Saiwai-ku, Kawasaki-shi, Kanagawa 212-8530, Japan

I. MANUAL OUTLINE

PIXMA iP5300

This manual consists of the following three parts to provide information necessary to service the PIXMA iP5300:

Part 1: Maintenance

Information on maintenance and troubleshooting of the PIXMA iP5300

Part 2: Technical Reference

New technology and technical information such as FAQ's (Frequently Asked Questions) of the PIXMA iP530

Part 3: Appendix

Block diagrams and pin layouts of the PIXMA iP5300

Reference This manual does not provide sufficient information for disassembly and reassembly procedures.

Refer to the graphics in the separate Parts Catalog.

<I. MANUAL OUTLINE>

II. TABLE OF CONTENTS

Part 1: MAINTENANCE

1. MAINTENANCE

1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by

Service Engineer

1-2. Customer Maintenance

1-3. Product Life

1-4. Special Tools

1-5. Serial Number Location

2. LIST OF ERROR DISPLAY / INDICATION

2-1. Operator Call Errors

2-2. Service Call Errors

2-3. Warnings

2-4. Troubleshooting by Symptom

3. REPAIR

3-1. Notes on Service Part Replacement

3-2. Special Notes on Repair Servicing

3-3. Adjustment / Settings

(1) Paper feed motor adjustment

(2) Grease application

(3) Ink absorber counter setting

(4) User mode

(5) Service mode

Service test print, EEPROM initialization, Ink absorber counter resetting

Destination setting

LF / Eject correction

Left margin correction

3-4. Verification Items

(1) Service test print

(2) EEPROM information print

4. MACHINE TRANSPORTATION

Part 2: TECHNICAL REFERENCE

1. NEW TECHNOLOGIES

2. CLEANING MODE AND AMOUNT OF INK PURGED

2-1. Cleaning

2-2. Moisturizing Timer Sequence

3. PRINT MODE

4. FAQ (Problems Specific to the iP5300 and Corrective Actions)

Part 3: APPENDIX

1. BLOCK DIAGRAM

2. CONNECTOR LOCATION AND PIN LAYOUT

2-1. Logic Boar

PIXMA iP5300

2-2. Carriage Board (Print Head Connector)

3. PIXMA iP5300 SPECIFICATIONS

<II. TABLE OF CONTENTS>

Part 1

MAINTENANCE

PIXMA iP5300 TABLE OF CONTENTS

1. MAINTENANCE

1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement

Consumables by Service Engineer

(1) Adjustment

* LF and eject corrections are performed at the same time.

Caution: DO NOT loosen the red screws at both ends of the carriage shaft, securing the print head position, as they

are not re-adjustable.

The red screws securing the paper feed motor may be loosened only at replacement of the paper feed

motor unit.

Part 1: MAINTENANCE TABLE OF CONTENTS

Adjustment Timing Purpose Tool Approx.

time

Destination settings

(EEPROM settings) - At logic board

replacement To set destination. None.

Perform in

the service

mode.

1 min.

Ink absorber counter

resetting

(EEPROM settings)

- At logic board replacement

- At ink absorber

replacement

To reset the ink absorber counter. None.

Perform in

the service

mode.

1 min.

Paper feed motor

position adjustment - At paper feed motor

replacement To adjust the belt tension.

(Position the paper feed motor so that

the belt is stretched tight.)

None. 5 min.

CD / DVD detection

sensor light volume

correction

- At logic board replacement

- At carriage unit

replacement

To correct the light volume for the

CD / DVD detection sensor. None.

Perform in

the service

mode.

2 min.

Grease application - At carriage unit

replacement

- At lift cam replacement

- To gears

To maintain sliding properties of the

following items:

- Carriage shaft

- Lift cam bushing

- Printer sliding portions (gears)

FLOIL KG-

107A 1 min.

Ink system function

check - At logic board replacement

- At platen unit replacement

- At carriage unit

replacement

To maintain detection functionality for

presence of the ink tanks and each ink

tank position.

None.

Perform in

the service

mode.

1 min.

LF correction - At logic board replacement

- At feed roller ass'y

replacement

To correct line feeding. None.

Perform in

the service

mode.

5 min.*

New Eject correction - At logic board replacement

- At platen unit replacement

To maintain the paper eject accuracy None.

(2) Periodic maintenance

No periodic maintenance is necessary.

(3) Periodic replacement parts

There are no parts in this printer that require periodic replacement by a service engineer.

(4) Replacement consumables

There are no consumables that require replacement by a service engineer.

1-2. Customer Maintenance

Adjustment Timing Purpose Tool A

rox.

time

Automatic print

head alignment - At print head replacement

- When print quality is not satisfying,

and not improved by print head

cleaning.

To secure the dot

placement

accuracy.

- 2 sheets of Matte Photo Paper

(MP-101)

- Printer buttons

- Computer (automatic

alignment via printer driver)

13 min.

Manual print head

alignment - At print head replacement

- When print quality is not satisfying,

and not improved by print head

cleaning.

To secure the dot

placement

accuracy.

- 5 sheets of plain paper

- Printer buttons

- Computer (printer driver with

the manual print head

alignment selected)

15 min.

Print head

cleaning When print quality is not satisfying. To improve

nozzle conditions. - Printer buttons

- Computer (printer driver)

1 min.

Print head deep

cleaning When print quality is not satisfying,

and not improved by print head

cleaning.

To improve

nozzle conditions. - Computer (printer driver) 2 min.

Ink tank

replacement When an ink tank becomes empty.

("No ink error" displayed on the

monitor, or short flashing of an ink

tank LED)

――2 min.

Paper feed roller

cleaning When paper does not feed properly. To clean the

paper feed rollers. - Printer buttons 2 min.

CD / DVD print

position

adjustment

At CD / DVD printing, when

necessary. To correct CD /

DVD print

position.

- Computer (application

software) 5 min.

Bottom plate

cleaning When the back side of the paper is

smeared. To clean the

platen ribs. - Plain paper

- Computer (printer driver)

1 min.

ASF sub- roller

cleaning When the paper fed from the ASF is

smeared due to ink mist attached to the

ASF sub-rollers.

To clean the ASF

sub-rollers. - Plain paper

- Printer buttons

See Part 2, 4. FAQ, How to

make and set the ASF sub-

roller cleaning sheet, for

details.

1 min.

1-3. Product Life

(1) Printer

Specified print volume (I) or the years of use (II), whichever comes first.

(I) Print volume: 21,000 pages

(II) Years of use: 5 years of use

(2) Print head

Print volume: 28,560 pages

(3) Ink tank (target value)

*1: Declared yield value in accordance with ISO/IEC FCD24711. Values obtained by continuous printing.

*2: When printing Canon standard patterns on 4" x 6" Photo Paper Plus Glossy continuously with the default settings

of Photo Paper Plus Glossy using Windows XP printer driver in borderless printing mode and Windows XP Photo

Printing Wizard. Declared yield value determined based on Canon standard method referring to ISO/IEC

FCD24712.

Note: Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper

used.

1-4. Special Tools

1-5. Serial Number Location

Black 1500 character pattern 8,400 pages

Color 7.5% duty per color pattern 6,300 pages

A4, photo, borderless printing 400 pages

4 x 6, photo, borderless printing 4,400 pages

Postcard, photo, borderless printing 1,500 pages

Avera

ield

( ): Estimated supplemental yield PGI-5BK CLI-8BK CLI-8C CLI-8M CLI-8Y

Color document (ISO/IEC FCD24712)

*1 530 pages (5,395

pages) 890 pages 695 pages 710 pages

Photo (4" x 6")*2 (4,340

pages) (1,600

pages) 436 pages 290 pages 331 pages

Name Tool No. Price

(JPY) Application Remarks

FLOIL KG-107A QY9-0057-000 210 To the carriage shaft sliding portions, and

lift cam bushing In common with the

S520.

On the carriage flexible cable holder (visible on the right of the carriage after the printer is turned on, the top cover

is opened, and the carriage moves to the center).

2. LIST OF ERROR DISPLAY / INDICATION

Errors are indicated by the LED, and warnings are displayed on the monitor of the computer connected to the

printer.

2-1. Operator Call Errors (by Alarm LED Blinking in Orange)

Part 1: MAINTENANCE TABLE OF CONTENTS

LED

blinking Error

[Error code] Solution Remarks

2 times

No paper in the ASF.

[1000] Set the paper in the ASF, and press the

Resume/Cancel button.

No CD / DVD tray.

[1001] Set the CD / DVD tray, and press the

Resume/Cancel button.

No paper in the cassette.

[1003] Set the paper in the cassette, and press the

Resume/Cancel button.

No CD or DVD. [1002] Set a CD or DVD in the CD / DVD tray

(which is ejected at error occurrence), and

inset the CD / DVD tray in the proper

position. Then, press the Resume/Cancel

button.

3 times

Paper jam. [1300] Remove the jammed paper, and press the

Resume/Cancel button. Error during paper feeding from the

ASF

Paper jam in the rear

guide. [1303]

Error in the duplexing transport unit

Paper jam in the under

guide. [1304]

Error during paper feeding from the

cassette

Front door close error.

[1250] Open the paper output tray. The error is indicated if the paper

output tray is closed at start of a print

job, or while a print job is being

performed.

4 times

Ink may have run out.

[1600] Replace the applicable ink tank, or press the

Resume/Cancel button to clear the error

without ink tank replacement.

When the error is cleared by pressing

the Resume/Cancel button, ink may

run out during printing.

Ink tank not installed.

[1660] Install the applicable ink tank(s) properly,

and confirm that the LED's of all the ink

tanks light red.

5 times - Print head not installed,

or not properly

installed. [1401]

- Print head temperature

sensor error. [1403]

- Faulty EEPROM data of

the print head. [1405]

- Print head hardware

error. [1682]

Install the print head properly.

6 times

Inner cover open during

printing on paper (print

continuable). [1851]

Close the inner cover, and press the

Resume/Cancel button.

Inner cover open during Close the inner cover, and press the

Otros manuales para PIXMA IP5300

Tabla de contenidos

Otros manuales de Impresora de Canon

Canon

Canon imageCLASS MF200 Series Manual de usuario

Canon

Canon iP4200 - PIXMA Photo Printer Manual de usuario

Canon

Canon LBP-810 Manual de usuario

Canon

Canon imagePROGRAF iPF9400 Manual de usuario

Canon

Canon MB2100 Series Manual de usuario

Canon

Canon PRO-500 Series Guía de configuración

Canon

Canon iPF500 - imagePROGRAF Color Inkjet Printer Manual de usuario

Canon

Canon imageclass MF216N Manual de usuario

Canon

Canon PIXMA iP2000 Series Instrucciones de uso

Canon

Canon imageCLASS X LBP1238 Manual de usuario

Canon

Canon TR8500 Series Manual de usuario

Canon

Canon PIXMA TS9140 Manual de usuario

Canon

Canon PIXMA MG6120 Series Manual

Canon

Canon PIXMA MP810 Manual de usuario

Canon

Canon LX-D5500 Manual de usuario

Canon

Canon LX-P1300 Manual de usuario

Canon

Canon imageRUNNER ADVANCE C3330 Series Manual de uso y cuidado

Canon

Canon iPF500 - imagePROGRAF Color Inkjet Printer Manual de usuario

Canon

Canon imageRUNNER 1019j Manual de usuario

Canon

Canon BJC-3000 Series Manual

Canon

Canon CLBP360PS Ver-up Manual de usuario

Canon

Canon BJ330 - BJ 330 B/W Inkjet Printer Manual de usuario

Canon

Canon PIXMA MX420 Series Instrucciones de uso

Canon

Canon BJ-10sx Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario

Epson

Epson Stylus Photo PX700W Instrucciones de montaje

Ricoh

Ricoh SP204SF Manual de usuario

Star Micronics

Star Micronics futurePRNT TSP100 Manual de usuario

Epson

Epson TM-TM88V-i Manual de uso y cuidado
