Canon PIXMA MX722 Manual de instrucciones

Getting Your Multifunction

Back On Your Network

After A Router Or Network Change

PIXMA MX722

Windows OS

If any of the following situations exist , the printer will need to be setup again

•You have replaced your Router or Access Point

•You want to use a different wireless network

•Router settings have been changed.

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions and do not remove the

Setup CD-ROM during restarting. The installation resumes once your computer has restarted.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to

access the network. If such a warning message appears, set the security software to always allow access.

Connecting to the Network

Continue to the next page for setup instructions.

Installing the Drivers & Software

<< Previous Next >>

Installing the PIXMA MX722 on Your Wireless Network

The re-setup procedure when you have changed networks, access point or router is the same as a first-time setup

Insert the Setup CD-ROM * that came with your printer into your CD-ROM drive and proceed through the easy to follow instructions.

If the following screen appears, select Start Setup Again.

When the Connection Method Selection screens (Steps 1-1 and 1-2) appear, select Network Connection and then Wireless Connection

Connecting to the Wireless Network

<< Previous Next >>

Continue to follow instructions until the Printer Setup screen (Step 2-1) appears. This is shown on the next page

Click Connect to the network on the Printer Setup screen (2-1).

Connecting to the Wireless Network

<< Previous Next >>

Continue to follow instructions until the Setup Procedure Selection screen (Step 3-1)appears. This is shown on the next page

The printer automatically searches for access points that support WPS (Wi-Fi Protected Setup)*.

*Unless you are absolutely sure your access point supports WPS and you are familiar with activating this on your access point, press the Stop

button on the printer’s operation panel and click on Other Methods on the Setup Procedure Selection screen (screenshot shown below)*.

If the Push Button Method is not shown on the printer’s operation panel(when no WPS access points have been detected), select Standard

setup on the printers operation panel, then click Other Methods on the Setup Procedure Selection screen

Connecting to the Wireless Network

<< Previous Next >>

If you selected the Push Button Method, follow any

remaining instructions to complete setup. Click here to skip

ahead

If you selected Other Methods, please continue to the next

page for important information

Connecting to the Wireless Network

<< Previous Next >>

For Standard setup only

Select Standard setup on the Setup Procedure Selection screen (3-2)

Continue to next page before proceeding any further with setup

Connecting to the Wireless Network

<< Previous Next >>

Follow On-screen instructions. When you get to Step 4-2 and later in Step 4-4 ( screens shown below) you will need to know SSID and

password information*

Step 4-2 Step 4-4

*Unless you are absolutely certain of this information, please continue to the next page for information on locating /

verifying this information

Connecting to the Wireless Network

<< Previous Next >>

If you don't know your Access Point / Router name or SSID*, or the Passphrase or Network key for your wireless network, you can find this

information during Standard setup using the Setup CD-ROM or the downloaded files (Mini Master Setup or Master Setup).

*The terms 'SSID' and 'AccessPoint / Router' refer to a name used to identify the specific Access Point or Router. "Passphrase' and 'Network

Key' refer to a password required to prevent unauthorized access to communication.

Look for the Confirm the access point name or the Confirm the network key (automatic display) buttons during the setup procedure.

Clicking either of these buttons will give the needed information. See example below of the Wireless Lan Setup Information window.

(appearance varies depending on Operating System). Use the provided information when selecting the Access Point / Router and for

entering the Network Key.

Installing the Drivers & Software

<< Previous Next >>

Network setup is complete. Continue to follow any remaining On-screen instructions to install the software. On the Software Installation List

screen, select any software to be installed. MP Drivers is required for the printer to be able to print and scan and cannot be de-selected. My

Image Garden and Quick Menu are highly recommended to take full advantage of your printer’s features. If you’ve already installed these

programs on the original installation, it is not necessary to install them again , only MP Drivers is required.

Follow any remaining On-Screen instructions.
