Canon PIXMA G7000 Series Manual de usuario

입문 가이드

안전 및중요 정보(부록)를먼저 읽으십시오.

入門指南

請首先閱讀「安全與重要資訊」(附錄)。

Hưng dn bt đu

Trưc tiên đc Thông tin an ton v quan trng

(ph lc).

Mari Memulai

Baca Keamanan dan Informasi Penting (lampiran)

terlebih dahulu.







Getting Started

Read Safety and Important Information

(addendum) rst.

프린터 설치하기...................................................................................................................1페이지

컴퓨터, 스마트폰 또는 태블릿에 연결하기...................................................4페이지

사용 설명 동영상

프린터 들기

安裝印表機......................................................................................................................................第1頁

連接至電腦、智慧型手機或平板..................................................................................第4頁

說明視訊

握持印表機

Ci đt my in..........................................................................................................................trang 1

Kt ni vi my tnh, smartphone hoc my tnh bng......................trang 4

Video hưng dn

Gi my in

Memasang Pencetak.........................................................................................................halaman 1

Menghubungkan ke Komputer, Ponsel Pintar atau Tablet.......................halaman 4

Video Instruksi

Memegang Pencetak

..................................................................................................................1

......................................4

 



Installing the Printer................................................................................................................... page 1

Connecting to a Computer, Smartphone or Tablet ...............................................page 4

Holding the Printer

Instructional Videos

ENGLISH

Setting Up the Printer Online Setup

1. Box Contents

•

Print heads •

Ink bottles

•

Power cord

•

Modular cable

•

Setup CD-ROM for Windows

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

3. Installing the Print Heads

1 Open the print head locking cover.

2 Take out each print head from the package and

remove the label.

3 Remove the protective tape.

4 Insert the C (color) print head on the left and the

B (black) print head on the right.

5 Close the print head locking cover and press

down until it clicks.

6 Press down both joint buttons completely until

they click.

Check!

Setting Up the Printer

4. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are lled with ink. If ink gets on your clothes or

belongings, it may not come o.

1 Open the ink tank cover and tank cap on the left

of the printer.

2 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

PGBK

3 Align the nozzle of the ink bottle with the inlet.

4 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

5 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

6 Replace the tank cap securely, and then close

the ink tank cover.

7 Repeat steps 1 through 6 to pour all ink into the

corresponding ink tanks on the right.

Check!

CMY

8 Close the scanning unit / cover.

Caution

Watch your ngers.

5. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Open the operation panel and press the ON

button.

ENGLISH

3 When the following screen appears, use the [

and ]buttons to select a language, and then

press the OK button.

Important

If an error appears on the screen, see "If an error message

(support code) appears on the screen" on page 3 and

follow the instructions.

4 If the country or region selection screen

appears, use the [and ]buttons to select

your country or region, and then press the OK

button.

6. Loading Paper

1 When the following screen appears, use the [

and ]buttons to select Yes, and then press the

OK button.

2 Remove the cassette from the printer.

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

4 Load paper.

• Load 2 or more sheets of Letter or A4 sized plain

paper with the print side facing down.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

5 Replace the cassette.

6 Pull out the paper output tray.

7 Follow the on-screen instructions, and then

press the OK button.

• Check that Ready to connect appears on the

printer's screen.

Check the support code, and then follow the

instructions if the displayed code is written below.

• 1890

The protective materials are not removed.

"2. Removing Packing Materials" on page 1

• 1470

The print heads are not installed correctly.

"3. Installing the Print Heads" on page 1

• 1471

No print heads are installed.

"3. Installing the Print Heads" on page 1

• 1642

There may be insucient ink.

"4. Pouring Ink" on page 2

For all other cases, refer to the Online Manual.

If an error message (support code) appears on

the screen

Support code

Setting Up the Printer

7-a

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

4 Click Start.

5 Click If you have already prepared

your printer, go to Connect.

Note

The following steps are for Windows (except

Windows 10 in S mode) and macOS users. For other

operating systems, continue setup by following the

on-screen instructions instead.

6 Click Download.

7 Run the downloaded le.

8 Click Start Setup.

9 Follow the on-screen instructions.

• These operations may take some time.

• To connect to a smartphone as well, see "7-b.

Connecting to a Smartphone" on page 5.

Using the Setup CD-ROM for Windows

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install

the printer driver.

What device are you connecting?

7-a.Connecting to a Computer

Not connecting to any other devices 7-c

ENGLISH

7-b

1 Install the "Canon PRINT Inkjet/SELPHY"

app on your smartphone.

• Scan the QR code shown on

the right to access the Canon

website, and then download

the app.

2 Open your smartphone's Wi-Fi settings.

Tap the network name (SSID) that starts

with "Canon_ij_".

If "Canon_ij_" does not appear, proceed

to step 3.

(Example of iOS screen)

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone.

bConnect your smartphone to the wireless router (if you have a wireless router).

Refer to your smartphone and wireless router manuals for more details.

Once you have added your printer, you can print from your smartphone.

To print photos, see "Loading Photo Paper" on page 6.

7-b.Connecting to a Smartphone

3 Open the installed app.

4 Follow the on-screen instructions in the

app to add your printer.

7-c Do Not Connect To A Device

1 Press the Stop button.

2 Select Do not connect, and then press the OK button.

3 Select Ye s, and then press the OK button.

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up.

4 Align the paper guide to the paper, and then

close the feed slot cover.

• Follow the on-screen instructions to set information

for the loaded paper.

5 When Save the rear tray paper information

appears on the printer's screen, press the OK

button.

6 Select the paper size and type, and press the OK

button.

Transporting Your Printer

Photo paper can only be loaded in the rear tray.

When relocating the printer, make sure of the following. Refer to the Online Manual for details.

Check that both joint buttons are pressed down

completely to avoid ink leaks.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using sucient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains at

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

ภาษาไทย



1

•

 •



•



•



•

Windows

•

 

•

 

2

1  

 

2  



 

3 

1  

2 

3 

4   

B

 

5  

 

6    







4

 

  



  

 



1    





2  





PGBK

3  

4  



•  



5 

•  

6  



7 

 



C M Y

8  

 



5

1 

 

 



2   

Otros manuales para PIXMA G7000 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Impresora de Canon

Canon

Canon Pixma TR150 Manual de usuario

Canon

Canon iP8500 - PIXMA Color Inkjet Printer Manual de usuario

Canon

Canon Selphy CP720 Manual de usuario

Canon

Canon PIXMA MP497 Manual de usuario

Canon

Canon imagePASS-N1 Manual de usuario

Canon

Canon image Prograf iPF785 Series Guía del usuario

Canon

Canon BJC-55 Series Manual de referencia

Canon

Canon MP-90 Manual de usuario

Canon

Canon MG3600 series Manual de usuario

Canon

Canon PIXMA G2070 Series Guía de configuración

Canon

Canon imageRUNNER 1643iF Manual de usuario

Canon

Canon LBP6020 Manual de usuario

Canon

Canon i960 Series Manual

Canon

Canon imageClass LBP320 Series Manual de usuario

Canon

Canon LBP-3260 Instrucciones de instalación

Canon

Canon i250 Series Manual de usuario

Canon

Canon BJC-S820 Manual

Canon

Canon S9000 Manual de usuario

Canon

Canon NP6320 Manual de usuario

Canon

Canon PIXMA TS302 Guía de configuración

Canon

Canon PIXMA MG7500 Series Manual de usuario

Canon

Canon PIXMA MG8170 Manual de usuario

Canon

Canon iP110B Guía de configuración

Canon

Canon Satera LBP5610 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario

Epson

Epson Stylus Photo PX700W Instrucciones de montaje

Ricoh

Ricoh SP204SF Manual de usuario

Star Micronics

Star Micronics futurePRNT TSP100 Manual de usuario

Epson

Epson TM-TM88V-i Manual de uso y cuidado
