Canon MF553dw Manual de usuario

Setup Guide

• After you finish reading this guide, store it in a safe

place for future reference.

• The information in this guide is subject to change

without notice.

https://oip.manual.canon/

1Important Safety Instructions

Be sure to read these instructions before using

the machine.

3User's Guide / FAQ

2Setup Guide (this document)

1234567 11

Unless otherwise stated, illustrations used in this

document are for the MF553dw.

Checking the Items

Included

* May not be

included with

some models.

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

2. Remove all packing material.

Remove all of the tape.

Do not remove the sticker that covers the USB

port until you actually use the USB port.

Loading Paper

1 2 3 4 5 6 7 11

A4/A5 A4/LGL

Ensure that the amount

of paper loaded is not

above this line

Installing the Optional

Part

If you are not using optional part, proceed to

step .

Before Installing the Optional Part

When installing the optional part after the machine has

been installed, perform the following before starting work:

1. Shut down the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Paper Feeder

1. Install the paper feeder in the location

where it will be used.

234567 111

• You can stack up to three paper feeders.

Handset

* The handset cannot be used with some models.

Insert the attached pin

halfway (Do not insert it

all the way in here).

Insert the pin all

the way in.

56789 111

Connecting the Power Cord

Specifying the Basic

Settings

When you turn on the machine for the first time, the Setup

Guide appears on the operation panel. Perform the initial

machine setup by following the on-screen instructions.

Operation panel

1. Select the language, then the country/

region and finally the time zone.

2. Set the current date/time.

Specifying the Security

Settings

Specify the basic security settings to prevent unauthorized

access to the machine.

1. To use the Remote UI, select <Yes>.

To continue without using the Remote UI, select

<No> and proceed to step 8.

2. To use System Manager mode, select <Yes>.

• Set the System Manager ID and PIN so that you

can configure the settings for extended functions

and the management of access privileges, etc.

• To continue without using System Manager

mode, select <No> and proceed to step 5.

3. Set the System Manager ID.

Enter any number and then select <Apply>.

4. Set the System Manager PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

5. To use General User mode, select <Yes>.

• Set the PIN to be used by general users to access

the Remote UI.

• To continue without using General User mode,

select <No> and proceed to step 8.

6. Set the Remote UI Access PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

Wireless LAN

1. Check the router's "SSID" and "Network

key."

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. To configure the settings, select <Yes> on

the operation panel.

3. Check the message and select <OK>.

5678 109111

4. Select the network with a matching SSID.

5. Enter the password (network key) and select

<Apply>.

Wired LAN

Connect the router to the machine with a LAN cable and

then select <No> in the screen for choosing how to

connect to the network.

Ending the Setup Guide

Check the description in the Application Library and then

select <End>.

Installing the Software/

Drivers

Install the software and drivers from the CD/DVD-ROM

included, or visit the URL below and download them from

the Canon website for your country/region.

https://global.canon/en/support/

Example: MF553dw download

XXXXXXX download

On models with a fax function,

configure the fax settings next.

7 8 9 115 6 101

Fax Setup *These settings do not appear on models without a fax function.

The first time you select <Fax> on the Home screen, the Fax Setup Guide starts up.

Setup Procedure

1. Select <Fax> on the Home screen.

2. Select <Set Up Now>.

3. Select <Next>.

4. Enter the Unit Telephone Number and

select <Apply>.

5. Select <Next>.

6. Enter the Unit Name (name and company

name, etc.) and select <Apply>.

7. Select the receive mode that best suits your

telephone connection and the way you

receive calls.

Refer to the illustration below and select <Yes> or

<No>. Finally, select <Apply> to set the receive

mode.

8. Connect the machine to a telephone line.

Telephone line jack

Handset (optional part)

Telephone

9. When you have completed the connection,

select <End>.

10. Select <Yes>.

Selecting the Receive Mode

Do you want to

connect a telephone?

Do you want to use

an answering machine?

For fax use only. Receives faxes automatically.

Can be used for both fax and phone. Uses an

answering machine function to record phone

messages while you are away. Receives faxes

automatically.

Can be used for both fax and phone. Receives faxes

automatically.

Can be used for both fax and phone. Allows you to

check for incoming faxes and receive them manually.

Auto

Answering Machine

Fax/Tel (Auto Switch)

Manual

Do you want to receive

faxes automatically?

Yes

Start

• Après avoir lu ce guide, rangez-le dans un

endroit sûr pour information.

• Les informations figurant dans ce guide sont

sujettes à modifications sans préavis.

https://oip.manual.canon/

3Guide de l'utilisateur / FAQ

Consignes de sécurité importantes

Veillez à lire ces instructions avant d'utiliser l'appareil.

2Guide de configuration

(ce document)

Guide de

configuration

1234567 11

Sauf indication contraire, les illustrations utilisées

dans ce document sont pour le modèle MF553dw.

Vérification des articles

inclus

* Non inclus

avec certains

modèles.

Retrait du matériel

d'emballage

1. Installez l'appareil là où il sera utilisé.

2. Retirez tout le matériel d'emballage.

Retirez tout le ruban adhésif.

Ne retirez l'autocollant qui recouvre le port USB qui

si vous avez besoin d'utiliser le port USB.

Chargement du papier
