Canon ImageCLASS D530 Guía de seguridad

Starter Guide

Read this guide ﬁrst.

Please read this guide before operating this product. The remarks for important safety instructions are described in the Basic

Operation Guide. After you ﬁnish reading the Starter Guide, store it in a safe place for future reference.

Connecting to a Computer

and Installing the Drivers

P.12

Preface

P.2

Installing the Machine

P.4

Checking the Supplied Accessories

Conﬁrm that all the supplied accessories are contained in the box. If an item is missing or damaged, please contact the Canon

Authorized Service Facilities or the Canon Customer Care Center.

About the USB Cable

The machine does not come with a USB cable. Have a USB

cable ready as needed.

Supplied Toner Cartridge

• The included "Canon Cartridge 128 Starter" can print an

average yield of 1,000 sheets*. The average yield of the

replacement toner cartridge diﬀers from the supplied toner

cartridge.

• To purchase replacement toner cartridges:

"Replacement Toner Cartridges" in the e-Manual

* The average yield is based on "ISO/IEC 19752" when printing A4

size paper with the default printing density.

User Software CD-ROM

The User Software CD-ROM contains the MF Drivers, MF

Toolbox, various software, and the e-Manual.*

MF Drivers

The MF Driver contains the printer and scanner drivers.

MF Toolbox

The MF Toolbox provides a group of commands for you,

such as to open a scanned image in an application, send it

as an e-mail attachment ﬁle, and store it on the hard disk.

Miscellaneous Software

The User Software CD-ROM contains Presto! PageManager.

Install it from the [Custom Installation] option.

* See "Using the e-Manual" (P.18).

Starter Guide

Sta

Basic Operation Guide

Power Cord

User Software CD-ROM

Limited Warranty Notice

Machine Unit

Registration Card

The toner cartridge is already installed.

Checking the Supplied Accessories

Preface Installing the Machine

Connecting to a Computer and Installing the Drivers

Included Documents

Printed Manuals

Sta

This manual

Starter Guide

This manual describes the conﬁguration and software installation.

Basic Operation Guide

This manual describes the basic use of the machine.

Manuals Included in the CD-ROM

e-Manual

This manual explains all the features of the

machine, and is categorized by subject. For

details about using the e-Manual, see “Using the

e-Manual” (P.18).

Removing the Packing Materials

Remove all the packing materials, such as orange tape. Packing materials may change in form or placement, or may be added or

removed without prior notice.

Proper Handling

Hold here.

Check!

Are all the packing materials removed?

Tape Packing Material

with tape

Removing the Packing Materials

Do not remove this

packing material yet.

Establishing an Installation Site

= 4" (100 mm)

D560

35 5/8" (904 mm)

24 5/8" (626 mm)

27 3/4" (706 mm)

★

D530

35 5/8" (904 mm)

23 1/4" (590 mm)

27 3/4" (703 mm)

★

2 3

Do not place the machine near the following:

• Alcohol, paint thinner, or other ﬂammable substances ▶If ﬂammable substances come into contact with electrical

parts inside the machine, this may result in a ﬁre or electrical shock.

• Any medical equipment ▶Radio wave emitted from this machine may interfere with medical equipment.

• Surfaces that are unstable, subject to excessive vibration, objects that could block the ventilation slot, dampness

or dust, in direct sunlight or exposed to the elements, subject to high temperatures, open ﬂames, and poor

ventilation ▶Installing the machine in locations with these characteristics may result in personal injury, ﬁre, or

electric shock.

Ozone from the Unit

Although ozone is generated from the machine during operation, it does not have any aﬀect on the human body.

However, if you intend to use the machine for long periods of time, ensure that the installation location is well

ventilated for a comfortable working environment.

Preface Installing the Machine

Connecting to a Computer and Installing the Drivers

Protrusions

Left Side

Right Side

The plastic part

is also a packing

material. Be sure

to remove it.

The length of the tape is

approximately 20" (50 cm).

Fit the protrusions on each side of the toner cartridge,

and then slide the toner cartridge into the machine.

910

Protrusions

Preparing the Toner Cartridge

Shake 5 to 6 times.

Place on a ﬂat surface.

Preface Installing the Machine

Connecting to a Computer and Installing the Drivers

Check!

Are all the packing materials removed?

Packing materials

Sealing Tape

Packing material

with a sheet

Loading Paper

Loading Paper Other than Letter Size

The procedure here is for loading Letter size paper. To load paper other than Letter size, such as Legal or

Statement, see “Loading Paper Other than Letter Size” (P.16) after ﬁnishing the initial settings.

Adjust the paper guides tightly to

the width and length of the paper.

Spread the paper guides a little wider

than the width and length of the paper.

Loading Paper

Preface Installing the Machine

Connecting to a Computer and Installing the Drivers

Use the paper stopper when printing.

Lift the paper stopper to prevent the paper from

falling out of the output tray.

Load Limit Guide

Push until the edge of the paper stack

meets the back of the paper cassette.

Check!

Make sure that the paper

stack does not exceed the

load limit guide.

Language

English

French

Portuguese

Spanish

Select Country/Region

United States (US)

Canada (CA)

Brazil (BR)

Mexico (MX)

• Press [◀] or [▶] to move the cursor to the left and

right.

• Press [▲] or [▼] to change the numeric value,

or AM/PM.

※The factory default settings for time display is set as 12-Hour.

Current Time Set.

01/01/2012 12:52 AM

(0:00-12:59)

Connecting the Power Cord

OFF

Do not connect the USB cable.

Connect the cable when installing the software.

Make sure

that the

machine is

turned OFF.

Press [▲] or [▼] to highlight a

language, and then press [OK].

Press [▲] or [▼] to highlight a

region, and then press [OK].

Enter the date and time, and then press [OK].
