INSTRUCTION MANUAL
E
Instruction Manual
Wi-Fi Adapter
W-E1
2
Wi-Fi Adapter W-E1 is an accessory that enables Wi-Fi (wireless
communication) functions when installed in the SD card slot of the
EOS 7D Mark II, EOS 5DS, or EOS 5DS R.
The wireless communication functions available with the W-E1 are as
follows.
(1)qCommunicate with a smartphone (p.21, 53)
Connect the camera to a smartphone or tablet wirelessly and use
the dedicated application “Camera Connect” to do the following.
• View images stored in the camera on a smartphone or save
viewed images to a smartphone.
• Operate the camera to shoot still photos or change camera
settings using a smartphone.
In this manual and on the camera’s LCD monitor, “smartphone”
refers to smartphones and tablets.
(2)DOperate remotely using EOS Utility (p.27, 59)
Connect the camera to a computer wirelessly and operate the
camera remotely using EOS Utility (EOS software).
Introduction
What You Can Do Using the W-E1
Images cannot be recorded on the W-E1. Be sure to prepare a CF card
for recording images.
Depending on the transmission range and connection status, image display
may be delayed, images may not be displayed smoothly, or shutter release
timing may be delayed.
Note that Canon cannot be held liable for any loss or damage from
erroneous wireless communication settings for using the W-E1. In addition,
Canon cannot be held liable for any other loss or damage caused by use of
the W-E1.
When using wireless functions, establish appropriate security at your own
risk and discretion. Canon cannot be held liable for any loss or damage
caused by unauthorized access or other security breaches.
3
In this manual, the terms “wireless” and “wireless LAN” are used as
general terms for Wi-Fi and Canon’s original wireless functions.
The term “access point” indicates wireless LAN terminals (wireless
LAN access points, wireless LAN routers, etc.) that relay wireless
LAN connection.
Read the Camera Instruction Manual and familiarize yourself with
operating the camera. Explanations in this instruction manual
assume that you are accustomed to the camera operations.
Screens in this manual are of the EOS 7D Mark II.
Icons in this Manual
<6> : Indicates the Main Dial.
<5> : Indicates the Quick Control Dial.
<9> : Indicates the Multi-controller.
<0> : Indicates the Setting button.
* In addition to the above, the icons and symbols used on the camera’s buttons
and displayed on the LCD monitor are also used in this manual when discussing
relevant operations and functionality.
(p.**) : Reference page numbers for more information.
: Warnings to prevent potential problems during operation.
: Supplemental information.
Conventions Used in this Manual
4
This manual consists of the following five sections: “Getting Started”,
“Easy Connection”, “Advanced Connection”, “When Connected”, and
“Reference”.
After preparing to connect in “Getting Started”, follow the diagram below
and see the corresponding pages according to your needs.
Structure of this Manual
Getting Started (p.9)
Explains how to register a nickname and the basic operations.
Selecting Connection Destination
qSmartphone
DEOS Utility
Easy Connection (p.19)
Explains how to connect the camera
directly to the device.
Advanced Connection (p.33)
Mainly explains how to connect using
a Wi-Fi access point.
A smartphone or computer can be
connected to a camera while
maintaining connection to an access
point.
When Connected (p.51)
Explains how to use the wireless functions such as sending images after a
connection is established.
Reference (p.73)
Describes the solutions to problems and other information. Read as necessary.
5
2
1
3
Introduction 2
What You Can Do Using the W-E1...................................................2
Conventions Used in this Manual .....................................................3
Structure of this Manual ....................................................................4
Safety Precautions............................................................................8
Handling Precautions........................................................................8
Getting Started 9
Operation Flowchart .......................................................................10
Preparation and Basic Operation 11
Preparing to Use the W-E1.............................................................12
Installing the W-E1 in the Camera ..................................................12
Basic Operation and Settings .........................................................16
Preparation for Smartphones..........................................................18
Easy Connection 19
Wireless Function Operation Flowchart (Easy Connection) ...........20
Easy Connection to a Smartphone 21
Connecting with [Easy connection]...............................................22
Easy Connection to EOS Utility 27
Connecting with [Easy connection]...............................................28
Contents
6
Contents
4
5
8
6
7
Advanced Connection 33
Wireless LAN Function Operation Flowchart (Advanced Connection)
... 34
Connecting by Selecting a Network 35
Checking the Type of Access Point................................................ 36
Connecting via WPS (PBC Mode).................................................. 37
Connecting via WPS (PIN Mode) ................................................... 41
Connecting to a Detected Network Manually ................................. 45
When Connected 51
Communicating with a Smartphone 53
Operating the Camera Using a Smartphone .................................. 54
Specifying Viewable Images .......................................................... 56
Operating Remotely Using EOS Utility 59
Using EOS Utility............................................................................ 60
Reconnecting and Adding Settings 63
Reconnecting ................................................................................. 64
Registering Multiple Connection Settings....................................... 66
Checking and Operating Connection Settings 67
Checking, Changing, or Deleting Connection Settings .................. 68
Clearing Wi-Fi Function Settings.................................................... 71
7
Contents
10
9
Reference 73
Troubleshooting Guide 75
Responding to Error Messages ......................................................76
Troubleshooting Guide....................................................................84
Wireless Function Notes .................................................................85
Security ...........................................................................................86
Checking Network Settings.............................................................87
Reference 89
Setting up the Network Manually ....................................................90
Setting up the IP Address Manually................................................92
Specifications..................................................................................94
Index ...............................................................................................96
8
The following precautions are provided to prevent harm or injury to
yourself and others. Make sure to thoroughly understand and follow
these precautions before using the product.
If you experience any malfunctions, problems, or damage to the
product, contact the nearest Canon Service Center or the dealer
from whom you purchased the product.
Safety Precautions
Warnings: Follow the warnings below. Otherwise, death or
serious injuries may result.
Before using the camera inside an airplane or hospital, check if it is allowed.
Electromagnetic waves emitted by the W-E1 may interfere with the plane’s
instruments or the hospital’s medical equipment.
Cautions: Follow the cautions below. Otherwise, physical injury
or property damage may result.
Keep the W-E1 out of the reach of children and infants. If a child or infant swallows it,
consult a physician immediately.
Do not touch the contacts with your fingers or metal objects. Do not expose the
contacts to dust or water. If a smudge adheres to the contacts, communication
failure may result.
The W-E1’s wireless functions may not work when the camera is hot, such as
immediately after prolonged movie shooting. Use the wireless functions after
the camera cools down.
If the wireless functions are used for a prolonged period, the W-E1 may
become hot due to excessive heat in the camera. When removing the W-E1,
set the camera’s power switch to <2>, then wait until the camera cools
down.
To prevent damage to the W-E1, note the following:
• Do not drop, bend, or wet it. Do not subject it to excessive force, physical shock, or
vibration.
• Do not affix any stickers, etc., on it.
• Do not store or use it near anything that has a strong magnetic field, such as a TV
set, speakers, or magnets. Also avoid places prone to having static electricity.
• Do not leave it in direct sunlight or near a heat source.
• Store it in a case, etc.
• Do not store it in hot, dusty, or humid locations.
Handling Precautions
9
Getting Started
10
This section explains how to register a nickname (for identification) and
the basic operation of the wireless functions.
Follow the procedures below.
Operation Flowchart
Install the W-E1 in the camera. (p.12)
Register a nickname. (p.13)
Set the camera’s nickname.
The default nickname (the camera name) can
be used.
Be sure to set a nickname as otherwise you
cannot set the wireless functions.
Display the [Wi-Fi function] screen.
(Steps 1 and 2 on page 16)
Select a Wi-Fi function and establish a
connection.
For further settings, see “Easy Connection” or
“Advanced Connection”.
Easy Connection (p.19)
Connect the camera directly to the
device.
Advanced Connection (p.33)
Connect using a Wi-Fi access point.
