English

FAX L Driver Installation Guide

Illustrations and displays used in this manual are which of FAX-L170 unless specified.

User Software CD-ROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Drivers and Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Supported Operating Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Installing the FAX L Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installing with [Easy Installation]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installing with [Custom Installation] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

USB cable connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Checking the installation results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

How to Use the Online Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

How to Check the Windows Vista/7 Processor Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Uninstalling the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

User Software CD-ROM

Drivers and Software

FAX L Drivers

Printer driver You can print from an application using the machine by installing the

printer driver on your computer. You can process print data at high speed by

compressing the print data using the computer's processing capability.

Fax driver If you install the fax driver on your computer, you can select "Print" from an

application, select the Canon fax driver as a printer, and specify the output

destination and options. The fax driver converts the data into an image that

conforms to standard fax protocols so that the data can be printed or saved

using the recipient's fax machine.

Supported Operating Systems

: Available : Not Available

Windows 2000/XP Windows Vista/7

Printer driver

Fax driver

Installing the FAX L Drivers

Install the software to use the machine.

•If you are using a 64-bit operating system

The FAX L drivers for 64-bit operating systems may not be supplied depending on your country or region.

•User rights for logging on to Windows

Log on as a user with administrative rights.

•When installing via USB connection

Connect the USB cable after the software installation.

Make sure that the power of the machine is turned ON when connecting the USB cable.

•Installing the e-Manual

The e-Manual is not installed by selecting [Easy Installation].

To install the e-Manual, select [Custom Installation] on p. 6.

* If the Multi-lingual User Manual CD is supplied with the machine, install the e-Manual from the Multi-lingual User Manual CD.

Installing with [Easy Installation]

Insert the User Software CD-ROM into the slot on your computer.

Click [Easy Installation].

To install the following manual that cannot be installed with [Easy Installation], select [Custom

Installation] (See p. 6).

•e-Manual

* If the Multi-lingual User Manual CD is supplied with the machine, install the e-Manual from the Multi-lingual User Manual CD.



* The options to be displayed differ depending on your country or region.

If the above CD-ROM setup screen does not appear:

Windows 2000, XP

1. From the [Start] menu, select [Run].

2. Enter "D:\MInst.exe", and then click [OK].

Windows Vista, 7

1. Enter "D:\MInst.exe" in [Start Search] or [Search programs and files] under the [Start] menu.

2. Press the [ENTER] key on the keyboard.

* The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the

computer you are using.

If the language selection screen is displayed before the CD-ROM setup screen appears:

Select the language and then click [Next].

Click [Install].

Read the License Agreement, and then click [Yes].

Click [Next].

Click [Exit].

Confirm that the application is selected [ ] under [Install], and then click

[Next].

Restart your computer.

(1) Select the [Restart Computer Now (Recommended)] check box.

(2) Click [Restart].

The CD-ROM may be removed once this screen appears.

(1)

(2)

Connect the USB cable after restarting your computer.

See "USB cable connection" on p. 10.

Installing with [Custom Installation]

Insert the User Software CD-ROM into the slot on your computer.

Click [Custom Installation].

The options to be displayed differ depending on your country or region.

If the above CD-ROM setup screen does not appear:

Windows 2000, XP, and Server 2003

1. From the [Start] menu, select [Run].

2. Enter "D:\MInst.exe", and then click [OK].

Windows Vista, 7, and Server 2008

1. Enter "D:\MInst.exe" in [Start Search] or [Search programs and files] under the [Start] menu.

2. Press the [ENTER] key on the keyboard.

* The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the

computer you are using.

If the language selection screen is displayed before the CD-ROM setup screen appears:

Select the language and then click [Next].

Select the check box next to the application you want to install, and then

click [Install].

The options to be displayed differ depending on your country or region.

To install the e-Manual, select the [Manuals] check box.

* If [Manuals] does not appear , install the e-Manual from the Multi-lingual User Manual CD supplied with the machine.

Read the License Agreement, and then click [Yes].

Click [Next].

Click [Exit].

Confirm that the applications are selected [ ] under [Install], and then

click [Next].

The options to be displayed differ depending on your country or region.

Restart your computer.

(1) Select the [Restart Computer Now (Recommended)] check box.

(2) Click [Restart].

The CD-ROM may be removed once this screen appears.

(1)

(2)

Connect the USB cable after restarting your computer.

See "USB cable connection" on p. 10.
