entroview+

user guide

entroview+ user guide

To let the caller gain access, press Unlock.

Replace the handset to complete the call.

Press the Privacy button or Adjust the ringer volume with the slider.

Concierge Button / Call Back / Camera Switch Button if applicable.

If you do not wish to be disturbed, press Privacy. The button will illuminate and the ringer is silenced. Press the

button again to turn the ringer back on.

Lift the handset to answer an incoming call. The video monitor will display for the length of the call.

Cat 5e / Cat 6 / CW1308 6 Pair Minimum.

This does not allow for redundant cables. If this is a requirement then the installer must allow for this during

installation.

10 Pair CW1308 recommended for cable runs exceeding 70 metres.

Any unused cores to be tied to system 0v.

When someone calls

cable specification

While on a call

Silence a call

Cb button

keep it quiet

Privacy

Unlock

Adjust

Low Med Hi

V-

V+

EX To Sou nders or Beacon s Only

BZ*

V-

V+

Suggested Colour Code

Cat 5 / Cat 6

DR - White/Blue+Blue/White

VT - White/Orange+Orange/Whit

0V - White/Green+White/Brown

BZ - White/Grey

S2 - Green/White

S1 - Brown/White

DS - Grey/White

V- - Red/Blue

V+ - Blue/Red

Suggested Colour Code

6 Pair CW1308

White/Blue

Blue

White/Orange

*Orange

White/Green

Green

White/Brown

Brown

CB*

Optional

Door Bell

entroview+ user guide

* NOTE: If DS is required the internal ringer can be enabled and the BZ connection is not required, freeing up the Orange wire.

wiring diagram

Privacy

Unlock

Adjust

Press the Menu button to turn the screen on.

Press Menu to cycle through the on screen display options.

Press + or – to adjust the selected parameter. Once adjusted the settings will store

and the screen will turn off.

video setup

3 Position Call

Tone Volume

Low Med Hi

Switches 1, 2 & 3 select the privacy function

options. Privacy can be: disabled completely, set to

latch on/off or set to time out after a preset time (see

table: 0 = OFF 1 = ON).

Switch 4is for 1 way systems and should be ON for

normal use.

Switch 5is not used.

Switch 6selects video termination and should be

ON for normal use.

V-

V+

PL12

Option Switches

12 34 56

1 2 3 Time

0 0 0

0 0 1 Disabled

0 1 0 5 mins

0 1 1 30 mins

1 0 0 1 hr

1 0 1 4 hrs

1 1 0 8 hrs

1 1 1 12 hrs

option switches

To adjust the ringtone press and hold Privacy to start the ringer. Press Privacy to select the ringtone options and

press Door Open to store.

ringtones
