CAME ACS01 Manual de usuario

Access control system

ACS01

YOUR ACCESS CONTROL SYSTEM

ACS01

Quick guide

FA01815-EN

EN English

Page 2- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

GENERAL PRECAUTIONS

Important safety instructions.

Please follow all of these instructions. Improper installation may cause serious

bodily harm.

Only use this product for its intended purpose. Any other use is hazardous. • All

operations indicated in this manual must be carried out exclusively by skilled and

qualiﬁed personnel and in full compliance with the regulations in force. • The device

must be installed, wired, connected and tested according to good professional

practice, in compliance with the standards and laws in force. • Data cabling must

be tested and certiﬁed before connecting to the ACS01. • The user experience may

vary according to the available bandwidth/internet connection. • The control board

must be powered o and all batteries must be removed during installation and

maintenance or when making electronic connections. •

CAME S.p.A. declares that the product described in this manual complies with

Directive 2014/53/EU and the Radio Equipment Regulations 2017.

The full EC declaration of conformity and UK Conformity Assessed (UKCA) marking

information can be found at www.came.com.

5 steps for conﬁguring ACS01

①Connect ACS01 to a PoE switch with an Internet connection.

②Go to came.io and create an account, or log in if an account has already been created.

③Create a site on came.io

④Associate the access control module with the site.

⑤Launch site conﬁguration.

For more information, see the full ACS01 manual available on docs.came.com

by typing ACS01 as search key.

Page 3- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

Technical requirements

Properly functioning LAN, preferably with an internet connection. If no LAN is available, use a reliable 4G cellular connection or

a compatible Wi-Fi connection.

Power supply: 12V - 24V AC/DC or PoE (Power over Ethernet)

Minimum network speciﬁcations:

- 1000BASE-T Ethernet (IEEE 802.3-2012);

- DHCP;

- DNS.

Minimum internet connection speciﬁcations:

- Download >30Mbit/s;

- Upload: >5Mbit/s;

- Latency: 40ms;

Ports for communication with the Cloud:

- 443 (out): for communication with came.io UDP/TCP;

- 4040 (out): for communication with mqtt.bluecherry.io UDP/TCP;

- 123 (out on UDP): for NTP communication with:

147.135.207.214

93.94.88.51

93.94.88.50

194.0.5.123

162.159.200.123

162.159.200.1

80.211.178.99

185.19.184.35

188.166.105.124

167.99.40.178

188.166.85.21

Port for internal communication:

- 80: for HTTP/Websocket interface;

- 2000: for GroupTalk connection.

Page 4- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

DESCRIPTION OF PARTS AND TECHNICAL SPECIFICATIONS

ACS01

NC C NO NC C NO NC C NO NC C NO

IN 1

IN 2

IN 3

+ - + - + -

IN 4

+ -

G CH CH

A1 B1 A2 B2 S1 S2 G B L D0 D1 B L D0 D1 A B G + - + -

Page 5- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

1Outputs: 4 relays can switch max. 3A to 24V DC

24 inputs (power up to 24V AC/DC)

3CAN-bus: enables communication with CAME BPT systems or expansion modules

4Microswitches to select wet or dry inputs. ON = dry contact (without power); OFF contact = wet (with power)

5Reset button

6Micro-SIM expansion slot

7Antennas for connection with Wi-Fi or 4G modules

8Status LEDs

9Optional expansion slot for 4G module + antenna (7). Ethernet provided by default

10 Power input 12V and 24V AC/DC

11 Network: 1 Gbps Ethernet/PoE port

12 USB ports: one USB 2.0 port and one USB 3.0 port for connecting dierent devices

13 SD card expansion slot

14 Output 12V DC, max 125 mA

15 Optional expansion slot for Wi-Fi module + antenna (7). Ethernet provided by default

16 RS 232/485: 1 port for connecting additional devices

17 2 Wiegand ports for connection with third-party keypads or RFID readers

18 CAME transponder (2 connections for CAME transponders)

19 CAME keypad (2 connections for SELT or S5000/S7000 CAME accessories)

20 RTC: Real Time Clock for time management during a network or power interruption. Type of battery: CR2032

21 Conﬁguration button

Page 6- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

LED legend

CEW4G

STATUS Blue Cloud LED

Green Ethernet

LED E

Green Wi-Fi LED

WGreen 4G LED 4G Red Power LED

OFF / Not

installed ////Solid

NO connection Quick ﬂash Quick ﬂash Quick ﬂash Quick ﬂash Solid

NOT connected

to account

Blinking 2x fast

1x slow Solid Solid Solid Solid

Found Solid Solid Solid Solid Solid

Conﬁguration

mode

Solid Blinking

(x1) Slow blinking

in mode 1

Blinking

(x1) Slow blinking

in mode 1

/ Quick ﬂash

Page 7- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

Technical data

Technical

Speciﬁcations Amount Speciﬁcations Cabling Max. Length (m)

PoE power supply 1 PoE (IEEE802.3af) cat 5e 100

Power Supply AC/DC 1 12-24V AC/DC 2x1 mm2 30

Output relays 4 3A 24V DC 2x1 mm2 50

Inputs 4

wet contact 12-24V

AC/DC or dry contact,

selectable by DIP-

switch

2x1 mm2 50

CAME BPT, CAN-Bus 1Protocol: BPT,

termination 120Ω 3x1 mm2

900 total cable length

250 maximum section

length

CAME keypad 2 2x0,75 mm2 100

CAME transponder 2 2x0,75 mm2 100

Wiegand 2 4x1 mm2 70

RS232 1Baudrate: 9600 -

921600 3x1 mm2 Depending on the

baudrate

RS485 1EIA-485 Baudrate:

9600 - 921600 3x1 mm2 Depending on the

baudrate

Output power supply 1 12 V DC 125 mA 2x0,75 mm2 30

USB 2.0 1 USB 2.0 cable 2

USB 3.0 1 USB 3.0 cable 2

Ethernet Port 1 1 Gbps PoE cat 5e 100

Internal fuse 1 1,5A max.

Power supply Power consumption (W) Ethernet

module Current draw (A) Ethernet module

24 V DC 7,8 0,33

24 V AC 8,5 0,45

12 V DC 9,2 0,77

12 V AC 10,8 0,93

PoE 10,9 0,12

Usage features Speciﬁcations

Temperature range 0 - 50 °C

Humidity 0 - 90%, no condensation allowed

Typical installation cabinet Electrical cabinet according to local electrical directives

Module type Length (mm) Width (mm) Height (mm)

ACS01 212 90 58

Page 8- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

Version Standard Frequency operating band

(MHz)

Max. conducted output

power (dBm)

ACS01MLS (815AC-0010) Ethernet n.a. n.a.

ACS01MGS (815AC-0020)

ACS01MGSE (815AC-0021)

GSM 880 - 915 33

DCS 1710 - 1785 30

UMTS 1920 - 1980 24

880 - 915

LT E

1920 - 1980

1710 - 1785

2500 - 2570

880 - 915

832 - 862

703 - 748

ACS01MWS (815AC-0030)

ACS01MWSE (815AC-0031)

Wi-Fi 2400 - 2483,5 16

NETWORK CONNECTION

Network connection

Ethernet / PoE network connection

+ -

Connect the Ethernet/PoE port of the module to the network.

In PoE connection, the ACS01 receives power via the Ethernet

cable. Connecting the power cable is optional.

When no PoE is available, power the ACS01 locally

via the corresponding terminal.10

Page 9- Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

Wi-Fi connection

Connect the antennas provided either directly on the control board or via a cable. 7

ACS01

4G connection

Insert the SIM card in the speciﬁc slot. 6

Connect the antennas provided either directly on the control board or via a cable. 7

ACS01

Page 10 - Manual FA01815-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions

Connecting the power supply

The ACS01 can be powered in two ways:

1. Ethernet (PoE) - preferable( 11 )

2. Electrical connections for 12V or 24V AC/DC(10 )

The red LED Pis stable when there is power.

Both the power supply and the PoE can also be connected. The PoE will always be used as the primary power

supply. In the event of a connection failure, the module will switch to the traditional power supply.

CAME accessories connection

Keypad selector

Model Connection on

the keypad

Connection on

ACS01 port 1

Connection on

ACS01 port 2 DIP conﬁguration

S5000 Blue cable A1 A2 n.a.

White cable B1 B2

S7000 AA1A2

n.a.

BB1B2

SELTxNDG, SELTxBDG

AA1A2

1,2,3 = OFF

4 = ON

BB1B2

When entering the code, conﬁrm with #.

Transponder selector switch

Model Connection on

the transponder

Connection on

ACS01 port 1

Connection on

ACS01 port 2 DIP conﬁguration

001TSP00 Red cable S1 S1 n.a.

Black cable G G

SELRxNDG, SELRxBDG

S1 S1 S1

1,2,3 = OFF

4 = ON

GND G G

MTM modules

MTM module connection Connection on ACS01

D+ CH

D- CL

C-
