CAME ACS-EM Manual de usuario

ACS-EM

FA01889-EN

EN English

Page 2- FA01889-EN - 09/2022 - © CAME S.p.A. - -

GENERAL PRECAUTIONS

Important safety instructions.

Please follow all of these instructions. Improper installation may cause serious bodily

harm.

Only use this product for its intended purpose. Any other use is hazardous. • All operations

indicated in this manual must be carried out exclusively by skilled and qualiﬁed personnel

and in full compliance with the regulations in force. • The device must be installed, wired,

connected and tested according to good professional practice, in compliance with the

standards and laws in force. • Data cabling must be tested and certiﬁed before connecting

to the ACS01. • The user experience may vary according to the available bandwidth/

internet connection. • The control board must be powered o and all batteries must be

removed during installation and maintenance or when making electronic connections.

Page 3- FA01889-EN - 09/2022 - © CAME S.p.A. - -

PRODUCT DATA AND INFORMATION

Description

ACS-EM is an expansion device for the ACS01 access control module used to increase the number of connected inputs, outputs and

readers. 2 inputs with power supply, 2 outputs with relay, 2 keypad selectors and 2 CAME transponders can be connected to each ACS-

EM. No data are stored on the ACS-EM, therefore it must always be connected to the main ACS01 module via a CAN bus.

Page 4- FA01889-EN - 09/2022 - © CAME S.p.A. - -

Description of parts

PW IN1 IN2 R1 R2

CL CH G B1 A1 B2 A2 G S1 G S2

NC C NO NC C NO

+ - + - + -

124V AC/DC power-supply input

22 inputs with power supply up to 24V AC/DC

3Outputs: 2 relays can switch max. 3A to 24V DC

4Reset button

5Output LEDs

6Power LED

7CAME transponder connection terminal block (2

connections)

8CAME keypad connection terminal block (2 connections for

SELT or S5000/S7000 accessories)

9ACS01 module connection terminal block (CAN bus)

10 End-of-line jumper

11 Input LEDs

Page 5- FA01889-EN - 09/2022 - © CAME S.p.A. - -

Technical data

Technical Speciﬁcations Amount Speciﬁcations Cabling Max. Length (m)

Power Supply AC/DC 1 24 V AC/DC 2x1 mm² 30

Output relays 2 3A 24V AC/DC 2x1 mm² 50

Inputs 2 Contact with 12-24 V

AC/DC power

2x1 mm² 50

CAN Bus communication 1 3x1 mm² 900 total cable length

250 maximum section length

CAME keypad 2 2x0.75 mm² 50

CAME transponder 2 2x0.75 mm² 50

Device Power supply Maximum power (W) Maximum current draw (mA)

RFID 24 V AC 4.4 0,18

24 V DC 3.1 0,13

MIFARE 24 V AC 6.7 0,28

24 V DC 4.9 0,20

Usage features Speciﬁcations

Temperature range 0 - 50 °C

Humidity 0 - 90%, no condensation allowed

Typical installation cabinet Electrical cabinet according to local electrical directives

Module type Length (mm) Width (mm) Height (mm)

ACS-EM 94 72 58,5

Page 6- FA01889-EN - 09/2022 - © CAME S.p.A. - -

ELECTRICAL CONNECTIONS

Connecting the power supply

B1 A1 B2 A2 G S1 G S2CL CH G

NC C NO NC C NO

+ - + - + -

Power the module with 24 V AC/DC via the relevant terminal

1. When the module is powered up, the LED 6lights up.

Page 7- FA01889-EN - 09/2022 - © CAME S.p.A. - -

Connecting to the ACS01 module

CL CH G B1 A1 B2 A2 G S1 G S2

ACS01

IN 1

IN 2

IN 3

- + - + -

IN 4

+ - G CL CH

B1 A1

B2 A2

Connect the ACS-EM to the ACS01 module via a CAN bus to allow

communication with the access-control system.

Close the end-of-line jumper on the last ACS-EM module

connected.

Page 8- FA01889-EN - 09/2022 - © CAME S.p.A. - -

Inputs and outputs

Inputs are used to detect the operator status (open/closed) via electrical contacts installed on the operator or in the electric/magnetic

lock.

Outputs are used to control the operators.

Input connections

NC C NO

RELAY 1

NC C NO

RELAY 2IN 2IN 1

POWER

ACS

EXPANSION MODULE

KEYPAD 1CAN KEYPAD 2 BADGE 1 BADGE 2

CL CH G B1 A1 B2 A2 G S1 G S2

+-+-

+24 V

POWER SUPPLY

0 V

24 V

0 V

RELAY

OUT

Page 9- FA01889-EN - 09/2022 - © CAME S.p.A. - -

CAME accessories connection

Keypad selector

Model Keypad connection Module port 1

connection

Module port 2

connection

DIP conﬁguration

S5000 Blue cable A1 A2 n.a.

White cable B1 B2

S7000 A A1 A2 n.a.

BB1B2

SELTxNDG, SELTxBDG A A1 A2 1,2,3 = OFF

4 = ON

BB1B2

When entering the code, conﬁrm with #.

Transponder selector switch

Model Transponder

connection

Module port 1

connection

Module port 2

connection

DIP conﬁguration

001TSP00 Red cable S1 S1 n.a.

Black cable G G

SELRxNDG, SELRxBDG

S1 S1 S1

1,2,3 = OFF

4 = ON

GND G G

Page 10 - FA01889-EN - 09/2022 - © CAME S.p.A. - -

CONNECTION EXAMPLES

−W

−

ACS-EM

ACS01

YOUR ACCESS CONTROL SYSTEM

NC C NO

RELAY1

NC C NO

RELAY2IN 2IN 1

POWER

ACS

EXPANSION MODULE

KEYPAD1CAN KEYPAD 2 BADGE1 BADGE2

CL CH G B1 A1 B2 A2 G S1 G S2

+-+-

ACS-EM

NC C NO

RELAY1

NC C NO

RELAY2IN 2IN 1

POWER

ACS

EXPANSION MODULE

KEYPAD1CAN KEYPAD 2 BADGE1 BADGE2

CL CH G B1 A1 B2 A2 G S1 G S2

+-+-

CAN

G CLCH

ACS01

CAME

CONTROL BOARD

+24 V

0 V

CAME

CONTROL BOARD

POWER

SUPPLY

LOCK

POWER

SUPPLY
