USER GUIDE
Thunderbolt
TM
3 & USB-C®Dock with Dual 4K Connectivity
2
Table of Contents
1. General Information
2. Laptop Compatibility
3. Using the USB-C Pro Dock
4. Interface Summary
5. iPad Pro
6. Specifications
7. Accessories
8. Technical Support &
Warranty Information
3
6
7
12
16
17
18
19
3
Eliminate the confusion surrounding the Type-C connector with a dock that
adapts to the interface it is connected to.
Thunderbolt™ 3 and USB-C share the same connector, and until now
Thunderbolt™ 3 devices have only worked on Thunderbolt™ 3 host laptops,
creating confusion for many users.
The USB-C Pro Dock breaks this mould by utilizing the latest ThunderboltTM
technology to adapt itself to your laptop. It is essentially a full ThunderboltTM 3
(40Gb/s) device that has the latest ThunderboltTM advancements in order to be
compatible with non-Thunderbolt 3TM laptops that feature USB-C.
Now everyone can benefit from a feature rich dock without compromising on
connectivity and compatibility.
1. General Information
Introduction
4
Please read the USB-C Pro Dock manual thoroughly and familiarize yourself with
the product before use.
Avoid using the USB-C Pro Dock in extremely hot and cold environments. A safe
temperature range is between 40°F – 95°F (4.4°C - 35°C).
Avoid using the USB-C Pro Dock in humid environments. Moisture and
condensation can accumulate in the device and cause damage to the electrical
components.
Only use the power adapter that has been supplied with the USB-C Pro Dock.
An excessive or inadequate power supply can result in unstable performance or
device failure.
•
•
•
•
Keep the USB-C Pro Dock away from liquids and moisture. Exposure to liquids can
result in damaging the unit, electric shock, and result in a fire hazard.
If your USB-C Pro Dock gets wet while it is still off, do not turn it on. In the case of
any issue with the device, do not attempt to repair or open the device yourself.
Doing so can result in personal injury, damage the device, and will void the
warranty. If you have any issues, please contact CalDigit Technical Support.
•
•
General Use Warnings
Safety Warnings
5
• 1 x USB-C Pro Dock
• 1 x Power Supply
• 1 x Power Cord
(plug style may vary based on regional regulations and requirements.)
• 1 x Thunderbolt™ 3 Cable (0.7m)
A
B
C
D
System Requirements
USB-C computer
ThunderboltTM 3 computer
macOS 10.14.5 Mojave or later
Windows 10 or later
System Requirements
In the Box
D
A
B
C
6
The USB-C Pro is intended for use with ThunderboltTM 3 (40Gb/s) and USB-C laptops.
In addition it can be used with USB-A (5Gb/s) laptops with reduced functionality.
2. Laptop Compatibility
ThunderboltTM 3
(40Gb/s) Laptop USB-C Laptop USB-A (5Gb/s) Laptop
Dual Displays ✓ ✓
Single Display ✓ ✓
USB Connectivity ✓ ✓ ✓
SD Card Reader ✓ ✓ ✓
Giagbit Ethernet ✓ ✓ ✓
Audio ✓ ✓ ✓
Laptop Charging ✓ ✓
7
Powering the
USB-C Pro Dock
NOTE
Always use the supplied Thunderbolt™ 3 cable, a certified 40Gb/s Thunderbolt™ 3
cable or a USB-C cable that is 10Gb/s. If you’re using a Mac do not use the Mac’s USB-C
charging cable as this does not provide 10Gb/s performance.
The USB-C Pro Dock requires power from the AC adapter to operate.
Connect the AC adapter connector to the DC jack on the back of the USB-C
Pro Dock and the other side to an AC outlet.
To power off the USB-C Pro Dock, disconnect the power cable from the AC
outlet.
1.
2.
3. Using the USB-C Pro Dock
8
Connecting the USB-C Pro Dock to
your computer
Once the USB-C Pro Dock has been powered on, connect the device using
the supplied Thunderbolt™ 3 cable from the Thunderbolt™ 3 port labeled
“Computer” on the USB-C Pro Dock to a Thunderbolt™ 3 or USB-C port on
your computer. This single connection will now provide 85W charging for
your laptop in addition to expanding your connectivity options.
NOTE
If you are connecting the USB-C Pro Dock to a USB-A computer you will need a USB-C to
USB-A Cable sold separately.
9
LED Indicator
CalDigit Docking Station
Utility
The USB-C Pro Dock is equipped with an LED indicator, which will display a
BLUE light if the unit is powered on and connected to your computer.
The CalDigit Docking Station Utility makes it incredibly easy to disconnect
all your USB storage devices from the USB-C Pro Dock without the need to
manually disconnect them one by one.
NOTE
NOTE
If you only connect the Power Adapter to the USB-C Dock without connecting the
Thunderbolt™ 3 cable to your laptop at the same time, the blue LED light will not turn
on. The LED will turn on once both the Power Adapter and Thunderbolt™ 3 cable are
connected at the same time.
The CalDigit Docking Station Utility Installer file needs to be downloaded and installed
on your Mac from the CalDigit website. Please go to downloads.caldigit.com/ to
download the Installer package.
10
Disconnecting all
USB storage devices
Disconnecting individual
USB storage devices
Open the CalDigit Docking Station Utility on the top menu bar.
Click the eject button on the USB-C Pro Dock image.
1.
2.
Open the CalDigit Docking Station Utility on the top menu bar.
Click on the specific USB device you would like to eject. Only that device
will be ejected.
1.
2.
