Calculated Industries 6260 Manual de usuario

USER’S

GUIDE AreaTake-Off Tooland Digitizing System

Model

#6260

TABLE OF CONTENTS

INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

PACKAGE CONTENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

RIGHT-HAND ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

LEFT-HAND ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

GETTING STARTED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

KEY DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

MEASURING KEYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

FUNCTION KEYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

SETUP KEYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

USING THE ULTRA SCALE MASTER PRO . . . . . . . . . . . . . 16

UNDERSTANDING THE LCD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

BUILT-IN SCALES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

SHAPES AND DEFINITIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

MEASURING POLYLINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

MEASURING SIMPLE POLYGONS . . . . . . . . . . . . . . . . . . . . . . . .22

MEASURING TAKE-OUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

MEASURING COMPLEX POLYGONS . . . . . . . . . . . . . . . . . . . . . .26

MEASURING IRREGULAR SHAPES . . . . . . . . . . . . . . . . . . . . . . .28

MEASURING ARCS AND CIRCLES . . . . . . . . . . . . . . . . . . . . . . . .30

MEASURING ARCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

MEASURING 3-POINT CIRCLES. . . . . . . . . . . . . . . . . . . . . . . . . .34

CUSTOM SCALES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

SETTING A MEASURED CUSTOM SCALE . . . . . . . . . . . . . . . . . . .36

SETTING AN ENTERED CUSTOM SCALE (IMPERIAL MODE). . . . .38

SETTING A HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

UNITS OF MEASUREMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

DIGITIZER MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

PC INTERFACE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

SENDING VALUES TO YOUR PC (PC SEND). . . . . . . . . . . . . . . . .43

PREFERENCES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

APPENDIX A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

ACCURACY/ERRORS/AUTO SHUT-OFF. . . . . . . . . . . . . . . . . . . . .47

APPENDIX B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

APPENDIX C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

APPENDIX D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

REPAIR AND RETURN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

INTRODUCTION

The Ultra Scale Master Pro

has been speciﬁcally

designed for residential

and light commercial

builders and contractors

requiring area and

volume take-offs. Use

it for estimating project

materials and costs, for

measuring, storing and

calculating perimeters,

areas, and volumes from

architectural plans and

other types of scaled

drawings. Use the

Ultra Scale Master Pro to

calculate the area and

volume of irregular shapes;

it can also be used as a

digitizer. A PC interface

is included to enable data

and measurements to be

sent to PC applications.

The Ultra Scale Master Pro

may be used with or

without a PC.

USER’SGUIDE — 1

SETUP

PACKAGE CONTENTS

Your package contains the following pieces:

Female End Cap

2 — ULTRA SCALEMASTER®PRO

Long Reﬂector Bar

USB Cable

Ultra Scale Master Pro

model 6260 (Puck)

Four“AAA” batteries

(already installed)

Corner Connector

User’s Guide,

Quick Reference Guide,

and Quick Setup Sheet

Male End Cap

USER’SGUIDE — 3

Short Reﬂector Bar

Long Reﬂector Bar

Carrying Case

RIGHT-HAND ASSEMBLY

Assemble the reﬂector bars

as shown. Align the corner

connector at a 90° angle at the

top left corner of the plans.

5. Slide Female End Cap onto the male end of the ﬁrst Long Reﬂector Bar.

The Female End Cap is preinstalled for a Right-Hand conﬁguration.

1. Insert the male end of the

Corner Connector into

the female end of the ﬁrst

Long Reﬂector Bar.

2. Insert the male end of the second

Long Reﬂector Bar into the female

end of the Corner Connector.

NOTE: Sloping side of the Reﬂector

Bars face outward.

4 — ULTRA SCALEMASTER®PRO

4. Insert the Male End Cap into

the female end of the Short

Reﬂector Bar. The Male End

Cap is preinstalled for a Right-

Hand conﬁguration.

3. Insert the male

end of the Short

Reﬂector Bar into

the female end of

the second Long

Reﬂector Bar.

NOTE: Sloping side of the Reﬂector

Bars face outward.

FINAL ASSEMBLY

The ultrasonic beams are sent from the left arm of

the Puck to the top bar, then reﬂected back, and

from the right arm of the Puck to the side bar, then

reﬂected back as shown above.

The Puck can be moved to any point within the bars

as long as the left arm remains parallel to the top bar

and the right arm remains parallel to the side bar as

shown above.

USER’SGUIDE — 5

Right-Hand

Conﬁguration

2nd Long Reﬂector Bar Short Reﬂector Bar

1st Long Reﬂector Bar

Left

Puck Arm

Right

Puck Arm

NOTE: Sloping side of the Reﬂector

Bars face outward.

5. Insert the the male end of

the second Long Reﬂector

Bar into the female end of

the Short Reﬂector Bar.

4. Insert the male end of the Short Reﬂector

Bar into the Female Bar End Cap.

LEFT-HAND ASSEMBLY

Assemble the reﬂector bars as shown. Align

the corner connector at a 90° angle at the

top right corner of the plans.

6 — ULTRA SCALEMASTER®PRO

FINAL ASSEMBLY

The ultrasonic beams are sent from the right arm of

the Puck to the top bar, then reﬂected back, and from

the left arm of the Puck to the side bar, then reﬂected

back as shown above.

The Puck can be moved to any point within the bars

as long as the right arm remains parallel to the top

bar and the left arm remains parallel to the side bar

as shown above.

1. Insert the male end of the

ﬁrst Long Reﬂector Bar

into the female end of the

Corner Connector.

1. Insert male end

of the Corner

Connector into

the female end of

the second Long

Reﬂector Bar.

4. Insert the Male Bar

End Cap into the

female end of the ﬁrst

Long Reﬂector Bar.

USER’SGUIDE — 7

Left-Hand

Conﬁguration

2nd Long Reﬂector BarShort Reﬂector Bar

1st Long Reﬂector Bar

Right

Puck Arm

Left

Puck Arm

GETTING STARTED

Once assembly and setup are complete, proceed with the following steps in

order to begin measuring.

1. When placing the bars and securing the drawing, make sure that the

bars are at least 1" from the outermost measurements.

2. It is essential that the bars remain ﬁxed relative to the drawing’s

position. Scribe a line to mark the initial location of the bars as a

reference point should the bars shift.

3. The Puck should maintain a 45° angle within the bars while measuring.

4. Ensure that the measuring surface is ﬂat and smooth. Make sure there

are no folds, tears, or raised areas of the plans.

5. Make sure there are no objects between the Puck and the bars. This

includes hands, arms, pencils or pens, USB cable, cups, scale rulers, etc.

6. Make sure that no air current is blowing directly into the measuring

area. Air blowing into the measuring path can result in no

measurement reading.

7. To get accurate measurements, make sure that the Puck and the bars are

close to the ambient temperature of the work environment.

8 — ULTRA SCALEMASTER®PRO
