Cadillac CTS 2017 Manual de usuario

CTS

Convenience &

Personalization Guide

2017

cadillac.com

Cruise Control/Voice

Recognition/Heated

Steering Wheel♦

Buttons

Memory

Seat

Buttons

Turn Signal

Lever/Exterior

Lamps Control

Manual

Shift

Paddles

Audio Steering

Wheel Controls/

5-way Control

Power Rake/

Telescope

Steering Wheel

Control♦

Instrument

Cluster/Driver

Information

Center

Engine

Start/Stop

Button

Electric

Parking

Brake

Switch

Power

Window/

Mirror

Controls

Review this guide for an overview of some important features in your Cadillac CTS. Some optional equipment described in this guide

(denoted by♦) may not be included in your vehicle. More detailed information can be found in your Owner Manual.

INSTRUMENT PANEL

Hazard Warning Flashers/

Lane Keep Assist with

Lane Departure Warning♦/

Auto Stop-Start Disable♦

Buttons

Heated/

Ventilated Seat

Buttons♦

Audio

System/

Climate

Controls

Traction Control

and StabiliTrak

Button/Driver

Mode Control

Windshield

Wipers

Lever

Cadillac

CUE Touch

Screen

Glove Box/

Parking Assist/

Automatic

Parking Assist♦

Buttons

Head-Up

Display

Controls♦

REMOTE KEYLESS

ENTRY TRANSMITTER KEYLESS ACCESS SYSTEM

Lock

Press to lock all doors.

Unlock

Press to unlock the driver's door

andfuel door. Press again to unlock

alldoors.

Press and hold to open all windows.

Note: To change the Remote Lock and

Unlock settings, go to Remote Lock, Unlock,

Start in the Vehicle Settings menu.

Remote Start

Use to start the engine from outside the

vehicle. See Adaptive Remote Start on page 17.

Vehicle Locator/Panic Alarm

Press and release to locate your vehicle. e exterior lamps ash

and the horn sounds.

Press and hold for 3 seconds to activate the alarm. e turn signal

lamps ash and the horn sounds for 30 seconds, or until the

buon is pressed again or the vehicle is started.

Trunk Release

Press twice to open the trunk.

Door Key

Press the buon (A) on the side of the transmier to pull the door

key out of the transmier. Use the key to lock/unlock the driver’s

door, front passenger’s door and rear folding seats.♦

See Keys, Doors and Windows in your Owner Manual.

e Keyless Access System enables operation of the doors, ignition

and trunk without removing the Remote Keyless Entry transmier

from your pocket or purse. e transmier must be within 3 feet

of the door being unlocked or the trunk.

KEYLESS UNLOCKING

With the transmier within range:

Press the lock buon on the driver’s door handle to unlock

thedriver’s door; press it again within 5 seconds to unlock

alldoors.

Press the lock buon

on a passenger door

handle to unlock all

doors.

Press the touch pad

above the license plate

to open the trunk.

KEYLESS LOCKING

With the ignition o, the transmier removed from the vehicle,

andall doors closed:

Press the lock buon on any door handle to lock all doors

immediately.

If Passive Locking is turned on, all doors will lock automatically

aer a short delay once all doors are closed. e fuel door will

lock automatically aer several minutes (press the Unlock

buon on the transmier to unlock the fuel door).

Note: To change the Keyless Locking and Unlocking settings, go to Remote

Lock, Unlock, Start in the Vehicle Settings menu.

See Keys, Doors and Windows in your Owner Manual.

♦Optional equipment

KEYLESS START

START

With the vehicle in Park or

Neutral, press the brake pedal

and then press the ENGINE

START/STOP buon to start

theengine. e green indicator

on the buon will illuminate.

Note: The transmitter must be in the

vehicle to turn on the ignition. If the

transmitter battery is weak, place thetransmitter in the pocket under the

rubber mat on the top shelf of the center console to enable the engine to

start. Replace the transmitter battery as soon as possible.

Cell phone chargers may interfere with the operation of the Keyless Start

System and should not be plugged in when starting or turning o the

engine.

STOP/OFF

Shi to Park and press the ENGINE START/STOP buon to

turn o theengine.

Power will be available for 10 minutes to operate the audio system

until the driver’s door is opened and to operate the windows and

sunroof♦until any door is opened.

ACCESSORY

With the engine o and the brake pedal NOT depressed, press

the ENGINE START/STOP buon to place the vehicle in

Accessory mode. e yellow indicator on the buon will

illuminate.

See Driving and Operating in your Owner Manual.

AUTO ENGINE STOP/START

(IF EQUIPPED)

e Auto Engine Stop/Start system is included on 2.0L L4

turbocharged engine and 3.6L V6 engine vehicles.

When the brakes are applied and the vehicle is at a complete stop,

the engine may turn o, depending on operating conditions, to

conserve fuel. When the engine stops, the tachometer displays

AUTO STOP. When the brake pedal is released or the accelerator

pedal is pushed, the engine will restart.

Auto Stop may automatically deactivate if:

• A minimum vehicle speed is not reached.

• e engine or transmission is not at the required operating

temperature.

• e outside temperature is not in the required operating range.

• e shi lever is in any gear other than D (Drive).

• e baery charge is low.

• e current seings for the climate control or defog system

have not been reached.

• e Auto Stop time is greater than 2 minutes.

AUTO ENGINE STOP/START DISABLE

Press the

buon le of the Cadillac CUE screen when the

engine is running to disable the Auto Engine Stop/Start system.

When the system is disabled, the buon indicator will not be illu-

minated and the

symbol on the instrument cluster will change

from green to white with a slash through it.

See Driving and Operating in your Owner Manual.

VOICE RECOGNITION

Push to Talk

Press to interact with the OnStar, Bluetooth or Cadillac CUE system.

End Call/Mute

Press to end/reject a call or mute the audio system.

See your Cadillac CUE Infotainment System Manual.

5-WAY CONTROL

Moves le/right, up/down, and in.

Left/Right

Press to view the le or right

cluster display. Press the le

to exit a display menu.

Up/Down

Press the control bar up or down

to scroll through a menu.

SEL Select

Press to select a highlighted menu item.

See Instruments and Controls in your Owner Manual.

AUDIO CONTROLS

+ –Volume

Press +or –to increase or decrease the volume.

Next/Previous

Press or to select the next or previous favorite radio station,

track or le.

See your Cadillac CUE Infotainment System Manual.

CRUISE CONTROL

On/O

SET Set Speed

With Cruise Control on, press

the control bar down fully to

set the cruise speed.

RES Resume Speed

With Cruise Control on, press the control bar up fully to resume the

previous set speed.

+ – Adjust Speed

When active, press the control bar up (+) or down (–) lightly to

increase or decrease the set speed by 1-mph increments; press up or

down fully to increase or decrease the set speed to the next 5-mph

interval on the speedometer.

Cancel

Press to cancel cruise control without erasing the set speed from

memory.

Following Gap (ADAPTIVE CRUISE CONTROL♦AND

FORWARD COLLISION ALERT♦)

Press repeatedly to select a gap seing of Far, Medium, or Near.

See Driving and Operating in your Owner Manual.

HEATED STEERING WHEEL♦

On/O

See Instruments and Controls in your Owner Manual.

STEERING WHEEL CONTROLS

♦Optional equipment

INSTRUMENT CLUSTER

UPLEVEL CLUSTER CONFIGURATIONS♦

1. With the vehicle in Park, use the 5-way control on the steering

wheel to view the Options page in one of the display zones on

the cluster.

2. Press SEL (Select) to enter the Options menu.

3. Scroll down to highlight Display Layout; press SEL.

4. Scroll up or down to highlight one of the cluster

congurations; press SEL.

5. Press to exit the menu.

See Instruments and Controls in your Owner Manual.

CLUSTER DISPLAY ZONES

Use the 5-way control on the right

side of the steering wheel to move

between the dierent display zones

and scroll through the dierent dis-

plays in each cluster conguration.

Balanced Enhanced Performance (Vsport and V-Series models only)

DRIVER INFORMATION CENTER

e Driver Information Center (DIC) on the instrument cluster

displays a variety of vehicle information. e DIC Info Displays

may include a digital speedometer, trip odometers, fuel range,

average fuel economy, instantaneous fuel economy, average speed,

timer, compass, turn arrow, estimated time to arrival, distance to

destination, speed limit, best fuel economy, speed warning, cruise

control set speed, following distance indicator, gap seing, baery

voltage, engine boost, oil life, and odometer.

INFO PAGES MENU

1. Use the 5-way control on the right side of the steering wheel to

view the Options page in one of the display zones on the cluster.

Press SEL to enter the Options menu.

2. Scroll down to highlight Info Pages; press SEL.

3. Scroll up or down to move through the list of

InfoDisplays.

4. Press SEL to select or deselect a display item.

See Instruments and Controls in your Owner Manual.

HEAD-UP DISPLAY♦

e Head-Up Display (HUD) displays some operating information

onto the windshield. e HUD controls are located on the le side

of the instrument panel.

HUD

Li up or press down to adjust the position of the image. It cannot

be adjusted side-to-side.

INFO

Press to select from four displays: Speed View; Audio/Phone View;

Navigation View; and Performance View.

+ –

Li up or press down to brighten or dim the display.

Hold down to turn o the display.

ROTATION OPTION

Adjust the angle of the HUD image to compensate for windshield

variations.

To adjust the angle of the HUD, use the 5-way control to view

the Options menu on the instrument cluster and select HUD

Rotation.

See Instruments and Controls in your Owner Manual.

♦Optional equipment

TOUCH SCREEN AND CONTROLS

Applications:

Touch the screen icon to

access the application

Wi-Fi Indicator

See your Cadillac CUE Infotainment System Manual.

OFF

Climate Control Power O

Windshield Defrost Mode

Driver’s Temperature

Control

Additional Pages:

Touch to view additional

pages of applications

(optional equipment shown)

Interaction Selector:

Touch to display the

favorites list

Passenger’s Temperature

Control

Passenger’s Heated/

Ventilated Seat Control♦

Driver’s Heated/

Ventilated Seat Control♦

The controls use capacitive technology – simply touch the icon/text

to access a feature or adjust a function.

VOLUME

Touch arrows or swipe

ﬁnger above chrome bar

AUTO

Automatic Climate

Control Operation

Rear Window Defog

Recirculation Mode

Home Page

Storage Compartment

with USB Port and Wireless

Charging♦: Press and hold

the bright bar to open/close

Climate Control Fan Speed

Power/Mute:

Press and hold to turn

Cadillac CUE On/O;

press to mute audio

CADILLAC CUE MENUS

See your Cadillac CUE Infotainment System Manual.

♦Optional equipment

Cadillac CUE oers a variety of entertainment, communication and vehicle system options. Touch an application icon on the touch screen to

access the following items. You can use simple gestures on the touch screen just as you would on a smartphone, such as tap, drag, pinch and

spread, to interact with the Cadillac CUE system.

Audio

• Radio Band

• Media

• Seek Up/Down

• Tune

• Browse

• Menu

Navigation♦

• Zoom Out

• Zoom In

• Reset

• Destination

• Map Menu

• Seek Up/Down

• Mute/Unmute

• Cancel a Destination

Phone

• Voice Recognition

• Contacts

• Recent

• Keypad

• Voice Mail

• Phones

Note: Press and hold the

Push to Talk steering

wheel button to activate

Handset Voice Recognition.

See page 11.

Climate

• Driver/Vehicle

Set Temperature

• Passenger

Set Temperature

• Sync Temperature

Seings

• A/C Mode

• Automatic Climate

On/O

• Air Distribution

Seings

• Front/Rear Seings♦

• Fan Speed

Settings

• Time and Date

• Rear Seat Reminder

• Language

• Valet Mode

• Teen Driver

• Radio

• Vehicle

• Bluetooth

• Apple CarPlay

• Android Auto

• Voice

• Display

• Rear Camera

• Return to Factory

Seings

• Soware Information

CADILLAC CUE FEATURES

STORING FAVORITE STATIONS

Radio stations from all bands (AM, FM or SiriusXM♦), tone seings,

phone contacts and navigation destinations♦can be stored in

anyorder.

1. Display the desired radio station, tone seings, navigation

destination or contact.

2. Touch and drag up the Interaction Selector at the boom of

the screen to display the favorite screen buons.

3. Touch and hold a favorite screen buon.

4. Repeat the steps to store another favorite item.

CADILLAC COLLECTION

♦

In-vehicle apps —

connecting to music,

news, weather, travel

information and more —

are available for down-

load to the radio through

the Collection icon on

the home page.

Downloading and

using the apps requires

Internet connectivity

and a data plan accessed through the vehicle’s OnStar 4G LTE Wi-Fi

hotspot, if active, or a mobile device hotspot.

Visit my.cadillac.com/learn for more information.

Refer to your Owner Manual for important safety information about using

the infotainment system while driving.

Cadillac CUE uses a Bluetooth or USB connection to link a

compatible smartphone, cell phone, USB ash drive or portable

audio player/iPod®to the touch screen infotainment display.

Forassistance, call 1-855-4-CUE-NOW (1-855-428-3669) or visit

my.cadillac.com/learn.

SETTING THE TIME

1. Touch Seings on the Home page.

2. Touch Time and Date.

3. Touch Set Time.

4. Touch +or – to adjust the hours, minutes, and AM or PM.

5. Touch Back to exit the menu.

If the Auto Set feature is enabled, the time will be updated

automatically as the system obtains time information from the

cellular network.

PORTABLE AUDIO DEVICES

Two USB ports and an auxiliary audio input jack are located in the

center console storage compartment.

Connect an iPod®, iPhone®, MP3 player, a USB ash drive or a

USB mass storage device to the USB port.

Touch Audio, and then touch Media until the connected

device is shown. Cadillac CUE will read the device and build a

list of voice commands. Search for music on-screen or by voice

commands.

Tabla de contenidos

Otros manuales de Automóvil de Cadillac

Cadillac

Cadillac CTS 2008 Manual de usuario

Cadillac

Cadillac ESCALADE EXT 2003 Manual de usuario

Cadillac

Cadillac SRX 2008 Manual de usuario

Cadillac

Cadillac Escalade 2022 Manual de usuario

Cadillac

Cadillac 2014 ELR Manual de lista de piezas

Cadillac

Cadillac 2006 Escalade Manual de usuario

Cadillac

Cadillac ESCALADE EXT 2005 Manual de usuario

Cadillac

Cadillac 2011 CTS-V Sports Sedan Manual de usuario

Cadillac

Cadillac 2011 SRX CROSSOVER Manual de usuario

Cadillac

Cadillac 2009 XLR-V Manual de usuario

Cadillac

Cadillac 2011 Escalade ESC Manual de usuario

Cadillac

Cadillac 1999 Seville Manual de usuario

Cadillac

Cadillac XT4 2019 Manual de usuario

Cadillac

Cadillac 2008 XLR Manual de usuario

Cadillac

Cadillac STS 2005 Guía de referencia

Cadillac

Cadillac CTS 2015 Manual de usuario

Cadillac

Cadillac CT6 2020 Manual de usuario

Cadillac

Cadillac 2011 CTS COUPE Manual de usuario

Cadillac

Cadillac 2011 CTS COUPE Manual de lista de piezas

Cadillac

Cadillac 1996 Eldorado Manual de usuario

Cadillac

Cadillac 2006 Escalade Manual de lista de piezas

Cadillac

Cadillac 2012 Cadillac Escalade Manual de usuario

Cadillac

Cadillac CRUZE Manual de instrucciones

Cadillac

Cadillac STS 2008 Guía de referencia

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario

Seat

Seat toledo Manual de usuario
