Cabletron Systems SmartSwitch 9000 Manual de usuario

9032051-01

SmartSwitch 9000

9T125-08

User’s Guide

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,

SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED

TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

35 Industrial Way

Rochester, NH 03867-5005

Printed in the United States of America

Order Number: 9032051-01

LANVIEW

is a registered trademark, and

SmartSwitch

is a trademark of Cabletron Systems, Inc.

CompuServe

is a registered trademark of CompuServe, Inc.

i960 microprocessor

is a registered trademark of Intel Corp.

Ethernet

is a trademark of Xerox Corporation.

Notice

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING:

Changes or modiﬁcations made to this device which are not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

VCCI Notice

This is a Class A product based on the standard of the Voluntary Control Council for Interference by

Information Technology Equipment (VCCI). If this equipment is used in a domestic environment,

radio disturbance may arise. When such trouble occurs, the user may be required to take corrective

actions.

DOC Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la class Aprescrites dans le Règlement sur le brouillage radioélectrique

édicté par le ministère des Communications du Canada.

iii

Notice

DECLARATION OF CONFORMITY

ADDENDUM

Application of Council Directive(s):

89/336/EEC

73/23/EEC

Manufacturer’s Name:

Cabletron Systems, Inc.

Manufacturer’s Address:

35 Industrial Way

PO Box 5005

Rochester, NH 03867

European Representative Name:

Mr. J. Solari

European Representative Address:

Cabletron Systems Limited

Nexus House, Newbury Business Park

London Road, Newbury

Berkshire RG13 2PZ, England

Conformance to Directive(s)/Product Standards:

EC Directive 89/336/EEC

EC Directive 73/23/EEC

EN 55022

EN 50082-1

EN 60950

Equipment Type/Environment:

Networking Equipment, for use in a

Commercial or Light

Industrial Environment.

We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with

this notice conforms to the above directives.

Manufacturer Legal Representative in Europe

Mr. Ronald Fotino Mr. J. Solari

____________________________________________________ ______________________________________________________

Full Name Full Name

Principal Compliance Engineer Managing Director - E.M.E.A.

____________________________________________________ ______________________________________________________

Title Title

Rochester, NH, USA Newbury, Berkshire, England

____________________________________________________ ______________________________________________________

Location Location

Notice

Chapter 1 Introduction

Features...........................................................................................................................1-1

Related Manuals............................................................................................................1-3

Getting Help .................................................................................................................. 1-4

Chapter 2 Installing the SmartSwitch 9000 Module

Unpacking the Module.................................................................................................2-1

Installing a TPIM........................................................................................................... 2-1

User Accessible Components......................................................................................2-2

Setting the Module Card DIP Switch.........................................................................2-4

Ring Speed .....................................................................................................................2-5

Installing the Module into the SmartSwitch 9000 Chassis......................................2-5

The Reset Switch ........................................................................................................... 2-7

Chapter 3 Operation

Bridging..........................................................................................................................3-2

Transparent Bridging.............................................................................................3-2

Source Route Bridging .......................................................................................... 3-3

SR-TB Bridging.......................................................................................................3-3

Spanning Tree Algorithm......................................................................................3-4

Flexible Network Bus (FNB)........................................................................................3-4

System Management Buses .........................................................................................3-4

SMB-1 Bus...............................................................................................................3-5

SMB-10 Bus.............................................................................................................3-5

System Diagnostic Controller...................................................................................... 3-5

DC/DC Converter ........................................................................................................3-5

FNB Interface.................................................................................................................3-6

i960 Core......................................................................................................................... 3-6

Chapter 4 LANVIEW LEDs

Contents

Chapter 5 Speciﬁcations

Safety...............................................................................................................................5-1

Service.............................................................................................................................5-1

Physical...........................................................................................................................5-2

Dimensions .............................................................................................................5-2

Weight......................................................................................................................5-2

Electrical .........................................................................................................................5-2

Appendix A TPIM Speciﬁcations

TPIM-T1.........................................................................................................................A-1

TPIM-T2 and TPIM-T4 ................................................................................................A-2

TPIM-F2 and TPIM-F3.................................................................................................A-3

1-1

Chapter 1

Introduction

The 9T125-08 MicroLAN™ Switch Extension Module, shown in Figure 1-1, is a three port

Token Ring switch module. This module supports two separate Token Rings with four lobe

connections each, and an interface to the FNB backplane. Each front panel Token Ring also

supports Ring-in/Ring-out connections by using plug-in Token Ring Port Interface modules,

TPIMs.

Features

Processor

The 9T125-08 is equipped with an advanced Intel i960 microprocessor. This microprocessor

provides a platform for all management functions within a scalable RISC-based architecture.

System Management

Interfaces to the two System Management Buses (SMB-1 and SMB-10) for intermodule

management.

Connectivity

The 9T125-08 provides four RJ45 Trunk Coupling Unit (TCU) lobe connector for each of the

two front panel Token Rings. Each front panel Token Ring has sockets for TPIMs allowing for

Ring-in/Ring-out connections.

SRT Packet Switching

SRT Bridging may occur between the front panel Token Ring connections and

SR-TB bridging to any other module in the chassis via FNB -1 or FNB -2 of the FNB bus. The

module is capable of Transparent Bridging and/or Source Route Bridging. IEEE 802.1d

Spanning Tree Protocol is supported in all bridging functions. Translational bridging

between Source Routing and Transparent Frames types is also performed for packets

destined for the FNB.

Introduction

1-2

Figure 1-1. The 9T125-08 MicroLAN Switch Extension Module

16 Mb

RING OUT

RING IN

RING OUT

RING IN

TR1

TR2

SMB CPU

FNB

TOKEN RING

9T125-08
