Cabletron Systems SmartSwitch 9000 Manual de usuario

SmartSwitch 9000

9G421-02/9G429-02

Gigabit Ethernet Interface Module

User’s Guide

9032344-02

Notice

Cabletron Systems reserves the right to make changes in speciÞcations and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, Þrmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,

SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED

TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

35 Industrial Way

Rochester, NH 03867-5005

Printed in the United States of America

Order Number: 9032344-02

Cabletron Systems

and

LANVIEW

are registered trademarks, and

SmartSwitch

is a trademark of

Cabletron Systems, Inc.

CompuServe

is a registered trademark of CompuServe, Inc.

i960 microprocessor

is a registered trademark of Intel Corp.

Ethernet

is a trademark of Xerox Corporation.

All other product names mentioned in this manual may be trademarks or registered trademarks of

their respective companies.

Notice

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operatorÕs manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING:

Changes or modiÞcations made to this device which are not expressly approved by the

party responsible for compliance could void the userÕs authority to operate the equipment.

Industry Canada Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le prŽsent appareil numŽrique nÕŽmet pas de bruits radioŽlectriques dŽpassant les limites applicables

aux appareils numŽriques de la class A prescrites dans le R•glement sur le brouillage radioŽlectrique

ŽdictŽ par le minist•re des Communications du Canada.

VCCI Notice

This is a Class A product based on the standard of the Voluntary Control Council for Interference by

Information Technology Equipment (VCCI). If this equipment is used in a domestic environment,

radio disturbance may arise. When such trouble occurs, the user may be required to take corrective

actions.

iii

Notice

Safety Information

CLASS 1 LASERTRANSCEIVERS

The 9G429-02 is a Class 1 Laser Product

The 9G429-02 uses a Class 1 Laser transceiver. Read the following safety

information before installing or operating these adapters.

The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This

control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and

does not allow any user adjustment. Class 1 Laser transceivers comply with the following safety

standards:

¥ 21 CFR 1040.10 and 1040.11 U.S. Department of Health and

Human Services (FDA).

¥ IEC Publication 825 (International Electrotechnical Commission).

¥ CENELEC EN 60825 (European Committee for Electrotechnical

Standardization).

When operating within their performance limitations, laser transceiver output meets the Class 1

accessible emission limit of all three standards. Class 1 levels of laser radiation are not considered

hazardous.

Laser Radiation and Connectors

When the connector is in place, all laser radiation remains within the Þber. The maximum amount of

radiant power exiting the Þber (under normal conditions) is -12.6 dBm or 55 x 10

-6

watts.

Removing the optical connector from the transceiver allows laser radiation to emit directly from the

optical port. The maximum radiance from the optical port (under worst case conditions) is 0.8 W cm

-2

or 8 x 10

W m

sr-1.

Do not use optical instruments to view the laser output. The use of optical instruments to view

laser output increases eye hazard. When viewing the output optical port, power must be removed

from the network adapter.

Notice

Declaration of Conformity

Addendum

Application of Council Directive(s):

89/336/EEC

73/23/EEC

ManufacturerÕs Name:

Cabletron Systems, Inc.

ManufacturerÕs Address:

35 Industrial Way

PO Box 5005

Rochester, NH 03867

European Representative Name:

Mr. J. Solari

European Representative Address:

Cabletron Systems Limited

Nexus House, Newbury Business Park

London Road, Newbury

Berkshire RG14 2PZ, England

Conformance to Directive(s)/Product Standards:

EC Directive 89/336/EEC

EC Directive 73/23/EEC

EN 55022

EN 50082-1

EN 60950

Equipment Type/Environment:

Networking Equipment, for use in a

Commercial or Light

Industrial Environment.

We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with

this notice conforms to the above directives.

Manufacturer Legal Representative in Europe

Mr. Ronald Fotino Mr. J. Solari

____________________________________________________ ______________________________________________________

Full Name Full Name

Compliance Engineer Manager Managing Director - E.M.E.A.

____________________________________________________ ______________________________________________________

Title Title

Rochester, NH, USA Newbury, Berkshire, England

____________________________________________________ ______________________________________________________

Location Location

Contents

Chapter 1 Introduction

Features........................................................................................................................... 1-3

Related Manuals............................................................................................................ 1-4

Getting Help .................................................................................................................. 1-5

Chapter 2 Installation

Tools Needed ................................................................................................................. 2-1

Unpacking the Module................................................................................................. 2-1

Physical Layout ............................................................................................................. 2-2

User Accessible Daughterboard Components.......................................................... 2-3

DIP Switch............................................................................................................... 2-3

Removing the Daughterboard from the Motherboard..................................... 2-5

Daughterboard Components ............................................................................... 2-7

SMB-1 PROM .................................................................................................. 2-7

BOOT PROM................................................................................................... 2-7

FLASH SIMM.................................................................................................. 2-7

DRAM SIMM .................................................................................................. 2-7

Installing the Module into the SmartSwitch 9000 Chassis...................................... 2-8

The Reset Switch ......................................................................................................... 2-10

Chapter 3 Operation

System Management Buses ......................................................................................... 3-2

SMB-1 Bus ............................................................................................................... 3-2

SMB-10 Bus ............................................................................................................. 3-2

System Diagnostic Controller...................................................................................... 3-2

DC/DC Converter ........................................................................................................ 3-3

INB Interface.................................................................................................................. 3-3

SecureFast SmartSwitch Architecture ........................................................................ 3-3

i960 Core......................................................................................................................... 3-4

Contents

Chapter 4 LANVIEW LEDs

Appendix A Speciﬁcations

Technical SpeciÞcations...............................................................................................A-1

CPU .........................................................................................................................A-1

Memory ..................................................................................................................A-1

Network Interfaces ...............................................................................................A-1

Regulatory Compliance...............................................................................................A-2

Service............................................................................................................................A-2

Physical..........................................................................................................................A-3

Dimensions ............................................................................................................A-3

Weight.....................................................................................................................A-3

Environment ..........................................................................................................A-3

1-1

Chapter 1

Introduction

The 9G421-02/9G429-02 (Figure 1-1) is a Gigabit Ethernet interface module,

occupying a single slot in the SmartSwitch 9000 chassis. Gigabit Ethernet

networks are connected to the 9G421-02/9G429-02 through front panel ports.

These ports interface with the switch through Gigabit Network Interface Blocks

(GNIB) and are based upon an ASIC architecture.

The module connects to the Internal Network Bus (INB) B, providing a high

speed backplane for communication among other modules in the SmartSwitch

9000 chassis. The 9G421-02/9G429-02 uses a SmartSwitch ASIC design and an

advanced Intel i960

microprocessor providing a platform for all management

functions within a scalable RISC-Based Architecture.

Network management information is available through a variety of methods. All

information based on Simple Network Management Protocol (SNMP) is

accessible either via an in-band (Front Panel port), Side Band (SMB-10), or via the

Environmental ModuleÕs (EM) COM ports. Serial Line Internet Protocol (SLIP) or

Point-to-Point Protocol (PPP) is supported by the EM COM ports. For more

information on the SMB-10, SLIP or PPP refer to the SmartSwitch 9000 Local

Management UserÕs Guide.

The 9G421-02/9G429-02 features front panel LANVIEW

Diagnostic LEDs to

offer at-a-glance status information about each front panel port as well as the

operation of the overall module.

The 9G421-02 uses a shortwave 850 nanometer laser. The 9G429-02 uses a

longwave 1300 nanometer laser. Follow applicable safety precautions to prevent

injury.

CAUTION

Introduction

1-2

Figure 1-1. The 9G421-02/9G429-02 Module

SMB CPU

INB

Otros manuales para SmartSwitch 9000

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de Cabletron Systems

Cabletron Systems

Cabletron Systems FDMMIM Manual de usuario

Cabletron Systems

Cabletron Systems CyberSWITCH CSX400 Manual de usuario

Cabletron Systems

Cabletron Systems 3H02-04 Manual de usuario

Cabletron Systems

Cabletron Systems CSX200 CyberSWITCH Manual de usuario

Cabletron Systems

Cabletron Systems NB20E Manual de usuario

Cabletron Systems

Cabletron Systems Spectrum EMM-E6 Manual de usuario

Cabletron Systems

Cabletron Systems ESX-1380 Manual de programación

Cabletron Systems

Cabletron Systems MMAC-Plus 9W111-08 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch Router Instrucciones de montaje

Cabletron Systems

Cabletron Systems BRIM-WT1 Manual de usuario

Cabletron Systems

Cabletron Systems BRIM-E6 Manual de usuario

Cabletron Systems

Cabletron Systems CyberSWITCH CSX101 Manual del propietario

Cabletron Systems

Cabletron Systems ELS100 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 8-slot Instrucciones de montaje

Cabletron Systems

Cabletron Systems CyberSWITCH CSX400 Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9F106-02 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS100-24TXG Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch Router Manual de usuario

Cabletron Systems

Cabletron Systems CSX200 CyberSWITCH Manual de usuario

Cabletron Systems

Cabletron Systems DELST-UI Manual de programación

Cabletron Systems

Cabletron Systems 2000 Manual de usuario

Cabletron Systems

Cabletron Systems SSR 2000 Manual de usuario

Cabletron Systems

Cabletron Systems SSR-600 Manual de usuario

Cabletron Systems

Cabletron Systems Cabletron SmartSwitch Router 250 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
